3C10114C - 3Com 3C10111C - NBX 100 - Modular Exp Base Installation Manual

3C10114C

Table 32
Table 32 3C10114C NBX Analog Line Card Specifications
Weight
Government
approvals
Facility Interface
Code
Service Organization
Code
Connectors
USOC Jack
REN
Environmental
contains the 3C10114C Analog Line Card specifications.
510 gm (18 oz)
FCC Part 68
FCC registration numbers:
SSAUSA-25639-PF-TQ
Fully Protected PBX
SSAUSA-25639-MF-T
Fully Protected Multifunction Systems
SSAUSA-25639-KF-T
Fully Protected Key Telephone System
FCC Part 15 Class A
CE: This product complies with the requirements of
European Directive 1995/5/EC
Emissions
IECS-003 Class A
FCC Part 15 Class A
EN 55022 Class A
AS/NZS 3548 Class A
EN61000-3-2
EN61000-3-3
CNS 13438 Class A
02LS2
9.0 F
Connects up to four Loop Start PSTN telephone lines via
four RJ-11C ports
Serial port (CONSOLE) for diagnostic access
RJ-11C
0.2 A
Ambient temperature: 0 °C to 40 °C
(32 °F to 104 °F)
Humidity: 10% to 90% noncondensing
NBX Analog Line Cards 177
