SRKA4/ISP4400
Server System
Product Guide
Order Number: A07928-003

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SRKA4 - Server Platform - 0 MB RAM and is the answer not in the manual?

Questions and answers

Related Manuals for Intel SRKA4 - Server Platform - 0 MB RAM

Summary of Contents for Intel SRKA4 - Server Platform - 0 MB RAM

  • Page 1 SRKA4/ISP4400 Server System Product Guide Order Number: A07928-003...
  • Page 2 Disclaimer Intel Corporation (Intel) makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Intel assumes no responsibility for any errors that may appear in this document.

  • Page 3: Table Of Contents

    Contents Part I: User’s Guide ......................9 1 Chassis Description Chassis Features ....................... 13 Peripherals ........................ 14 Hard Drives........................ 15 Power Subsystem...................... 16 System Cooling......................17 Chassis Front Controls and Indicators ............... 18 Rear Panel I/O Ports and Features................19 2 Baseboard Description .....................
  • Page 4 Top Cover .......................... 51 Removing the Top Cover ................... 51 Installing the Top Cover ..................... 51 Memory Retention Bar ....................... 52 Removing the Memory Retention Bar ................ 52 Installing the Memory Retention Bar ................52 SKA4 Baseboard........................ 53 Removing the Baseboard ..................53 Installing the Baseboard ....................
  • Page 5 PCI Installation Tips....................76 Problems with Application Software................76 Bootable CD-ROM Is Not Detected ................77 Error and Informational Messages..................77 POST Codes and Countdown Codes................. 77 8 Technical Reference Cables and InterConnect Descriptions ................79 Internal Cables and Connectors................. 79 Connectors Accessible to the User ................
  • Page 6 Hard Drive Secured in Drive Carrier ................26 Front of Chassis with Bezel Door Closed..............27 Front Right Side of Chassis with Bezel Door Open............ 27 Disengaging Drive Carrier from Chassis..............28 PCI Hot-plug Retention Mechanism................29 Rear Retention Latch....................29 One of Two Thumbscrews Securing Top Cover ............
  • Page 7 CD-ROM Adapter Board 40 Position IDE Connector ..........87 CD-ROM Adapter Board Power Connector ............... 87 Audio Connector......................88 CD-ROM JAE Connector Pin-out................88 34-Position Floppy Connector Pin-out ............... 89 Floppy Adapter Board Power Connector ..............89 FFC Cable Pin-out ..................... 90 Environmental Specifications..................
  • Page 8 viii SRKA4/ISP4400 Server System Product Guide...

  • Page 9: Part I: User's Guide

    Part I: User’s Guide 1 Chassis Description 2 Baseboard Description 3 Configuration Software and Utilities 4 Removing and Installing User Serviceable Components...
  • Page 10 SRKA4/ISP4400 Server System Product Guide...

  • Page 11: Chassis Description

    1 Chassis Description The Intel SRKA4 MP Server System is designed to be mounted in a rack (rack mode). Figure 1 shows an example of this configuration. Before operation, you must purchase an adapter kit and configure the server so that it can be mounted on a rack.

  • Page 12: One Of Two Thumbscrews Securing Top Cover

    The chassis has two covers: a front cover and a top cover. The front cover is secured by screws and can only be removed by a qualified service technician. The top cover is secured by thumbscrews and provides user access to hot-pluggable PCI components. One of two thumbscrews is noted by "A"...

  • Page 13: Chassis Features

    Chassis Features Figure 3 and Figure 3a give an overhead view of the system with the top cover, front cover, and front bezel removed. OM09936 Figure 3. SRKA4 MP Server System Figure 3a. Overhead View of System Without Cover and Bezel Table 2.

  • Page 14: Peripherals

    This process is called hot-swapping. Hot-swapping fans can only be performed by a qualified service technician. E. Electronics Bay The E-Bay contains the Intel SKA4 baseboard. The baseboard has the following (E-Bay) major components: Up to four Intel Pentium III Xeon...

  • Page 15: Hard Drives

    Configurable Media Bay The configurable media bay supports either one of the following configurations: A .5-inch slim line floppy drive and ½-inch slim line CD-ROM drive A 3.5-inch floppy drive Only qualified service technicians should remove and install components in the configurable media bay.

  • Page 16: Power Subsystem

    NOTE All hard drives have different cooling, power, and vibration characteristics. Intel has validated specific hard drive types in the SRKA4 chassis. The SRKA4 Validation List contains a list of these manufacturers and hard drive types. The document can be found on http://support.intel.com/support/motherboards/server/SRKA4/compat.htm...

