Group-Assigned Features
Planning Form Instructions
NOTE:
If the system has AUDIX Voice Power/Fax Attendant, you do not need to fill in
this information; settings are automatically set by Integrated Administration to
factory settings assumed by the AUDIX Voice Power system (and not
necessarily those listed for the communications system on Form 7d). Changing
the assumed factory settings could affect how the AUDIX Voice Power system
works. If you change these values, do so with caution , and record the settings
on Form 7d. For more information, see the AUDIX Voice Power documentation.
For each calling group:
1. On Form 7d (page 2), copy the Group No., ID, and extension number
from the front of the form.
2. Select the Hunt Type by doing one of the following:
To keep the factory-set hunting pattern, check the Circular box.
NOTE:
If you choose a linear hunt, be sure you have listed the extension
numbers and names in the Extensions section on Form 7d (page 1), in
the order that you want the group searched. If you have not done this,
go back and correct the front of the form so that the extensions are in
the right order.
To change the factory-set hunting pattern, check the Linear box.
3. Under the Delay Announcement heading, do one of the following:
If there is no announcement device, check the No box and proceed to
Step 4.
To designate an announcement device, check the second box and
write the extension number for the device in the space provided (see
Form 2a or 2b).
4. To designate a telephone to receive message-waiting indications for the
group, do one of the following under the Message-Waiting Receiver
heading on Form 7d (page 2):
To assign no receiver, check the No box.
To assign a receiver, check the second box and write the extension
number of the message-waiting receiver (see Form 2a).
5. Under the Calls-in-Queue Alarm Threshold heading, do one of the
following:
To keep the factory setting, check the 1 Call box.
To change the factory-set number of calls allowed in the queue before
members are notified, check the second box and write the number of
calls (up to 99) in the space provided.
