Troubleshooting Checklist
S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m
For zone configuration problems, use the following helpful tools:
•
•
•

Troubleshooting Zone Configuration Issues with Fabric Manager

Much of the information accessible through Fabric Manager can also be accessed using the CLI. (See
the
To verify which devices belong to the active zone set on a specific VSAN using Fabric Manager, follow
these steps:
Choose Tools > Edit Full Zone Database. You see the Select VSAN dialog box.
Step 1
Select a VSAN and click OK. You see the Edit Local Full Zone Database dialog box for the selected
Step 2
VSAN.
Click Zones in the left pane. The right pane lists the members for each zone.
Step 3
Note The active zone set appears in bold. If there is no zone set in bold, you have not activated a zone set for
this VSAN.

Troubleshooting Zone Configuration Issues with the CLI

Much of the information accessed and summarized using Fabric Manager can also be found using CLI
show commands. (See
Table 14-1
Command
show zone analysis [active] vsan vsan-id
show zone name zonename
show device-alias database
show fcalias vsan-id
show zone member pWWN-id, fcalias-id,
or pWWN-id
show zone statistics
show zone internal vsan-id
show zoneset zonesetname
Cisco MDS 9000 Family Troubleshooting Guide, Release 3.x
14-2
Cisco Fabric Analyzer. (See the
Cisco Fabric Manager and CLI system messages. (See the
Log messages (See the "Troubleshooting with Logs" section on page
"Troubleshooting Zone Configuration Issues with the CLI" section on page
Table 14-1.)
Zone Troubleshooting Commands in the CLI
Chapter 14
"Cisco Fabric Analyzer" section on page
Command Description
Displays zone database information for a specific VSAN
Displays members of a specific zone.
Displays any device aliases configured.
Displays if and how FC aliases are configured.
Displays all zones to which a member belongs using the
FC ID, the FC alias, or the pWWN.
Displays the number of control frames exchanged with
other switches.
Displays the internal state of the zone server for a
specific VSAN.
Displays information about the named zone set.
Troubleshooting Zones and Zone Sets
B-25.)
System Messages, page 1-10.)
1-13.)
14-2.)
