Euphonix Modular I/O Configuration Guide
Connections, Power Consumption, Width, Weight

1.3.17 SD942 8ch SD Embedder/De-embedder

General Description
Connections, Power Consumption, Width, Weight

1.3.18 HD943 8ch HD/SD Embedder/De-embedder

General Description
module is capable of terminal-gear type functionality such as
audio replacement, typically when used as an audio console
interface it will function as either an embedder or de-
embedder. All settings are done using on-board switches.
SD out (BNC), SD in (BNC), SD through (BNC), ~800mA,
4HP, ~300g.
The SD942 can embed or de-embed 8 channels of audio
to/from a single SD video signal as per SMPTE272M
standard. Embedding or de-embedding may be applied to
any 8 of the available 16 channels of embedded audio via
flexible cross-point matrix (FC972 Remote required).
Certain settings are done from on-board switches such as
device ID.
Although the module is capable of terminal-gear type
functionality such as audio replacement, typically when used
as an audio console interface it will function as either an
embedder or de-embedder.
Additional features include 8 channel of audio delay, and a
video test pattern generator.
SD in (BNC), SD Out (BNC x2), SD through (BNC),
~1000mA, 4HP, ~300g.
The HD943 can embed or de-embed 8 channels of audio
to/from a single SD or HD video signal (auto-sensing) as per
SMPTE272M (SD) or SMPTE299M (HD) standard.
Embedding or de-embedding may be applied to any 8 of the
available 16 channels of embedded audio via flexible cross-
point matrix (FC972 Remote required). Certain settings are
done from on-board switches such as device ID.
21
Product Description