  • Page 17: System Cooling

    Operating the server with a non-redundant cooling system is not recommended for systems requiring high availability. To maintain SRKA4 MP Server System availability, Intel recommends the use of all six fans to form a redundant cooling system. If one of six fans ceases to function normally, the remaining five fans adequately cool the system.

  • Page 18: Chassis Front Controls And Indicators

    Chassis Front Controls and Indicators OM10262 Figure 6. Front Panel Controls and Indicators Power On/Off button: When activated by momentary contact while the system is off, this button turns the power subsystem on. If the system is in sleep state, activating the button by momentary contact brings the system out of sleep state.

  • Page 19: Rear Panel I/O Ports And Features

    Rear Panel I/O Ports and Features OM10263 Figure 7. Rear Panel I/O Ports and Features AC input power connector Two optional external SCSI connector ports The figure shows only one connector port, but your system has two C. Hot-plug 64-bit, 33 MHz PCI add-in board slots D.
  • Page 20 SRKA4/ISP4400 Server System Product Guide...

  • Page 21: Baseboard Description

    2 Baseboard Description The SRKA4 MP Server System contains the SKA4 baseboard. For more information about the SKA4 baseboard, see the SKA4 Baseboard Product Guide contained in your server software kit.
  • Page 22 SRKA4/ISP4400 Server System Product Guide...

  • Page 23: Configuration Software And Utilities

    3 Configuration Software and Utilities Configuration software and utilities are part of the SKA4 baseboard. For more information about configuration software and utilities, see the SKA4 Baseboard Product Guide contained in your server software kit.
  • Page 24 SRKA4/ISP4400 Server System Product Guide...

  • Page 25: Removing And Installing User Serviceable Components

    This server can withstand normal levels of environmental ESD while you are hot-swapping SCSI hard drives. However, Intel recommends doing all procedures in this manual only at an ESD-protected workstation. If one is not available, provide some ESD protection by wearing an antistatic wrist strap attached to chassis ground of the server—any unpainted metal surface—when handling...

  • Page 26: Scsi Hard Drives

    SCSI Hard Drives The system supports Adaptec Ultra 160/m SCSI SCA type or slower hard drives that are 3.5 inches wide. Contact a sales representative or dealer for a list of approved SCSI devices. Mounting a SCSI Hard Drive in a Carrier 1.

  • Page 27: Front Of Chassis With Bezel Door Closed

    1. Open the front bezel door by simultaneously pulling out on the raised lip of the front bezel door latch. In Figure 9, the door latch is noted by “A”; the tab used to secure the front bezel door is noted by “B”. OM09941 Figure 9.

  • Page 28: Installing A Scsi Hard Drive

    5. Grasp the locking handle and pull it toward you to disengage the drive connector from the backplane connector. The locking handle is noted by "A" in Figure 10. OM09942 Figure 10. Disengaging Drive Carrier from Chassis 6. Carefully slide the drive out of the bay. Place the drive on an antistatic surface. Installing a SCSI Hard Drive A bank of five LEDs on the front of the hard drive bays monitors the drive status of each drive in the hot-docking bay.

  • Page 29: Hot-Plug Pci Add-In Boards

    Hot-plug PCI Add-in Boards The SRKA4 MP Server System supports six hot-plug PCI add-in boards. From the back of the server system, the six slots are shown in "Rear Panel I/O Ports and Features" on page 19. Each hot-plug PCI add-in board is held in place by a PCI Hot-plug (PHP) Retention mechanism. OM09943 Figure 11.

  • Page 30: Removing A Hot-Plug Pci Add-In Board

    Removing a Hot-plug PCI Add-in Board WARNING If the system has been running, any installed PCI add-in board on the baseboard will be hot. To avoid the possibility of a burn, be careful when removing or installing baseboard components that are located near processors.

  • Page 31: Installing A Hot-Plug Pci Add-In Board

    12. Before replacing the top cover, check that no left loose tools or parts were left inside the system. 13. Position the cover over the chassis so that the rows of tabs align with slots in the chassis. Slide the cover toward the front of the system until the tabs on the cover firmly engage in the chassis.
  • Page 32 12. If you are installing a full-length board, lock the Rear Retention Latch. See Figure 12 on page 29. 13. Use the screw removed earlier to fasten the new board to the chassis. Tighten the screw firmly (6.0 inch-pounds). 14. Attach cables if necessary. 15.

