Table 16.

Advanced Settings

Parameter
Shrink BIOS after
Post
BIOS RAM
allocation method
DMEM mapping

Cluster Channels

The cluster channels menu (see Figure 42) is selectable only with Intel RAID Controllers that are
equipped with cluster firmware and allows the user to enable the IO channels of the Intel RAID
Controller SRCMR for clustering. Special care must be taken, that the IO Processors of a shared
channel (SCSI or Fibre Channel) have different IDs, otherwise there will be conflicts.

Clear Log Buffer

The Intel RAID Controller SRCMR records certain events in a logging buffer which is part of the
Flash-RAM. Clear all events in the buffer when using the Intel RAID Controller SRCMR in a new
system. The Clear Log Buffer function detects and deletes entries from the log buffer.
Storage Console
Alternatives Description
Off The BIOS is not shrinked after the post phase.
On The BIOS is always shrinked after the post phase.
Auto The Intel RAID Controller SRCMR decides on the BIOS shrink.
Auto The BIOS address space is automatically allocated.
Older The BIOS address space is allocated according to an older PCI
specification.
Move below The DPMEM address space is allocated below 1MB.
1MB
Do not move The DPMEM address is always above 1MB.
Figure 42. Cluster Channels
103
