108 C 3: T
HAPTER ELEPHONES AND
A C
TTENDANT ONSOLES
Figure 34 Connections for 3Com 3102 Business Telephones
1
1 Power cable. Ask your Administrator how you should power your phone.
Then see Table 19
power. (Figure 36
2 Ethernet cable (to data jack)
3 Ethernet cable (optional; to connect a computer or an Attendant Console to
the network)
4 Handset cord (to handset)
5 Headset connection (to connect an optional headset)
Figure 35 Connections for 3Com 1102 Business Telephones
1
1 Ethernet cable (optional; to connect a computer or an Attendant Console to
the network)
2 Strain-relief tab to prevent power cord from becoming disconnected
3 Power cable. Ask your Administrator how you should power your phone.
Then see Table 19
power. (Figure 36
4 Handset cord (to handset)
5 Ethernet cable (to data jack)
5
for instructions on how to connect your telephone to
shows a connection using an optional AC adapter.)
5
for instructions on how to connect your telephone to
shows a connection using an AC adapter.)
2
3
4
2
3
4
