Table 14 lists the host drive types that can be created with the Intel RAID Controller SRCMR
Firmware.
Table 14.

Host Drive Types

Type of Host
Drive Description of Host Drive
Disk 1:1 assignment: host drive to hard disk (sometimes also called JBOD)
Chain Concatenation of several hard disks
RAID 1 Mirroring
RAID 0 Data Striping
RAID 4 Data Striping with parity drive
RAID 5 Data Striping with striped parity
RAID 10 Combined RAID 0 and RAID 1
After loading StorCon, the screen in Figure 13 appears (press <F10> to toggle between a black and
white or color display).
82
Figure 13. Select Interface
Intel RAID Controller SRCMR User's Guide
Minimum
Number of
Hard Disks
Required
1
2
2
2
3
3
4