  • Page 33: Part Ii: Service Technician's Guide

    Part II: Service Technician’s Guide 5 A Detailed Description of Chassis Features 6 Removing and Installing System Components 7 Solving Problems 8 Technical Reference A Equipment Log and Configuration Worksheets B Regulatory and Environmental Specifications C Warnings...
  • Page 34 SRKA4/ISP4400 Server System Product Guide...

  • Page 35: 5 A Detailed Description Of Chassis Features

    5 A Detailed Description of Chassis Features This chapter provides a detailed description of chassis features. For a general description, see Chapter 1 of this guide. The SRKA4 MP Server System is designed to be mounted in a rack (rack mode). Before operation, you must purchase an adapter kit and configure the server so that it can be mounted on a rack.

  • Page 36: Srka4 Mp Server System Without Covers And Bezel

    The top cover is held in place by two thumbscrews, each located at the top rear corner of the chassis. One of two thumbscrews is noted by "A" in Figure 15. OM09935 Figure 15. One of Two Thumbscrews Securing Top Cover A bezel snaps on to the front of the chassis and allows adequate airflow to cool the system components.
  • Page 37 Table 4. Chassis Feature Summary Feature Description A. Peripheral Bay A peripheral bay in the front of the system has a 5.25-inch device bay and a configurable media bay. A1. Peripheral Bay: The device bay can hold a 5.25-inch CD-ROM or DAT device. Device Bay A2.
  • Page 38 The processors, SDRAM memory modules, and hot-plug PCI components are listed individually below. E1. Processors The system supports up to four Intel Pentium III Xeon processors. E2. Registered The memory expansion board holds up to sixteen Dual Inline Memory Module...

  • Page 39: Peripherals

    Device Bay The device bay accommodates either a 5.25-inch CD-ROM or a DAT drive. Intel strongly recommends NOT installing any device, such as a hard drive, requiring airflow cooling in the device bay.

  • Page 40: Hard Drive Secured In Drive Carrier

    SCA drive is installed, make sure that the drive meets these backplane and carrier requirements. NOTE All hard drives have different cooling, power, and vibration characteristics. Intel has validated specific hard drive types in the SRKA4 chassis. The SRKA4 Validation List contains a list of these manufacturers and hard drive types.

  • Page 41: Power Subsystem

    Power Subsystem The SRKA4 MP Server System uses a universal input-switching power subsystem (PSBS). This subsystem provides up to 630 Watts DC. The subsystem also minimizes the RMS current drawn from each AC line by providing power factor corrected AC input. The chassis can be configured with one, two, or three 350-Watt power supply modules.
  • Page 42 Each power subsystem auto-senses within the following voltage ranges and is rated as follows: 100-120 V at 50/60 Hertz (Hz); 11.0 A maximum 200-240 V at 50/60 Hz; 5.5 A maximum The DC output voltages of each power supply module are: +3.3 V at 28 A max (Total combined power of the +3.3 and +5 channels must not exceed 195W) +5 V at 32 A max (Total combined power of the +3.3 and +5 channels must not exceed 195W)

  • Page 43: System Cooling

    Operating the server with a non-redundant cooling system is not recommended for systems requiring high availability. To maintain SRKA4 MP Server System availability, Intel recommends the use of all six fans to form a redundant cooling system. If one of six fans ceases to function normally, the remaining five fans adequately cool the system.

  • Page 44: Fan Leds Indicating A Fan's Status

    An LED above each cooling fan displays the status of that fan. The LEDs for two fans are noted by "A" in Figure 20. The LED on the left indicates the status of the fan pointed to by the left arrow.

  • Page 45: E-Bay

    Narrow SCSI device. Both connections are not a standard part of the SRKA4 MP Server System. For a Legacy Wide or Narrow device, Intel provides two cables that can be routed to the peripheral bay on the front of the system. To purchase the cable, contact a sales representative. The Legacy Narrow connector can be routed to the peripheral bay.

  • Page 46: Chassis Front Controls And Indicators

    Chassis Front Controls and Indicators OM10262 Figure 21. Front Panel Controls and Indicators Power On/Off button: When activated by momentary contact while the system is off, this button turns the power subsystem on. If the system is in sleep state, activating the button by momentary contact brings the system out of sleep state.

