1.
To secure
the robot
arm
2.
3.
UR16e PolyScope X
Place the robot arm on the surface on which it is to be mounted. The surface must be
even and clean.
Tighten the four 8.8 strength, M8 bolts to a torque of 20 Nm.
(Torque values have been updated SW 5.18. Earlier printed version will show different
values)
If accurate re-mounting of the robot is required, use the Ø8 mm. hole and Ø8x13 mm.
slot with corresponding ISO 2338 Ø8 h6 positioning pins in the mounting plate.
