58 C 2: I
HAPTER NSTALLING
How Many
Telephones or
Devices Does the NBX
System Support?
What Effect Does an
NBX System Have on
a LAN?
S H C
YSTEM ARDWARE OMPONENTS
The NBX 100 system accommodates 200 devices. The SuperStack 3 NBX
system can support 1500 devices.
The following items are defined as devices in the NBX system:
Each 3Com telephone
■
Each Single-port Analog Terminal Adapter (ATA)
■
Each port on an Analog Terminal Card
■
Each Attendant Console
■
Each T1 or E1 channel
■
Each B channel (if you are using ISDN BRI)
■
Each Line Card port
■
Each instance (installation) of the pcXset
■
Each ConneXtions H.323 port
■
Examples:
With 300 3Com telephones, a SuperStack 3 NBX system can
■
accommodate up to 1200 additional devices, in any combination of
card ports, Attendant Console, T1 channels, and so on.
With 124 telephones, an NBX 100 system can have no more than 76
■
additional devices.
For detailed information on device limits, see
Guidelines" on page
A 10 Mbps Ethernet LAN can support a fully configured, fully utilized
NBX 100 system. A 100 Mbps Ethernet LAN can support a fully
configured, fully utilized NBX SuperStack 3 system. That is, a 10 Mbps
Ethernet LAN with 200 "voice devices" (3Com telephones and outside
telephone lines) can support the toll-quality audio provided by the
NBX 100 system even when all 200 devices are in use. Similarly, a
100 Mpbs LAN can support toll-quality audio with a fully configured
SuperStack 3 NBX system. If you use an Ethernet switch, verify that it
supports the 802.1P and 802.1Q specifications.
47.
™ Soft Telephone application
"System Configuration
