2.1. Technical Specifications UR16e
Robot type
Maximum payload
Reach
Degrees of freedom
Programming
Power consumption (average)
Ambient temperature range
Safety functions
IP classification
Cleanroom classification
Noise
Tool I/O ports
Tool I/O power supply & voltage
Force Torque sensor accuracy
Speed
Pose repeatability
Joint ranges
Footprint
Materials
Robot weight
System update frequency
Control Box size (W × H × D)
Control Box I/O ports
Control Box I/O power supply
Communication
Tool Communication
Control Box power source
Short-Circuit Current Rating (SCCR)
TP cable: Teach Pendant to Control Box
Robot Cable: Robot Arm to Control Box
(options)
UR16e PolyScope X
UR16e
16 kg / 35.2 lb
900 mm / 35.4 in
6 rotating joints
PolyScope GUI on 12" touchscreen.
or PolyScope X GUI on 12" touchscreen.
585 WApprox. 350 W using a typical program
0-50 °C. At ambient temperatures above 35°C, the robot
may operate at reduced speed and performance.
17 sophisticated safety functions. PLd Category 3 in
accordance with: EN ISO 13849-1.
IP54
Robot Arm: ISO Class 5,
Control Box: ISO Class 6
Robot Arm: Less than 65dB(A) Control Box: Less than
50dB(A)
2 digital in, 2 digital out, 2 analog in
2 A (Dual pin) 1 A (Single pin) & 12 V/24 V
5.5 N
Base and Shoulder joints: Max 120 °/s.
All other joints: Max 180 °/s .
Tool: Approx. 1 m/s / Approx. 39.4 in/s.
± 0.05 mm / ± 0.0019 in (1.9 mils)per ISO 9283
± 360 ° for all joints
Ø190 mm / 7.5 in
Aluminium, PC/ASA plastic
33.1 kg / 72.9 lb
500 Hz
460 mm × 449 mm × 254 mm / 18.2 in × 17.6 in × 10 in
16 digital in, 16 digital out, 2 analog in, 2 analog out
24 V 2 A in Control Box
MODBUS TCP & Ethernet/IP adapter, PROFINET, USB
2.0, USB 3.0
RS
100-240 VAC, 47-440 Hz
200A
4.5 m / 177 in
Standard (PVC) 6 m/236 in x 13.4 mm
Standard (PVC) 12 m/472.4 in x 13.4 mm
Hiflex (PUR) 6 m/236 in x 12.1 mm
Hiflex (PUR) 12 m/472.4 in x 12.1 mm
18
