82 C 2: I
HAPTER NSTALLING
Table 10 IP Addressing and the NBX System (continued)
Local IP Environment
Private IP network, with subnets You probably need to change the NBX system IP address to conform with the
Internet connectivity; addresses
provided by the Internet Service
Provider.
Internet connectivity; addresses
provided from address block
controlled by the client's
organization.
Configuring IP
Addresses for Your
LAN
Establishing LAN
Connections
S H C
YSTEM ARDWARE OMPONENTS
NBX System Configuration
existing address space. You must change the NBX system IP address
(192.168.1.190) if that address is already in use on the network.
You must change the NBX System subnet mask (255:255:255:0) if it does not
conform to the network subnet scheme.
You must change the NBX system default gateway from 0.0.0.0 to the IP address
of the default gateway for the subnet where you install the NBX system.
You must change the NBX system IP address, default gateway, and possibly the
subnet mask. Ask the ISP to provide a fixed IP address, subnet mask, and default
gateway.
You must have a fixed IP address because the Call Processor does not support
DHCP or BOOTP.
You must change the NBX system IP address, default gateway, and possibly the
subnet mask. Ask the local network administrator to provide a fixed IP address,
(the NBX 100 Call Processor does not support DHCP or BOOTP) a subnet mask,
and a default gateway.
You must now adjust the default IP addresses and provide the
IP addresses specific to your LAN.
1 Log in to the NBX NetSet utility using the administrator username and
password.
2 In the NBX NetSet - Main Menu window, click System Configuration.
3 On the System Settings tab, click System-wide.
4 Edit the IP settings to conform to your LAN.
5 Click Apply and review your changes.
6 Click OK to close the dialog box.
After you establish IP connectivity, you are ready to install the
LAN connections.
Establishing NBX 100 LAN Connections
Connect the NBX 100 Call Processor to your network using either the
BNC 10B2 connector (3C10110C only) or the 10BT UPLINK MDI-X port.