  • Page 47: Rear Panel I/O Ports And Features

    Rear Panel I/O Ports and Features OM10263 Figure 22. Rear Panel I/O Ports and Features AC input power connector Two optional external SCSI connector ports The figure shows only one connector port, but your system has two C. Hot-plug 64-bit, 33 MHz PCI add-in board slots D.
  • Page 48 SRKA4/ISP4400 Server System Product Guide...

  • Page 49: Removing And Installing System Components

    CAUTIONS Electrostatic discharge (ESD) and ESD protection: ESD can damage disk drives, boards, and other parts. Intel recommends that all procedures in this chapter are performed only at an ESD-protected workstation. If one is not available, provide some ESD protection by wearing an antistatic wrist strap attached to chassis ground any unpainted metal surface on your system when handling parts.

  • Page 50: Front Cover

    ESD and handling boards: Always handle boards carefully. They can be extremely sensitive to ESD. Hold boards only by their edges. After removing a board from its protective wrapper or from the system, place it component-side UP on a grounded, static-free surface. If you place the baseboard on a conductive surface, the battery leads may short out.

  • Page 51: Installing The Front Cover

    Installing the Front Cover 1. Observe the safety and ESD precautions at the beginning of this chapter. 2. Before replacing the front cover, check that no left loose tools or parts are left inside the system. 3. Check that cables and other components are properly installed. 4.

  • Page 52: Memory Retention Bar

    Memory Retention Bar When accessing SKA4 baseboard components, you need to remove and install the memory retention bar. Removing the Memory Retention Bar 1. Unscrew the captive screw located at the front of the E-Bay. The captive screw is noted by "A"...

  • Page 53: Ska4 Baseboard

    SKA4 Baseboard Removing and installing the SKA4 baseboard requires the removal and installation of baseboard components. Both procedures require this guide and the SKA4 Baseboard Product Guide. Before continuing, make sure that both product guides are readily available. When this guide directs you to a procedure in the either the SRKA4/ISP4400 Server System Product Guide or the SKA4 Baseboard Product Guide, read the procedure first.

  • Page 54: Power Supply Ac Bracket

    13. Remove the power supply AC bracket. a. Release the screw securing the connector. The screw is noted by "A". b. Slide the bracket up and towards the inside of the chassis. c. Drape the AC bracket over the left side of the E-Bay assembly. OM09950 Figure 24.

  • Page 55: Installing The Baseboard

    20. Remove the four screws on the top and bottom edges of the rear subchassis. These screws attach the E-Bay to the chassis. Two of the four screws are noted as "A" in Figure 25. OM09951 Figure 25. Screws Securing the E-Bay to the Chassis 21.

  • Page 56: Rear Retention Mechanism

    5. Using needlenose pliers, install the plastic rear retention mechanism located at the front of the E-Bay. The Rear Retention Mechanism is noted by "A" in Figure 26. OM09952 Figure 26. Rear Retention Mechanism 6. Place the rug at the bottom of the E-Bay. 7.

  • Page 57: Accessing Baseboard Components

    18. Install the memory board. See the SKA4 Baseboard Product Guide for instructions. 19. Install the memory retention bar. See "Installing the Memory Retention Bar" on page 52. 20. Install the fan board assembly. See "Installing a Fan Board Assembly" on page 63. 21.

  • Page 58: Power Subsystem

    AND unplug all AC power cords. Remove the power subsystem bay and send it back to an Intel customer service representative. Before sending the bay back, make sure all power supply modules are removed from the system.

  • Page 59: Removing A Power Supply Module

    This server can withstand normal levels of environmental ESD while hot-swapping SCSI hard drives. However, Intel recommends doing all procedures in this manual only at an ESD-protected workstation. If one is not available, provide some ESD protection by wearing an antistatic wrist strap attached to chassis ground of the server—any unpainted metal surface—when handling components.

  • Page 60: Installing A Power Supply Module

    4. Press down on the power supply module tab. Simultaneously and gently, pull the power supply handle towards you and remove it from the power subsystem bay. 5. If replacing the module with another one, see "Installing a Power Supply Module" on page 60. Otherwise, install a power supply module filler panel.

  • Page 61: Installing A Power Subsystem Bay

    Installing a Power Subsystem Bay WARNINGS System power on/off: The on/off button on the front panel DOES NOT turn off the system AC power. To remove power from system, unplug the AC power cords from the wall outlet or the system. Hazardous conditions, power supply: Hazardous voltage, current, and energy levels are present inside the power supply.

