Introduction

System Specifications

Processor
Intel® Core i7-720QM Processor:
1.6GHz
45nm (45 Nanometer) Process Technology,
6M L3 Cache &
FSB 1333MHz - TDP 45W
rPGA988A Package
Intel® Core i7-820QM Processor:
1.73GHz
45nm (45 Nanometer) Process Technology,
8M L3 Cache &
FSB 1333MHz - TDP 45W
rPGA988A Package
Intel® Core i7-920XM Processor:
2.00GHz
45nm (45 Nanometer) Process Technology,
8M L3 Cache & FSB 1333MHz - TDP 55W
rPGA988A Package
Core Logic
Intel® PM55 Chipset
Display
18.4" HD+/ FHD (1920 * 1080) TFT LCD
Memory
DDRIII (DDR3) Dual Channels
Two 204 Pin SO-DIMM Sockets Supporting
DDRIII (DDR3) 1066MHz/1333MHz Memory
Modules
Memory Expandable up to 8GB
Compatible with 2GB or 4GB Modules
1 - 2 System Specifications
Video Adapter Options
nVIDIA® GeForce GTX 280M SLI PCIe
Video Card
1GB GDDR3 Video RAM On Board
Supports PCIe * 8 (SLI - 2 * PCIe * 8)
Supports Microsoft DirectX ® 10.0
Supports HDCP
nVIDIA® GeForce GTX 285M SLI PCIe
Video Card
1GB GDDR3 Video RAM On Board
Supports PCIe * 8 (SLI - 2 * PCIe * 8)
®
Supports Microsoft DirectX 11.0
Supports HDCP
BIOS
One 32Mb Flash ROM
Phoenix™ BIOS
Storage
Up to three (Factory Option) Changeable
2.5" 9.5 mm (h) SATA (Serial) Hard Disk
Drives supporting RAID level 0/1
One 12.7 mm Super Multi/Blu-Ray Combo/
Blu-Ray Writer SATA Optical Device Drive
(Factory Option)
Audio
High Definition Audio
3D Enhanced Sound System
S/PDIF Digital Output
Built-In Microphone
5.1 Channel Speakers (with Subwoofer)
Dolby Home Theater Certified
Keyboard & Pointing Device
Full Size Winkey Keyboard with Numeric
Keypad
Built-In TouchPad (with Multi Gesture
Functionality)
Eight Touch Sensor Instant Keys (Color,
CCD, Bluetooth, WLAN, Internet, Silent
Mode, Sound Effect, Mute)
Eight Gaming Keys G1 ~ G8
Card Reader
Embedded 7-in-1 Card Reader (MS/ MS Pro/
SD/ Mini SD/ MMC/ RS MMC/ MS Duo)
Note: MS Duo/ Mini SD/ RS MMC Cards
require a PC adapter
Slots
One ExpressCard/34 Slot
Two Mini Card Slots:
Slot 1 for PCIe WLAN Module
Slot 2 for PCIe TV Tuner Module
