VEHICLE E-TECH 100% ELECTRIC (EV)
– store the cable 2 .
Note: immediately after a long period
of charging the traction battery, the
2
lead may be hot. Please use the han­
dles.
After pressing the charging
cable release button, you
will have around 30 sec­
onds to unplug it before it is
locked once again.
Label 12
The label 12 located on the charging
flap 8 provides information on the
4 2 - G e t t i n g t o k n o w y o u r v e h i c l e
charging operation according to the
status of the warning light 9 :
– when it flashes in white this indicates
that the lead is plugged into the vehicle
and the system is carrying out its
checks;
– when it flashes in blue this indicates
that charging is in progress;
– when it lights up continuously in blue
this indicates that charging program­
ming is activated;
– when it lights up continuously in
green this indicates that the vehicle is
fully charged;
– when it lights up continuously in red
this indicates an operating fault.
The label 12 located on the right-hand
side reminds you of the following in­
structions:
– do not wash the charging flap using
a high-pressure water jet;
– with the vehicle stationary, the valve
and the charging flap can be opened;
– when the vehicle is being driven, the
valve and the charging flap must be
closed;
– open the flap to connect the charg­
ing lead;
– close the flap again once discon­
nected;
– connect to a domestic socket, an al­
ternating current charging terminal or a
quick charging terminal;
– for any information on charging,
please consult your vehicle user man­
ual.