  • Page 62: Cooling System

    12. Securely fasten the power supply modules in the power subsystem bay. See "Installing a Power Supply Module" on page 60. 13. Install the top cover. See "Installing the Top Cover" on page 51. 14. Install the front cover. See "Installing the Front Cover" on page 51. Cooling System CAUTIONS Cooling and air flow: Once you remove the fan board assembly or...

  • Page 63: Installing A Fan Board Assembly

    OM09956 Figure 30. One of Two Screws Securing the Fan Board Assembly 7. Lift the fan board assembly directly upward and rest it on the E-Bay assembly. 8. Disconnect the cables from the assembly. There are three cables. One ribbon cable connects to the baseboard. One ribbon cable connects to the front panel.

  • Page 64: Replacing The Fan Board

    Replacing the Fan Board 1. Remove the fan board assembly. See "Removing a Fan Board Assembly" on page 62. 2. Remove the screws securing the base from the upper portion of the fan bay assembly. Keep them in a safe place. You need them later in the procedure. 3.

  • Page 65: Removing Individual Fans

    Removing Individual Fans Cooling and air flow: Once you remove an individual fan, make sure you replace it within two minutes. If you cannot replace it, insert the original unit. When you have the replacement unit, repeat the replacement procedure. Vacant spaces formerly occupied by fans alter air flow patterns in the server system and may cause environmental conditions to exceed the environmental limits of the server.

  • Page 66: Hard Drive Bay

    Hard Drive Bay Removing the Hard Drive Bay 1. Observe the safety and ESD precautions at the beginning of this chapter. 2. Remove the front cover. See "Removing the Front Cover" on page 50. 3. Remove the fan board assembly. See "Removing a Fan Board Assembly" on page 62. 4.

  • Page 67: Installing The Hard Drive Bay

    7. With a flat head screwdriver, pry the right side of the hard drive bay out of the chassis. OM09959 Figure 33. Removing the Hard Drive Bay From the Chassis 8. Install the fan board assembly. See "Installing a Fan Board Assembly" on page 63. 9.

  • Page 68: Peripheral Devices

    Peripheral Devices Removing a Drive from the Configurable Media Bay The configurable media bay holds either a 1.44 MB, 3.5-inch diskette drive OR both a .5-inch slim-line floppy and .5-inch slim-line CD-ROM drive. The drives are secured to the media bay by a screw.

  • Page 69: Replacing A Drive In The Device Bay

    All SCSI devices must not be terminated except the peripheral at the end of the SCSI cable. Hard drives usually provide an active termination, while CD-ROM drives do not. Because Intel recommends putting hard drives only in the internal bays, the SCSI cable should be routed so that the last device on the cable is a hard drive in the internal bay.
  • Page 70 SRKA4/ISP4400 Server System Product Guide...

  • Page 71: Solving Problems

    7 Solving Problems This chapter helps you identify and solve problems that might occur while you are using the system. Resetting the System To do this: Press: Clear system memory, restart POST, and reload the operating system. Reset button or <Ctrl+Alt+Del>...

  • Page 72: Running New Application Software

    Running New Application Software Problems that occur when you run new application software are usually related to the software. Faulty equipment is much less likely, especially if other software runs correctly. Application Software Checklist Does the system meet the minimum hardware requirements for the software? See the software documentation.

  • Page 73: Specific Problems And Corrective Actions

    Specific Problems and Corrective Actions This section provides possible solutions for these specific problems: Power light does not light. No beep or incorrect beep pattern. No characters appear on screen. Characters on the screen appear distorted or incorrect. System cooling fans do not rotate. Diskette drive activity light does not light.

  • Page 74: Characters Are Distorted Or Incorrect

    Are the video monitor switch settings correct? Is the video monitor signal cable properly installed? Is the onboard video controller enabled? If you are using an add-in video controller board, do the following: 1. Verify that the video controller board is fully seated in the baseboard connector (and verify that the video monitor is plugged in to the ACTIVE video controller).

  • Page 75: Diskette Drive Activity Light Does Not Light

    Diskette Drive Activity Light Does Not Light Check the following: Are the diskette drive power and signal cables properly installed? Are all relevant switches and jumpers on the diskette drive set correctly? Is the diskette drive properly configured? Is the diskette drive activity light always on? If so, the signal cable may be plugged in incorrectly.

  • Page 76: Network Problems

    Network Problems The server hangs when the drivers are loaded. Change the PCI interrupt settings. Try the “PCI Installation Tips” below. Diagnostics pass, but the connection fails. Make sure the network cable is securely attached. Make sure you specify the correct frame type in your NET.CFG file. The Link LED does not light.

