200 I
NDEX
battery
replacing on the SuperStack 3 Call
Processor 170
BOOTP 82
brackets
NBX 100 chassis 73
NBX Gateway Chassis 75
SuperStack 3 Call Processor 75
bridged extensions
overview 164
BRI-ST Digital Line Card
description of 37
inserting (caution) 136
installing BRI-ST lines 55
specifications 179
status lights (LEDs) 37
bug fixes 196
Business Telephone
connecting telephone lines (caution) 56
description of 42
C
cables, bare wire-end 37
CALL
E1 status light 36
T1 status light 33
call center operations 97
Call Processor
installing (SuperStack 3 NBX) 74
IP address 159
NBX 100 27
providing IP address to devices 154
status lights (LEDs)
NBX 100 27, 74
SuperStack 3 NBX 23, 77
SuperStack 3 NBX 22
CARD
T1 status light 33
chassis
brackets
NBX 100 73
NBX Gateway Chassis 75
SuperStack 3 Call Processor 75
number of, in NBX 100 system 26
number of, in SuperStack 3 NBX system 24
removing cover from NBX 100 70
specifications 174
wall-mount dimensions for NBX 100 73
CO
E1 status light 35
T1 status light 32
Computer Telephony Integration (CTI) 27, 56
conference call multicast addresses 101
configuring a line card port 96
configuring IP
for subnetworks 153
IP On-the-Fly 154, 156
standard 153
configuring network devices
Attendant Console 153
Call Processor 153
NBX telephones 153
connecting
a computer to the telephone 110
power adapter to a telephone 87, 105
power adapter to an attendant console 114
telephone to the LAN 107
Connection Assistant 195
ConneXtions
and Auto Discover 91
configuration guidelines 161
maximum number of ports 50
cooling, environmental prerequisites 53
cordless telephones 38, 123
CTI (Computer Telephony Integration) 17, 22, 27,
56
D
DCH
E1 status light 35
T1 status light 32
DDI (Direct Dialing Inward) services
dial plan configuration (BRI) 134
dial plan configuration (E1) 140
DHCP (Dynamic Host Configuration Protocol)
BOOTP 153, 155
configuring IP with 153
configuring network devices 153
multiple subnetworks 153
non-support by Call Processor 82
overview 153
dial plan configuration file
DDI/MSN services for BRI 134
DDI/MSN services for E1 140
DID services for T1 146
translator entries for BRI 134
translator entries for E1 140
translator entries for T1 146
DID (Direct Inward Dialing) services
dial plan configuration (T1) 146
Digital Line Cards, BRI-ST
specifications 179
status lights (LEDs) 37
Digital Line Cards, E1
