Introduction

System Specifications

Mobile or Desktop CPU

The computer designs incorporate both mobile and desktop CPUs. To tell if you have a mobile or desktop CPU model,
look at the DC output rating on the bottom of the AC adapter:
AC Adapter
Warning
• Mobile:
• Desktop: DC-Output 20V, 4.5A, 90w
The AC adapter rated
at 90w (for desktop

Processor

CPU) will power a mo-
bile CPU. However,
the AC adapter rated
Desktop Model
at 65w (for mobile
• Intel Pentium 4 Processor - (478-pin) FC-PGA2 package
CPU) will NOT power a
(
desktop CPU.
• Intel Celeron Processor - (478-pin) FC-PGA2 package
(
Mobile Model
• Mobile Intel Pentium 4 Processor - (478-pin) Micro-FCPGA package
(
• Mobile Intel Celeron Processor - (478-pin) Micro-FCPGA package
(µ0.13) 0.13 Micron Process Technology, 256KB L2 Cache & 400MHz FSB - 1.4~2.0 GHz
(You can also check the heat sink type as pictured in
entiate between the desktop and mobile CPU models.)

Core Logic

• SIS650

Structure

• Fully PC99 Compliant
• ACPI 1.0B Compliant
• PC2001 Compliant
1 - 2 System Specifications
DC-Output 20V, 3.25A, 65w
µ
0.13) 0.13 Micron Process Technology, 512KB L2 Cache & 400MHz FSB - 1.8/2.0 GHz
µ
0.13) 0.13 Micron Process Technology, 256KB L2 Cache & 400MHz FSB - 2.0 GHz
µ
0.13) 0.13 Micron Process Technology, 512KB L2 Cache & 400MHz FSB - 1.4~2.2 GHz
Figure 6 - 1b of "Removing the Hard Disk" on page 6 - 4 to differ-
