Plane. Press to cycle among modes until you are in the desired mode. The default edit mode is along the XY plane.
CTRL
In Plan view, the Location grip is restricted to movement in one plane.
You can also change the location of a multi-view block using the Properties palette.
1 Select the multi-view block you want to relocate.
2 Select the Location grip.
3 Move the multi-view block to the desired location and click once, or enter a value and press
If you want to enter a specific value for the second direction in any edit mode (for example, in the Y
direction when editing along the XY plane), press
You can also lock the movement of the multi-view block along a specific direction. If you enter a value for
either dimension direction in the current edit mode, and then press
block is constrained to the second dimension direction. When editing along the XY plane, for example,
you can enter a value for X dimension, and then press
movement of the multi-view block is constrained to the Y dimension direction.
4 Right-click, and click Deselect All to turn off grips.

Attaching Hyperlinks, Notes, or Files to a Multi-View Block

Use this procedure to attach hyperlinks, enter notes, or attach reference files to a multi-view block in a drawing. You
can also edit notes and edit or detach reference files from a multi-view block.
1 Double-click the multi-view block to which you want to attach information.
2 On the Properties palette, click the Extended Data tab.
3 To add a hyperlink, click the setting for Hyperlink, and specify the link.
For more information about adding hyperlinks, see Add Hyperlinks to a Drawing" in AutoCAD Help.
4 To add or edit a note, click
1568 | Chapter 35 Multi-View Blocks
to cycle to the second direction.
TAB
TAB
next to Notes, enter text, and click OK.
, the movement of the multi-view
TAB
. The X dimension is locked at that value, and
.
ENTER
