Part # Descriptions
5121810 100-115 volts, 50/60 Hz
5121831 208-230 volts, 50/60 Hz
5121835 208-230 volts, 50/60 Hz
5121840 208-230 volts, 50/60 Hz
5121845 208-230 volts, 60 Hz
9. AtmosPure Regeneration Plumbing Kit (Part #5441700)
The regeneration plumbing kit includes flexible tubing and fittings to make
all the regeneration service supply tubing connections. These are the
connections to the 4% hydrogen inert gas mixture, vacuum, and vent.
10. AtmosPure Circulation Kits (see Part #'s below)
The circulation kits include all the plumbing and tubing parts needed to
connect the Gas Purifier to the glove box. There are two options for
neoprene lined hose or stainless steel tubing.
Part # Description
5441800 3/4" I.D. Neoprene lined hose
5441801 3/4" I.D. Neoprene lined hose
5441802 3/4" Rigid Stainless Steel
5441803 3/4" Rigid Stainless Steel
11. AtmosPure Roughing Pre-Filter Kit (Part #5441500)
Provides two roughing particulate pre-filters and clamp plates to mount
inside Protector Glove Boxes only. It is used to filter the inlet and outlet of
the glove box as the inert gas is purified. Order individual 5122400 filters
separate. Two each required.
12. AtmosPure P100 Particulate Filter Kit (Part #5441600)
Provides two P100 particulate filters and mount housings that are similar to
respirator cartridges. P100 filters are 99.97% efficient for all particulates.
It is used to filter the inlet and outlet of the glove box as the inert gas is
purified. Order replacement filter set 5441601 separate which includes two
P100 particulate filters.
13. Oxygen Monitors
Oxygen monitors allow the user to continuously monitor oxygen levels
inside the glove box. Monitors are normally placed inside the main
chamber to provide the best performance. Never operate a transfer
chamber vacuum evacuation on sensitive oxygen monitors as damage
can occur.
Part # Descriptions
5244500 0-10,000 ppm Oxygen Monitor (with three ranges of 0-100 ppm, 100-
1,000 ppm, and 1,000-10,000 ppm) 100V/115V – 50/60 Hz
5244501 0-10,000 ppm Oxygen Monitor (with three ranges of 0-100 ppm, 100-
1,000 ppm, and 1,000-10,000 ppm) 230V – 50/60 Hz – International
0.1-100% Oxygen Monitor (1,000 ppm lowest) 100V/115V/230V –
5244400
50/60 Hz
Product Service 1-800-522-7658
Chapter 7: Accessorizing Your Glove Box
Electrical Receptacle & Plug Type
North America, 100-115 Volts
British (UK)
Schuko
China/Australia
North America, 208-230 Volts
Used On
All Glove Boxes, single width
All Glove Boxes, double width
Protector Glove Boxes, single width
Protector Glove Boxes, double width
