CHILD SEATS
Installation table
The table below summarises the information already shown on the previous diagram in order to ensure the regulations
2
in force are respected.
2-seater van version
Child seat group
Rear-facing shell seat
Group 0 or 0 +
Rear-facing seat
Group 0+ and 1
Forward-facing seat
Group 1
Booster seat
Group 2 and 3
U = Seat enabling a child seat with "Universal" approval to be attached by seat belt: check that it can be fitted.
B2 = Seat allowing a child seat with "B2" approval to be attached by seat belt: check that it can be fitted.
RISK OF DEATH OR SERIOUS INJURY, before installing a child seat:
(1) on the front passenger seat, check that the airbag has been deactivated �� 116;
(2) position the vehicle seat as far back and as high as possible. Tilt the seatback slightly �� 63. Adjust the seat
belt position to the lowest position. After you have adjusted it, make sure that the seat belt is locked in position
correctly �� 68.
9 4 - G e t t i n g t o k n o w y o u r v e h i c l e
Weight of the child Passenger Airbag activated
< 13 kg
< 13 kg and
9 to 18 kg
9 to 18 kg
15 kg to 25 kg and
22 to 36 kg
Front passenger seat
Without passenger airbag or deactivated
X
X
U (2)
U / B2 (2)
U (1) (2)
U (1) (2)
X
X
