Parallel Port

The IEEE 1284-compatible parallel port, used primarily for a printer, sends data in parallel format.
The parallel port is accessed through a D-subminiature 25-pin connector.
Table 10. Parallel Port
Pin Signal
1 STROBE_L
2 Data bit 0
3 Data bit 1
4 Data bit 2
5 Data bit 3
6 Data bit 4
7 Data bit 5
8 Data bit 6
9 Data bit 7
10 ACK_L (acknowledge)
11 BUSY
12 PE (paper end)
13 SLCT (select)

Video Port

The video port interface is a standard VGA compatible 15-pin connector. Onboard video is
supplied by an ATI RAGE IIC VT4 video controller with 2 MB of onboard video SGRAM.
Table 11. Video Port
Pin Signal
1 Red (analog color signal R)
2 Green (analog color signal G)
3 Blue (analog color signal B)
4 NC
5 GND
6 GND
7 GND
8 GND
9 Fused VCC (+5V)
10 GND
11 NC
12 DDCDAT
13 HSYNC (horizontal sync)
14 VSYNC (vertical sync)
15 DDCCLK
82
Pin Signal
14 AUFDXT_L (auto feed)
15 ERROR_L
16 INIT_L (initialize printer)
17 SLCTIN_L (select input)
18 GND (ground)
19 GND
20 GND
21 GND
22 GND
23 GND
24 GND
25 GND
