I
NDEX
Numbers
10BASE-T Hub and Uplink Card 38
3C10116D T1
assigning IP address 161
3C10165D E1
assigning IP address 161
3Com Ethernet Power Source
powering attendant console 115
powering non-PE phones 88, 107, 130
powering PE phones 88, 107, 130
3Com Knowledgebase tool 195
3Com Network Jack to NBX Phone Power
Module 88, 106
3Com Professional Services 196
3Com resources, directory 197
802.3af 57
adapter for non-PE phones 88, 106
powering an attendant console 115
powering non-PE phones 88, 106
powering PE telephones 88, 106, 130
A
Access buttons 42
ACT
E1 status light 36
T1 status light 33
adding
Analog Line Card 84
Analog Terminal Card 85
Attendant Console 113
BRI-ST Digital Line Card 134
E1 Digital Line Card 140
T1 Digital Line Card 146
telephones 103
always open
ISDN connection 162
analog devices
Analog Line Card 84
Analog Terminal Adapter (ATA) 40
Analog Terminal Card 38, 85
connecting 123
Analog Line Card
auto discovering 119
description of 29
specifications 176
status lights (LEDs) 29
Analog Terminal Adapter (ATA)
adding 128
specifications 178
Analog Terminal Card 38
adding 124
connecting analog devices 123
description of 38
specifications 178
status lights (LEDs) 39
anti-static grounding strap 69, 76
Attendant Console
adding 113
description of 45
specifications 183
attendant console
Auto Discover 115
connecting the power adapter 114
connecting to PoE 114
extension mapping 117
Auto Discover
Analog Line Cards 119
Analog Terminal Cards 93
attendant console 115
BRI-ST Digital Line Card 135
ConneXtions gateways 91
E1 Digital Line Card 141
enabling and disabling 95
pcXset Soft Telephones 91
T1 Digital Line Card 147
telephones 103
B
bandwidth
10 Mbps LAN 58
fax machine requirements 194
low-bandwidth devices 101
low-bandwidth NBX telephone operation 161
routing devices 101
telephone requirements 58
