Drawings

®
An AutoCAD drawing becomes AutoCAD
compatible as soon as you select a AutoCAD Electrical
command to modify your drawing. An invisible block,
WD_M, is automatically inserted right on your drawing.
This block contains a number of attributes that define
many AutoCAD Electrical settings.
In This Chapter
® ■
Electrical
■
■
■
■
3
Working with templates
Inserting ladders
Inserting 3-phase wiring
Adding the current drawing to a
project
Adding drawing descriptions
25
