Table 19.

Configuration Menu Refresh Settings

Option
Refresh on
Refresh if window becomes active
Refresh information every ... seconds

Select Controller

The Select Controller window is used to select an Intel RAID Controller SRCMR for all further
actions within StorCon+. See Figure 78.
Select the desired protocol (Windows NT/95/98, Sockets, IBM
between the StorCon+ and the system equipped with the Intel RAID Controller SRCMR by double
clicking on the protocol icon on the very left side of the window. If you want to select an Intel
RAID Controller SRCMR via TCP/IP (sockets), type in the corresponding TCP/IP address or the
server system's name. Enter a user name and password. This information is transmitted with
encryption.
128
Description
Activates and deactivates the window update.
Update the window if it becomes active.
Sets the frequency for automatic window refreshes.
Figure 78. Logical Configuration Menu
†
NetBIOS) for the communication
Intel RAID Controller SRCMR User's Guide