  • Page 77: Bootable Cd-Rom Is Not Detected

    Verify that the baseboard jumpers are set correctly. See the SKA4 Baseboard Product Guide for more information. If other software runs correctly on the system, contact your vendor about the failing software. If the problem persists, contact the software vendor’s customer service representative for assistance.
  • Page 78 SRKA4/ISP4400 Server System Product Guide...

  • Page 79: Technical Reference

    Mouse device System Control SKA4 baseboard Fan Distribution 2x15 flat ribbon cable Board ® S/M Feature SKA4 baseboard Intel S/M card 2x13 flat ribbon cable Narrow SCSI SKA4 baseboard 5.25-inch device 2x25 flat ribbon cable Floppy SKA4 baseboard Floppy device...
  • Page 80 Table 7. SRKA4 Internal Connections (continued) Type From Interconnect Description ICMB external ICMB board External interface 1x6-pin ICMB cable SKA4 baseboard External interface 1x4-pin USB cables Internal USB SKA4 baseboard Internal interface 1x4-pin cable SKA4 baseboard Internal interface 1x3-pin cable Video SKA4 baseboard External interface...

  • Page 81: Connectors Accessible To The User

    Connectors Accessible to the User Keyboard and Mouse Ports These identical PS/2 compatible ports share a common housing. The top one is the mouse and the bottom one is the keyboard. Table 8. Keyboard and Mouse Connectors Mouse Keyboard Signal Signal MSEDAT (mouse data) KEYDAT (keyboard data)

  • Page 82: Parallel Port

    Parallel Port The IEEE 1284-compatible parallel port, used primarily for a printer, sends data in parallel format. The parallel port is accessed through a D-subminiature 25-pin connector. Table 10. Parallel Port Signal Signal STROBE_L AUFDXT_L (auto feed) Data bit 0 ERROR_L Data bit 1 INIT_L (initialize printer)

  • Page 83: Usb Connector

    Universal Serial Bus (USB) Interface The baseboard provides two stacked USB ports (Port 0 on top, Port 1 on bottom). The built-in USB ports permit the direct connection of two USB peripherals without an external hub. If more devices are required, an external hub can be connected to either of the built-in ports. Table 12.

  • Page 84: Ethernet Connector

    Ethernet Connector ® The system supports one Intel 82557 based on board Ethernet connection. Table 14. Ethernet Connector Signal NIC termination NIC termination NIC termination NIC termination Speed LED signal +3.3V standby (for LED) Activity LED signal +3.3V standby (for LED) Internal SCA-2 HDD Connector An SCA-2 connector is used on the primary side of the HDD backplane.
  • Page 85 Table 15. Internal SCA-2 HDD Connector (continued) Connector Connector Signal Contact Signal Contact -MSG +MSG -RST +RST -ACK +ACK -BSY +BSY -ATN +ATN -DB(P) +DB(P) -DB(7) +DB(7) -DB(6) +DB(6) -DB(5) +DB(5) -DB(4) +DB(4) -DB(3) +DB(3) -DB(2) +DB(2) -DB(1) +DB(1) -DB(0) +DB(0) -DB(P1) +DB(P1)

  • Page 86: External Adaptec Ultra 160/M Scsi

    External Adaptec Ultra 160/m SCSI As an option, the server system can support a shielded external SCSI connection. This connection is on Channel B of the Adaptec AIC-7899 SCSI Ultra 160 controller. Table 16. External Adaptec Ultra 160/m SCSI Signal Name Signal Name DP(12) DM(12)

  • Page 87: Peripheral Adapter Boards And Connectors

    AC Power Input A single IEC320-C13 receptacle is provided at the rear of the server. It is recommended to use an appropriately sized power cord and AC main. Peripheral Adapter Boards and Connectors The peripheral adapter boards convert the 50 pin JAE and FFC signal interface connectors of the ½-inch slim line peripherals to a standard 40 pin IDE and 34 pin floppy cable pin-outs.

  • Page 88: Audio Connector

    Table 19. Audio Connector Signal Audio Left Audio Right Table 20. CD-ROM JAE Connector Pin-out Signal Signal Audio L-Ch Audio R-Ch IORDY Audio GND /DMACK INTRQ RESET- /IOCS16 /PDIAG DD10 /CS1FX /CS3FX DD11 /DASP DD12 DD13 DD14 DD15 DMARQ CSEL /DIOR RESERV DIOW-...

