NI-1 BRI Provisioning
AT&T 5ESS Switch Translations
For the AT&T 5ESS switch, Capability Package "S" (2B) includes alternate
voice/circuit-switched data on two B-channels. Data and voice capabilities
include Calling Number Identification. Please note that in order to have
simultaneous calls on the two B-channels, two DNs must be assigned with
this package.
The AT&T 5ESS switch also provides for alternate voice and data hunting
on one DN via the Series Completion feature.
ISDN Capability Package "S"
The information listed below provides the DN translations that define
Capability Package "S", and the screens and fields that must be
populated.
The information provided shows the translations for one DSL and two DNs.
For multiple DSLs/DNs, the CO will duplicate these screens and enter the
applicable DSL and DN values as needed.
ISDN Ordering Code: Capability S
VIEW 23.2
DN1 Translations
Fields that must be populated on Screens 1, 2, 3 and 4:
1. DSL TN <C plus Telephone number>
9. ASSOC <U>
11. OE <enter OE and type>
14. D ISCN < enter value >
15. DSERV <SX>
16. B1SERV <DMD>
17. B2SERV <DMD>
