Table 2. Intel
Peripheral Interfaces
I/O Control
Video
LAN
Expansion Capabilities
(optional accessory
required)
Hard Drives
Peripherals
Control Panel
Power Supply
Fans
®
Intel Server System SR1530AH / SR1530AHLX / SR1530HAHLX
®
Server System SR1530AH / SR1530AHLX / SR1530HAHLX
Feature
External connections:
•
Stacked PS/2* ports for keyboard and mouse
•
DB9 Serial A port
•
Two RJ45 NIC connectors for 10/100/1000 Mb connections
•
Four USB 2.0 ports
Internal connections:
•
One USB port header, which supports two USB 2.0 ports
•
One DH10 Serial B header
•
Four Serial ATA connectors with embedded RAID 0/1/10
support.
•
One ATA-100 connector
•
ATX-compliant 24-pin, high-density 100-pin, and alternate 50-
pin control panel headers
SMSC* SCH5027 controller
On-board ATI* ES1000 video controller with 16 MB DDR SDRAM
®
Intel
In addition, one of the following:
•
Intel
Gigabit Ethernet Controller
•
Intel
82573E Gigabit Ethernet Controller
Support for one of the following:
•
One low-profile riser slot supporting a 1U PCI Express* riser
card
•
One low-profile riser slot supporting a 1U PCI-X* riser card
SATA support, 3 Gb/s: capable of supporting up to two drives
(SR1530AH / SR1530AHLX) or three drives (SR1530HAHLX)
•
Slimline bay for IDE optical drive (optional)
•
One USB port
•
Power / sleep button
•
Status LED
•
Power LED
•
Hard drive activity LED
•
NIC1 activity LED
•
NIC2 activity LED
One 350-watt power supply module
•
Three non-redundant fans (SR1530AH / SR1530AHLX)
•
Two non-redundant fans (SR1530HAHLX)
Feature Summary
Description
10/100/1000 82541PI Gigabit Ethernet Controller
®
Server System SR1530AH: Intel
®
Server System SR1530AHLX: Intel
®
10/100/1000 82573V
®
10/100/1000
3
