92 C 2: I
HAPTER NSTALLING
Table 13 Auto Discover Actions on NBX System Components
Component
NBX Analog Line Card
NBX Digital Line Card
Telephones
Analog Terminal Cards
Analog Terminal Adapters
3Com Attendant Console
pcXset
Soft Telephone
ConneXtions H.323 Gateway Configures line card port settings when the following conditions are true:
S H C
YSTEM ARDWARE OMPONENTS
Table 13 summarizes Auto Discover actions for NBX system components.
Auto Discover Action
Gathers configuration information from each port on the card, assigns a default
extension, and enters the information into the configuration database.
Gathers configuration information from the card, assigns a default extension, and
enters the information into the configuration database.
After you Auto Discover the Digital Line Card, you may need to edit the Dial Plan to
configure Direct Inward Dial (DID) numbers.
Gathers configuration information from the telephone, assigns a default User Profile
labeled "new user," assigns the next lowest available extension number to the
profile, and enters the information into the configuration database.
Auto Discover Telephones also finds both Analog Terminal Cards and Analog
Terminal Adapters.
By default, the Auto Discover process assigns extension number 100 (3-digit Dial
Plan) or 1000 (4-digit Dial Plan) as the first telephone extension. You can use the NBX
NetSet utility to specify a new extension starting number. To simplify Auto Attendant
configuration, you should start a range at a base number, for example, 100/1000,
200/2000, 300/3000, or 400/4000. The default Auto Attendant assumes that
extension 100 (3-digit dial plan) or 1000 (4-digit dial plan) is the extension of a
human attendant (receptionist).
Finds and configures any installed 3Com Attendant Consoles. The first 100 existing
telephones, except for the extension that is associated with the Attendant Console,
are mapped to Attendant Console buttons. The lowest extension is automatically
associated with the Attendant Console. Typically, you would wait until you have
installed all your telephones before you enable Auto Discover Attendant Consoles.
Enables the Auto Discover feature on installations of the pcXset PC Telephone Client
when the following conditions are true:
The pcXset PC Soft Telephone program is running.
■
The pcXset PC Soft Telephone host computer is connected to the network.
■
You have entered the proper license key into the NBX NetSet utility.
■
The ConneXtions H.323 Gateway program is running.
■
The ConneXtions H.323 Gateway host computer is connected to the network.
■
You have entered the proper license key into the NBX NetSet utility.
■
