176 A A: S
PPENDIX PECIFICATIONS
NBX Analog Line
Cards

3C10114

A optional analog line card is the system's interface to the telephone
company's CO lines. There are two models of the Analog Line Card:
Table 31 contains the 3C10114 Analog Line Card specifications.
Table 31 3C10114 NBX Analog Line Card Specifications
Weight 510 gm (18 oz)
Government FCC Part 68
approvals
FCC registration numbers:
SSAUSA-25639-PF-TQ
Fully protected PBX:
SSAUSA-25639-MF-T
Fully protected multifunction systems:
SSAUSA-25639-KF-T
Fully protected key telephone system:
FCC Part 15 Class A
REN: 0.2 A per line jack
Connectors Connects up to four Loop Start PSTN telephone lines via
four RJ-11 ports
Ambient temperature: 0 °C to 40 °C
Environmental
(32 °F to 104 °F)
Humidity: 5% to 85% noncondensing