  • Page 89: Position Floppy Connector Pin-Out

    Floppy Connectors Table 21. 34-Position Floppy Connector Pin-out Signal Signal Direction Select HD IN/ HD Out/ Open STEP Write Data Write Gate FD_INDEX_L Track 00 Drive Select 0 Write Protect Drive Select 1 Read Data Side One Select Motor On Disk Change/ Ready Table 22.

  • Page 90: Ffc Cable Pin-Out

    Table 23. FFC Cable Pin-out Signal Signal STEP INDEX WRITE DATA DRIVE SELECT WRITE GATE DISK CHANGE TRACK 00 READY HD OUT (HD AT HIGHT LEVEL) WRITE PROTECT MOTOR ON READ DATA DIRECT SELECT SIDE ONE SELECT SRKA4/ISP4400 Server System Product Guide...

  • Page 91: A Equipment Log And Configuration Worksheets

    A Equipment Log and Configuration Worksheets Equipment Log Use the blank equipment log provided here to record information about the system. Some of this information may be required when running the System Setup Utility (SSU). Manufacturer Name and Model Item Number Serial Number Date Installed...

  • Page 92: Configuration Worksheet

    Equipment Log (continued) Manufacturer Name and Model Item Number Serial Number Date Installed Configuration Worksheet The rest of this chapter consists of worksheets to record the settings you make when configuring the system using the SSU, BIOS Setup, and the Adaptec SCSI Utility. If default values ever need to be restored to CMOS (such as after a CMOS-clear), the system must be reconfigured.

  • Page 93: Current Usage

    The spreadsheet calculates total power use for a specific server configuration. The spreadsheet breaks down your system into many categories and automatically calculates power use on the "Summary" page. Categories include: Serverboard configuration ® Intel chassis Processors Memory SCSI Peripherals...
  • Page 94 An example of the summary page is displayed below. Power Budget SRKA4 Summary / Results +3.3V +12V -12V Total System Watts (amps) (amps) (amps) (amps) SRKA4 Margins as Configured 1PS (No redundancy) 0.70 -9.29 -6.35 0.48 -175.12 <-- Limits Exceeded! 3PS (2 + redundancy) 25.90 19.51...

  • Page 95: B Regulatory And Environmental Specifications

    2.0 g, 11 msec, 1/2 sine, 100 pulses in each direction Packaged Trapezoidal, 30 g, 170 inches/sec delta V, 3 drops in each direction on each of the three axes per Intel environmental test specifications Acoustic noise < 55 dBA with three power supplies at 28 °C +/- 2 °C...

  • Page 96: Product Regulatory Compliance Markings

    (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. For questions related to the EMC performance of this product, contact: Intel Corporation 5200 N.E. Elam Young Parkway Hillsboro, OR 97124...

  • Page 97: Fcc Verification Statement

    (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. For questions related to the EMC performance of this product, contact: Intel Corporation 5200 N.E. Elam Young Parkway Hillsboro, OR 97124-6497...

  • Page 98: Japan Emc Compatibility

    Japan EMC Compatibility Electromagnetic Compatibility Notices (International) English translation of the notice above: This is a Class A product based on the standard of the Voluntary Control Council For Interference (VCCI) from Information Technology Equipment. If this is used near a radio or television receiver in a domestic environment, it may cause radio interference.

  • Page 99: C Warnings

    C Warnings WARNING: English (US) AVERTISSEMENT : Français WARNUNG: Deutsch AVVERTENZE: Italiano ADVERTENCIAS: Español...

  • Page 100: Warning: English (Us)

    WARNING: English (US) The power supply in this product contains no user-serviceable parts. There may be more than one supply in this product. Refer servicing only to qualified personnel. Do not attempt to modify or use the supplied AC power cord if it is not the exact type required.
  • Page 101 WARNING: English (continued) A microprocessor and heat sink may be hot if the system has been running. Also, there may be sharp pins and edges on some board and chassis parts. Contact should be made with care. Consider wearing protective gloves. Danger of explosion if the battery is incorrectly replaced.

