Logical Configuration Window

The Logical Configuration window shows the logical configuration of host drives
terms_host_drives, array drives and logical drives terms_logical_drive controlled by the selected
Intel RAID Controller SRCMR. The complete configuration is shown as a tree starting from the
left with the host drives, followed by the array drives the logical drives and the physical drives. See
the logical configuration window in Figure 97. Click on the logical configuration icon (Figure 89)
to open the window.
To get detailed information on a drive, double click on an icon (shown in Table 25). (The window
that opens depends on the type of the device.) To change the logical configuration of a drive, click
the right mouse button on the desired drive or select an option from the configuration menu. Drive
types are described below.

Host Drives

✏
NOTE
Intel RAID Controller SRCMR does not support clustering.
Table 25.

Host Drive Icons

Icon

Normal Host Drive

This host drive belongs to the selected Intel RAID Controller SRCMR on a non clustering I/O
channel.
142
Figure 87. Logical Configuration
Description
Host Drives. Double click to open information on a drive.
Right click to change the logical configuration of a drive.
Create a New Host Drive. Double click to create a new
host drive.
Intel RAID Controller SRCMR User's Guide
