3Com 3C10111C - NBX 100 - Modular Exp Base Installation Manual page 111

Adding a New Telephone Using the Auto Discover Feature
Before you enable the Auto Discover feature, be sure that you have the
dial plan you want installed. The NBX 100 ships with a default 3-digit dial
plan starting at extension 100. The SuperStack3 NBX ships with a default
4-digit dial plan starting at extension 1000. Your extension range is one
factor you must consider when setting up Virtual Tie Lines for multi-site
telephone connectivity.
If you are adding licensed devices, such as the 3102, 3101, 3101SP, or
3105, you must first add the license key into the NBX NetSet utility. The
Auto Discover process will not discover a licensed device if the license has
not been added to the system.
To Auto Discover a telephone:
1 In NBX NetSet - Main Menu window,
Configuration. The System Configuration window appears.
Figure 39 NBX NetSet - Main Menu Window
2 Click the System-wide button. The System-wide dialog box
appears.
Adding Telephones
(Figure 39), click System
111
(Figure 40)
