Table of Maximum
Device Counts
Table 5 Supported Features on the SuperStack 3 NBX and NBX 100 Call Processors
System Device Capacity
3Com Business Telephone
3Com Basic Telephone
3Com Attendant Console
pcXset Soft Telephone
NBX Media Driver (for WAV
devices)
Polycom IP 3000 Speaker Phone
CITELlink Handset Gateway card
NBX Analog Terminal Card (ATC) 4 per card
You want to configure 200 Attendant Consoles, but, because the
■
individual device limit for Attendant Consoles is 100, you can
configure only 100 of them.
The total device count is now 622. You can configure 128 additional
devices (750–622).
You want to add Virtual Tie Lines (VTLs), but you can add only 48
■
because that is the maximum license level available for VTLs.
Because VTLs do not count toward the device limit, the total device
count remains at 622. So, after you add 48 VTLs, you can still
configure up to 128 additional devices.
Table 5 lists each NBX device and application, with information on
whether it counts toward the total device count and the maximum
number allowed per NBX system.
For the current device and license configuration on your system, see
NBX NetSet > Operations > Licenses as well as the Usage Report
accessible from the Licenses screen. See the 3Com Price List or your
3Com NBX Voice-Authorized Partner for details on incremental licences.
Per-Unit Device Count
Toward Total System
Count
1
1
1
1 per pcXset PC telephone
client
1 driver per system enables
the maximum allowable
number of WAV devices
1
16 per card
CAUTION: SuperStack 3 NBX: If you are using the 3Com SuperStack II ARPS
(Advanced Redundant Power Supply) as a backup power supply for the NBX
Gateway Chassis, you are limited to two ATC cards of version 3C10117 or
3C10117B per NBX Gateway Chassis. (3C10117C is not restricted in this way.)
System Configuration Guidelines
Maximum Number
Per SuperStack 3
System
1500
1500
100
1500
1500
93 cards (1488 ports)
1500
375 cards (1500 ports)
49
Maximum. Number
Per NBX 100 System
200
200
50
200
200
12 cards (192 channels)
200
50 cards (200 ports)
