Table 4. Chassis Feature Summary (continued)
Feature
E. Electronics Bay
(E-Bay)
E1. Processors
E2. Registered
SDRAM Memory
Expansion Slots
E3. PCI Add-In Slots
E4. PCI Hot-plug
Slots
E5. SKA4 Baseboard
E6. Voltage
Regulator
Module (VRM)
E7. Lithium Battery
F. Front
G. Right
H. Back
I. Left
38
Description
The E-Bay contains the SKA4 baseboard. The baseboard has the following major
components:
Up to four Intel Pentium III Xeon processors
Server Set III HE chipset
Up to sixteen PC/100-compliant Registered ECC SDRAM memory modules that
support up to 16 gigabytes of Error Checking and Correcting (ECC) Synchronous
Dynamic RAM
32-bit, 33 MHz, 5V PCI segment with two expansion slots and three embedded
devices
64-bit, 66/33 MHz, 3.3V hot-plug PCI segment with two expansion slots and one
embedded device
64-bit, 33 MHz, 5V hot-plug PCI segment with four expansion slots and three
embedded devices
Compatibility bus segment with three embedded devices
Two externally accessible USB port and one internally accessible USB header
One IDE connector, supporting up to two ATA33 compatible devices
One Adaptec AIC-7880 SCSI Controller
One Adaptec AIC-7899 SCSI Controller
The processors, SDRAM memory modules, and hot-plug PCI components are listed
individually below.
The system supports up to four Intel Pentium III Xeon processors.
The memory expansion board holds up to sixteen Dual Inline Memory Module
(DIMM) slots and supports up to 8 gigabytes of Error Checking and Correcting (ECC)
Synchronous Dynamic RAM.
The baseboard contains two 32-bit 33 MHz non-hot-plug PCI slots. These boards
are half-length boards only.
The baseboard contains six hot-plug PCI slots. You can add, remove, or exchange a
PCI add-in board from any hot-plug slot without shutting down the server.
Form-factor, 16 13 inches, ATX-style backpanel I/O.
The baseboard is mounted horizontally in a subassembly called the E-Bay. The
E-Bay is mounted towards the rear of the chassis.
The baseboard contains connectors for installing up to four Pentium III Xeon
processors in single-edge contact (SEC) cartridges.
The baseboard contains three embedded VRMs and connectors to add three
additional VRMs.
This battery is used to power the system clock.
This side is called the front of the E-Bay.
This side is called the right of the E-Bay.
This side is called the back of the E-Bay.
This side is called the left of the E-Bay.
SRKA4/ISP4400 Server System Product Guide
