I/O Processors

I/O processors of the Intel RAID Controller SRCMR are represented in the physical configuration
window in Figure 82 and in Table 21. Each processor controls one I/O channel.
Table 21.

I/O Processor Icons

Item Description
SCSI processor
SE (single ended)
SCSI processor
LVD/SE (low voltage differential / single ended)
FC processor
FC AL (fibre channel arbitrated loop)
134 Intel RAID Controller SRCMR User's Guide
