Peripheral Devices (SR1530AH / SR1530AHLX)
The server system provides locations and hardware for installing hard drives, slimline
CD-ROM drive, or DVD-ROM drive. The drives must be purchased separately. The
following figure shows the available options.
.
8
A
B
A.
Slimline Optical Drive Bay
B.
Hard Disk Drive Bay HDD0 (located under the slimline optical drive bay)
C.
Hard Disk Drive Bay HDD1
Figure 6. Optional Peripherals (SR1530AH / SR1530AHLX)
Intel
C
®
Server System SR1530AH / SR1530AHLX / SR1530HAHLX
AF001074
