22
Programming
the counting of the "W" and "var" energies proceed as fol-
lows:
5- Choose the C1 INPUT function by the
(see the description of the selected input function and the
weight of the associated pulse under the scrolling window);
S
press to confirm.
6- Once the ON/OFF window appears, choose "OFF" by the
and
S
firm with
and confirm with
7- The instrument asks the user to enter the number of puls-
es to be associated to the unit increase (pulse/ kWh, ex.:
entering the value 10 the instrument will need 10 input puls-
es to display 1kWh on the counter).
8- For the C2 INPUT, enabling function of the "kvarh" count-
ing, follow steps 5 to 7. To go back to the previous menus,
F
press .
S
F
S
1.2..
S
..2.1
Entering the main menu
17
keys to disable the counting of kWh's and con-
; choose "ON" to enable the counting of kWh's
S
.
F
17
Enabling the tariffs
remote control
This function enables the
control of the tariff phases of the
energy counters by means of
external pulses and not by
means of the instrument's clock.
From the PULSE sub-menu
select and enable the "A3
INPUT" and "C3 INPUT". Select
them one at a time by means of
33
and keys
Tariff table
24
