Labconco Protector 50600 User Manual page 59

17. AtmosPure 6-pin Communication Cable (Part #5442000)
Required for use when AtmosPure and glove box configured with Auto
Pressure Controller are sharing one vacuum pump.
18. AtmosPure 9-pin Oxygen/Moisture Monitor Cable (Part #5442100)
Required for use when the AtmosPure is used in AUTO mode. Allows for
automatic control of the AtmosPure blower from an accessory Oxygen or
Moisture Monitor (sold separately).
19. AtmosPure 3/4" to 3/8" Adapter Kit (See Part #'s below)
Fittings permit 3/4" ID neoprene hose included with 5441800 and 5441801 Kits
(sold separately) to attach to separate filtration components listed under item 20
below. Two fittings included with each kit.
Part #
5441900
5441901
20. Filtration Components for Moisture, Oxygen and Fume Removal
The following components can be used to remove organics, acids, ammonia,
oxygen, moisture and other gases as indicated. They are connected to the two
auxiliary valves on the main glove box chamber for recirculation of main
chamber atmosphere and contaminant removal of air.
Part # Descriptions
5248200 Vacuum Pump for Circulation, 115V, 60 Hz w/switch
5248201 Vacuum Pump for Circulation, 230V, 50 Hz International
7815301 Canister with Stand for Traps
7815200 Moisture & Solvent Trap Insert; to provide less than 50 ppm
moisture (molecular sieve)
7814800 Acid Vapor Trap Insert
7815000 Radioisotope Trap Insert
7995600 Ammonia Trap Insert
5244100 Flowmeter, Visual
5244200 Oxygen and Moisture Removal Column catalysts can be
replaced but not regenerated; to provide less than 5 ppm
oxygen and less than 50 ppm moisture (refillable)
5244300 Oxygen and Moisture Removal Column Support Stand
Complete Moisture Drying Train; includes pump, column(s), stainless steel
tubing and molecular sieve to achieve less than 5ppm moisture only.
Part # Descriptions
115V, 60 Hz – one column
5061300
115V, 60 Hz – two columns, one in use while other regenerates
5061301
230V, 50 Hz – one column
5061302
230V, 50 Hz – two columns, one in use while other regenerates
5061303
5117000 Optional Second Column for 5061300 or 5061302
7837300 Molecular Sieve Replacement Media for two refills
Product Service 1-800-522-7658
Chapter 7: Accessorizing Your Glove Box
Description
Elbows
Reducers
55