  • Page 102: Avertissement : Français

    AVERTISSEMENT : Français Le bloc d'alimentation de ce produit ne contient aucune pièce pouvant être réparée par l'utilisateur. Ce produit peut contenir plusieurs blocs d'alimentation. Veuillez contacter un technicien qualifié en cas de problème. Ne pas essayer d'utiliser ni de modifier le câble d'alimentation CA fourni, s'il ne correspond pas exactement au type requis.
  • Page 103 AVERTISSEMENT : Français (suite) Le microprocesseur et le dissipateur de chaleur peuvent être chauds si le système a été sous tension. Faites également attention aux broches aiguës des cartes et aux bords tranchants du capot. 'usage de gants de protection est conseillé. Danger d'explosion si la batterie n'est pas remontée correctement.

  • Page 104: Warnung: Deutsch

    WARNUNG: Deutsch Das Netzteil dieses Produkts enthält keine wartungsbedürftigen Teile. Dieses Produkt könnte mehr als ein Netzteil umfassen. Überlassen Sie die Wartungsarbeiten qualifiziertem Personal. Versuchen Sie nicht, das mitgelieferte Netzkabel zu verändern oder einzusetzen, wenn es nicht ganz genau dem benötigten Kabeltyp entspricht. Der Wechselstrom des Systems wird durch den Ein-/Ausschalter für Gleichstrom nicht ausgeschaltet.
  • Page 105 WARNUNG: Deutsch (Fortsetzung) Mikroprozessor und Kühlkörper können heiß sein, wenn das System längere Zeit eingeschaltet war. Außerdem können einige Platinen und Gehäuseteile scharfe Spitzen und Kanten aufweisen. Arbeiten an Platinen und Gehäuse sollten vorsichtig ausgeführt werden. Sie sollten Schutzhandschuhe tragen. Bei falschem Einsetzen einer neuen Batterie besteht Explosionsgefahr.

  • Page 106: Avvertenze: Italiano

    AVVERTENZE: Italiano Rivolgersi a un tecnico specializzato per la riparazione dei componenti dell’alimentazione di questo prodotto. È possibile che il prodotto disponga di più fonti di alimentazione. Non tentare di modificare o utilizzare cavi di alimentazione in c.a. che non siano del tipo prescritto.
  • Page 107 AVVERTENZA: Italiano (continua) Se il sistema è stato a lungo in funzione, il microprocessore e il dissipatore di calore potrebbero essere surriscaldati. Fare attenzione alla presenza di piedini appuntiti e parti taglienti sulle schede e sul telaio. Prestare attenzione durante l'esecuzione dei contatti. È consigliabile utilizzare guanti di protezione.

  • Page 108: Advertencias: Español

    ADVERTENCIAS: Español El usuario debe abstenerse de manipular los componentes de la fuente de alimentación de este producto, cuya reparación debe dejarse exclusivamente en manos de personal técnico especializado. Puede que este producto disponga de más de una fuente de alimentación. No intente modificar ni usar el cable de alimentación de corriente alterna, si no corresponde exactamente con el tipo requerido.
  • Page 109 ADVERTENCIAS: Español (continúa) Si el sistema ha estado en funcionamiento, el microprocesador y el disipador de calor pueden estar aún calientes. También conviene tener en cuenta que en el chasis o en el tablero puede haber piezas cortantes o punzantes. Por ello, se recomienda precaución y el uso de guantes protectores.
  • Page 110 SRKA4/ISP4400 Server System Product Guide...

  • Page 111: Index

    Index fans, 14, 37 installing all covers for correct airflow, 50 LEDs, 44 AC power connector, 19, 47 redundancy, 17, 43 AC power input, 87 system cooling, 17, 43, 62 add-in board expansion slot cover, 30, 31 installing hot-plug, 31 DC outputs, 42 removing hot-plug, 30 device bay...
  • Page 112 internal SCA-2 HDD connector, 84 fan board, replacing, 64 fan board assembly keyboard installing, 63 connector at back panel, 19, 47 removing, 62 connector description, 81 fans installing, 65 removing, 65 feature summary lithium battery, 38 chassis, 13 detailed, 35 front controls and indicators, 18, 46 memory rentention bar, installing, 52 rear controls and features, 19, 47...
  • Page 113 power subsystem bay SCSI installing, 61 cable type, 69 removing, 60 external connector, 19, 47, 86 hard disk drive, 26 power subsystem LEDs, 42 installing, 28 power supply plastic carrier, 26 AC input, 95 removing, 26 DC outputs, 42 SDRAM memory, 38 hazardous conditions, 60, 61 serial port, 81 power supply module...
  • Page 114 SRKA4/ISP4400 Server System Product Guide...

This manual is also suitable for:

Isp4400

Table of Contents
