Introduction

System Specifications

Processor Types

• Intel Pentium® 4 Processor (478-pin) m-PGA package
µ
( 0.13) 0.13 Micron Process Technology,
512KB On-die L2 Cache & 533MHz Front Side Bus - 2.8/
3.06 GHz
• Intel Pentium® 4 Processor (478-pin) m-PGA package
µ
( 0.13) 0.13 Micron Process Technology,
512KB On-die L2 Cache & 800MHz Front Side Bus - 2.4/
2.6/ 2.8/ 3.0/ 3.2 GHz
• Intel Prescott® Processor (478-pin) m-PGA package
µ
( 0.09) 0.09 Micron Process Technology,
1MB On-die L2 Cache & 800MHz Front Side Bus - 3.2/
3.4 GHz

Core Logic

• Intel® 865PE + ICH5

Structure

• PC 2001 Compliant
• PCI 2.2 Compliant
• ACPI 2.0 Compliant

Security

• Security (Kensington® Type) Lock Slot
• BIOS Password
1 - 2 System Specifications

Memory

• Two 200 Pin SODIMM Sockets, Supporting DDR 266/
333/ 400 MHz Modules
• Expandable up to 1024 MB (128/256/512MB DDR Mod-
ules)

BIOS

• One 512KB Flash ROM
• Phoenix BIOS

LCD (Options)

• 15.0" - XGA 1024x768
• 15.0" - SXGA+ 1400x1050
• 15.0" - UXGA 1600x1200
• 15.0" - QXGA 2048x1536

Display

• ATI M10
• AGP™ 8X Mode
• 128-bit Memory Interface
• 2D/3D Graphics Engine
• Fully DirectX 9 Compliant Notebook GPU
• External Memory up to 128MB DDR SGRAM On Board
• TV Encoder
