Physical Drives

Physical drives are hard disks. Setting changes are not possible here. If you want to change the

settings, you must do so in the physical configuration window.

Table 28.

Double click on the host drive icon. This window contains information on a host drive

terms_host_drive

Drive No

The host drive number. The host drives are reported to the system in order,

beginning with the lowest Drive Number. If the corresponding Intel RAID

Controller SRCMR is the first controller in the system, the system will boot from

the host drive with the lowest number.

Storage Console Plus

Physical Disk

Use the Physical Configuration window to change disk

settings.

. See Figure 88.

Figure 88. Host Drive Information Window

147
