3 Select the multi-view block definition to which you want to attach notes or files.
4 Click the General tab.
5 To add a description to the multi-view block, enter the description under Description.
6 Click Notes.
7 On the Notes tab, add or edit a note, as applicable.
8 On the Reference Docs tab, attach, edit, or detach a reference file:
If you want to
attach a reference file
edit the description of a reference file
edit a reference file
detach a reference file
9 Click OK twice.

Adding Classifications to a Multi-View Block Definition

Use this procedure to specify classifications for any classification definition applied to a multi-view block definition.
For more information, see
1 Open a tool palette that has a multi-view block definition tool.
2 Right-click a multi-view block definition tool, and click Multi-View Block Definitions.
3 Select the definition that you want to change.
4 Click the Classifications tab.
By default, the classification for all classification definitions is Unspecified. If no classification definitions
are listed, none are applied to multi-view block definitions.
5 For each classification definition, select the classification you want to apply to the current multi-view block
definition.
6 Click OK.

Adding a Multi-View Block Definition to DesignCenter

Use this procedure to add a multi-view block to DesignCenter
and dropping them from DesignCenter to your drawing. To add a multi-view block definition to DesignCenter, you
need to create a DWG file using the AEC Content Wizard.
For a detailed description of the AEC Content Wizard, see
1 On the Format menu, click AEC Content Wizard.
2 Select Multi-View Block.
3 Under Current Drawing, select a multi-view block definition, and click Add to add it to the Content File
list.
4 Click Next.
5 Select the layer key to use when the multi-view block is inserted, and specify any additional properties:
If you want to
explode the multi-view block when it is inserted in a drawing
specify an elevation for the multi-view block
associate an anchor with the multi-view block
1562 | Chapter 35 Multi-View Blocks
Classification Definitions" on page 2096.
Then
click Add, select a file, and click OK.
select the file, and click Edit. Edit the description, and click
OK.
double-click the reference file name to start its application.
Click OK when you are done editing.
select the file name, click Delete, and click OK.
™
. You can then create new multi-view blocks by dragging
Overview of AEC Content" on page 2116.
Then
select Explode on Insert.
enter a value for Preset Elevation.
select an anchor type.
