System Specifications - EUROCOM M375E Service Manual

Introduction

System Specifications

Processor Types
Core Logic
Security
Memory
BIOS
LCD
Display
Video Memory
The system allocates
or "shares" a portion of
system memory for
Storage
video use. "Shared"
memory is user-config-
urable via the SCU.
The default setting is
Audio
set to 8MB.
1 - 2 System Specifications
All manuals and user guides at all-guides.com
Feature
Intel® Pentium® M Processor (478-pin) Micro-
µ
( )FCPGA Package
Intel 855PM + ICH4-M
Security (Kensington® Type) Lock Slot
Two 200 Pin DDR SODIMM Sockets
Supporting DDR 266/333 MHz Modules
One 512KB Flash ROM
15.4" WXGA TFT LCD (16:9 Wide Screen Aspect Ratio)
ATI Mobility Radeon 9600 (M10) High Perfomance Chip
Integrated 128-bit 2D/3D Graphics Accelerator
Advanced HW Acceleration for DVD Playback
Fully DirectX® 9 Support
Ultra AGP™ 4x
Up to 128MB DDR SGRAM On Board (Default 64MB - Upgrade 128MB)
Dual-View Display Monitor
External Display Resolution up to 1600 * 1200 UXGA
One Changeable Optical Device (CD-ROM/ DVD-ROM/ CD-RW/ DVD-RW Combo/ DVD-Dual etc.)
One Changeable Primary 2.5" 9.5mm (h) Hard Disk Drive
Support LBA Mode, Master Mode IDE, PIO Mode 4 / ATA-33/66/100
AC'97 2.2 Compliant Device
Advanced Wavetable Synthesizer
DirectSound™ 3D Accelerator
Full-Duplex
Specification
µ
( 0.13) 0.13 Micron Process Technology,
1MB On-die L2 Cache & 400MHz Front Side Bus
- 1.3/ 1.4/ 1.5/ 1.6/ 1.7 GH
µ
( 0.09) 0.09 Micron Process Technology,
2MB On-Die L2 Cache & 400MHz Front Side Bus
- 1.5A/ 1.6A/ 1.7A/ 1.8 / 2.0 GHz
BIOS Password
Supporting 128/256/512/1024 MB DDR RAM Modules
Expandable up to 2GB
Insyde BIOS
S/PDIF Digital Output (5.1 CH)
Built-In Microphone
Built-In 4 Speakers (25 * 15mm)
