NI-1 BRI Provisioning
AT&T 5ESS Switch Translations
For the AT&T 5ESS switch, Capability Package "S" includes alternate
voice/circuit-switched data on two B-channels. It also supports Calling Number
Identification on data and voice connections. Please note that in order to have
simultaneous calls on the two B-channels, two Directory Numbers (DNs) must
be assigned with this package.
The AT&T 5ESS switch also allows alternate voice and data hunting on one DN
using the Series Completion feature.
ISDN Capability Package "S"
The information listed below provides the DN translations that define Capability
Package "S", and the screens and fields that must be programmed.
The information provided shows the translations for one Digital Subscriber Line
(DSL) and two DNs. For multiple DSLs/DNs, duplicate these screens and enter
the applicable DSL and DN values as needed.
ISDN Ordering Code: Capability S
VIEW 23.2
DN1 Translations
Fields that must be programmed on Screens 1, 2, 3 and 4:
1.
9.
11.
14.
15.
16.
17.
18.
20.
21.
22.
23.
42.
43.
44.
H–2
System Planning
DSL TN <C plus Telephone number>
ASSOC <U>
OE <enter OE and type>
D ISCN < enter value >
DSERV <SX>
B1SERV <DMD>
B2SERV <DMD>
< enter NT1 type >
NT1 TYPE
DSL CLS <STD>
RSTR MP <N>
MDPKT <0>
MTERM <2>
< enter value >
USPID
MAXBCHL <2>
ACT USER <Y>
