Table 2. Chassis Feature Summary (continued)
Feature
D. Cooling
E. Electronics Bay
(E-Bay)
E1. E-Bay
(Overhead View)
E2. Hot-plug PCI Slots
WARNING
The total power requirement for the SRKA4 MP Server System exceeds
the 240 VA energy hazard limit that defines an operator-accessible area.
Only qualified service technicians should access the processor, memory,
power subsystem, and non hot-plug/hot-swap areas of the SKA4
baseboard.

Peripherals

Peripheral Bay
The chassis contains one peripheral bay for CD-ROM, DAT, and floppy drives. The peripheral
bay contains two smaller bays: a device bay and a configurable media bay.
Device Bay
The device bay accommodates either a 5.25-inch CD-ROM or a DAT drive. Only qualified
service technicians should remove and install components in the device media bay.
14
Description
Installed:
Fan board assembly and six fans in a redundant (5+1) fan array or three fans in a
non-redundant (3+0) fan array. The fans cool the baseboard and other
components.
In a 5+1 configuration, a failed fan may be removed and installed without shutting
down the server. This process is called hot-swapping. Hot-swapping fans can
only be performed by a qualified service technician.
The E-Bay contains the Intel SKA4 baseboard. The baseboard has the following
major components:
Up to four Intel Pentium III Xeon
Server Set III HE chipset
Up to sixteen PC/100-compliant Registered ECC SDRAM memory modules that
support up to 16 gigabytes of Error Checking and Correcting (ECC)
Synchronous Dynamic RAM
32-bit, 33 MHz, 5V PCI slots and three embedded devices
64-bit, 66/33 MHz, 3.3V hot-plug PCI slots and one embedded device
64-bit, 33 MHz, 5V hot-plug PCI slots and three embedded devices
ISA bus segment with three embedded devices
Two externally accessible USB port and one internally accessible USB header
One IDE connector, supporting up to two ATA33 compatible devices
With the exception of the hot-plug PCI cards, the E-Bay can only be accessed by
qualified service technicians.
An overhead view of the E-Bay.
Six hot-plug PCI slots located within the E-Bay.
processors
