Last Status

Last Status information should always be 0x00000000. After a device failure or other significant
events, a different value may be displayed here. This value is volatile and is reset to 0x00000000
after each power up and/or reset. If you press <Enter> on a Drive, StorCon displays additional
information on the SCSI parameter settings.

Save Information

Use the Save Information menu option to save the configuration information of the selected Intel
RAID Controller SRCMR and its devices in an ASCII-file. See Figure 23. Such system
information/ documentation would be helpful should you require support.
At the end of this protocol is a chronological listing of boot messages and other events stored in the
Flash-RAM of the Intel RAID Controller SRCMR. If the buffer is full, the oldest events are
deleted first.
Storage Console
Figure 22. Hard Disk Last Status
Figure 23. Save Information
