NI-1 BRI Provisioning
Series Completion Feature Translations
The sample screens shown below illustrate the translations for alternate voice
and data hunting on one main DSL and three DNs forming a linear series
completion group. Voice hunting is provided using Series Completion (Field 87,
SERHLN). Data hunting is provided with Call Forward Data Busy Line
(/CFDBLAC).
The 5ESS limits the number of members of a series completion group to 16
DNs, and the number of lines forwarded using /CFDBLAC to the value specified
on Screen 9, Field 176 (SIMINTRA). This value is currently set to 99 series
completion groups, but can be changed.
5ESS SWITCH LABNSC1
SCREEN 1 OF 14
(*)1. DSL TN C 2228700
(*)4. MLHG ____
(*)5. TERM ____
(*)6. DSL OE _ ________
(*)9. ASSOC U
5ESS SWITCH LABNSC1
SCREEN 2 OF 14
>11. OE I 00101209
14. D ISCN 007096
15. D SERV SX
16. B1 SERV DMD
17. B2 SERV DMD
18. NT1 TYPE AULC
19. PM GRP PMDEF
20. DSL CLS STD
21. RSTR MP N
22. ACSR INH Y
23. MDPKT 8
24. MTERM 2
RECENT CHANGE
DSL/BRCS ASSIGNMENT
SERVICES AND FEATURES
------------------------
BRCS FEATURE LIST
BRCS FEATURE PARAMETERS
CKT
DELFEAT LIST
DPKT
DSL INFO
ODB
PPB1
PPB2
USER INFO
RECENT CHANGE
DSL/BRCS ASSIGNMENT (DSL INFO)
25. CUT DGTS
26. ACSR GRP ___________
27. DFLT SRV __________
23.8
SCREENS
-------
6
7 to 9
4 & 5
14
10
2
11
12
13
3
23.8
2228
