1 Chassis Description
The Intel SRKA4 MP Server System is designed to be mounted in a rack (rack mode). Figure 1
shows an example of this configuration. Before operation, you must purchase an adapter kit and
configure the server so that it can be mounted on a rack.
Contact your customer service representative for details on purchasing a rack adapter kit. For
instructions on mounting the server in a rack, see the SRKA4/ISP4400 Server System Quick Start
Guide accompanying your kit.
Table 1.
SRKA4 Server Physical Specifications
Specification
Height
Width
Depth
Weight
Required front clearance
Required rear clearance
Required side clearance
A.
Top Cover. The top cover protects the contents of the chassis.
B.
Front Cover. The front cover protects the peripheral devices.
C. Front Bezel Door. When this door is open, you can access hard drives and peripheral devices.
D. Front Bezel.
Rack Mode Only
4u (7 inches)
17.5-inch rack
26.5 inches
57 pounds, minimum configuration
88 pounds, maximum configuration
3 inches (inlet airflow <35 °C / 95 °F)
6 inches (no airflow restriction)
1 inch
Figure 1. SRKA4 MP Server System
A
B
C
D
OM09934
11
