4 Using the four 6-32 Phillips head screws provided, attach the disk drive to
5 Route the data cable through the rectangular opening in the chassis inner
6 Attach the other end of the data cable to J9 at the top of the chassis
7 Replace the cover on the chassis.
Mounting the
NBX 100 Chassis
the chassis, above the power supply, as shown in
wall.
Be sure to connect the disk drive data cable to J9 on the chassis
backplane, which is mounted on the back wall of the chassis. Do not
connect the cable to the Call Processor.
backplane circuit board. J9 is keyed to ensure proper alignment of the
connectors.
If you choose, you may mount the NBX 100 Call Processor chassis either
in an equipment rack or on the wall. Follow the instructions described in
"Mounting the NBX 100 Chassis"
To mount the Call Processor chassis in an equipment rack or on the wall,
you need:
Two mounting brackets (supplied with the Call Processor)
■
Four mounting screws (supplied with the Call Processor)
■
Phillips screwdriver
■
Drill and drill bit (wall-mount only)
■
Level (wall-mount only)
■
19-in. equipment rack (for rack mounting only)
■
Installing the NBX 100 Chassis
Figure
next.
71
25.
