Table 15. Internal SCA-2 HDD Connector (continued)
Pin Signal
15 -MSG
16 -RST
17 -ACK
18 -BSY
19 -ATN
20 -DB(P)
21 -DB(7)
22 -DB(6)
23 -DB(5)
24 -DB(4)
25 -DB(3)
26 -DB(2)
27 -DB(1)
28 -DB(0)
29 -DB(P1)
30 -DB(15)
31 -DB(14)
32 -DB(13)
33 -DB(12)
34 5V
35 5V
36 5V Charge
37 Spindle Sync
38 MTRON
39 SCSI ID (0)
40 SCSI ID (2)
Technical Reference
Connector
Contact Pin Signal
(S) 55 +MSG
(S) 56 +RST
(S) 57 +ACK
(S) 58 +BSY
(S) 59 +ATN
(S) 60 +DB(P)
(S) 61 +DB(7)
(S) 62 +DB(6)
(S) 63 +DB(5)
(S) 64 +DB(4)
(S) 65 +DB(3)
(S) 66 +DB(2)
(S) 67 +DB(1)
(S) 68 +DB(0)
(S) 69 +DB(P1)
(S) 70 +DB(15)
(S) 71 +DB(14)
(S) 72 +DB(13)
(S) 73 +DB(12)
(S) 74 Mated 2
(S) 75 5 V Ground
(L) 76 5 V Ground
(L) 77 Active LED Out
(L) 78 DLYD_START
(L) 79 SCSI ID (1)
(L) 80 SCSI ID (3)
Connector
Contact
(S)
(S)
(S)
(S)
(S)
(S)
(S)
(S)
(S)
(S)
(S)
(S)
(S)
(S)
(S)
(S)
(S)
(S)
(S)
(S)
(L)
(L)
(L)
(L)
(L)
(L)
85
