  • Page 1 Renault MEGANE Vehicle user manual...
  • Page 2 Castrol, exclusive Renault partner Benefit from cutting-edge technology born out of competition to ensure the performance and longevity of your Renault thanks to wide range of engine lubricants developed specially by Renault and Castrol. renault.com Renault recommends...
  • Page 3 Welcome to your new vehicle This driver’s handbook contains the information necessary: – for you to familiarise yourself with your vehicle, to use it to its best advantage and to benefit fully from the all the functions and the technical developments it incorporates. –...
  • Page 5 Sections Getting to know your vehicle ....... Driving ..............Your comfort ............Maintenance ............Practical advice ............ Technical specifications ........Alphabetical index ..........
  • Page 6 EXTERIOR Rear view mirrors ➥ 1.98 Electric windows ➥ 3.28 Windscreen wipers ➥ 1.108 and ➥ 1.114 Demisting ➥ 3.5 and ➥ 3.8 Key/Remote control ➥ 1.2 Map ➥ 1.6 Locking/unlocking the doors ➥ 1.13 Bodywork maintenance ➥ 4.15 Lights: operation ➥ 1.102 Lights: replacement ➥...
  • Page 7 PASSENGER COMPARTMENT Adjusting your driving po- Passenger compartment storage, fit- sition ➥ 1.29 tings ➥ 3.36 Rear bench seat ➥ 3.44 Rear headrests ➥ 3.42 Front seats ➥ 1.20 and ➥ 1.23 Front headrests ➥ 1.19 Luggage compartment stor- Child safety ➥ 1.43 age/fittings ➥...
  • Page 8 DRIVER’S POSITION Trip computer controls ➥ 1.81 Instrument panel ➥ 1.66 Exterior lighting ➥ 1.102 Multimedia screen ➥ 3.26 Cruise control Heating/Air conditioning ➥ 2.89 system ➥ 3.5 Cruise control adaptive ➥ 2.94 Heated seat(s) ➥ 1.20 and Speed limiter ➥ 2.85 ➥...
  • Page 9 DRIVING AIDS Speed limiter ➥ 2.85 ABS (anti-lock braking system) ESC (electronic stability control) Detection of road signs ➥ 2.81 Braking assistance Hill start assistance ➥ 2.43 Cruise control ➥ 2.89 Lane departure warning ➥ 2.49 Adaptive cruise control ➥ 2.94 Lane Keeping Assist ➥...
  • Page 10 SAFETY ON BOARD Front Airbags ➥ 1.34 Inhibiting the front passen- Curtain Airbags ➥ 1.41 ger airbag ➥ 1.58 Side Airbags ➥ 1.41 Seat belts ➥ 1.29...
  • Page 11 IDENTIFYING A VEHICLE - LABELS Review of a vehicle identification number ➥ 6.2 Vehicle identification plate ➥ 6.2 Engine identification plate ➥ 6.3 Tyre pressure labels ➥ 2.32 ➥ 4.13...
  • Page 12 THE ENGINE COMPARTMENT (routine maintenance) Coolant level ➥ 4.8 Brake fluid ➥ 4.8 Windscreen washer fluid ➥ 4.8 Battery ➥ 4.11 Engine oil filler cap ➥ 4.5 Engine oil dipstick ➥ 4.4 Opening the bonnet ➥ 4.2 0.10...
  • Page 13 BREAKDOWN RECOVERY Replacing windscreen wiper Puncture: blade(s) ➥ 1.108 Tools ➥ 5.8 Emergency spare wheel ➥ 5.2 Changing wheel Replacing headlight ➥ 5.11 bulbs ➥ 5.16 Front towing point ➥ 5.39 Replacing rear screen wiper blade ➥ 1.114 Fuses ➥ 5.28 Replacing rear light bulbs ➥...
  • Page 14 0.12...
  • Page 15 Section 1: Getting to know your vehicle Key, radio frequency remote control: general information, use, deadlocking ....Card: general information, use, deadlocking ......... . . Locking, unlocking the doors .
  • Page 16 KEY, RADIO FREQUENCY REMOTE CONTROL: general information (1/2) Driver’s responsibility when parking or stopping the vehicle Never leave an animal, child or adult who is not self-suffi- cient alone on your vehicle, even for a short time. They may pose a risk to themselves or to others by starting the engine, 1 Locks all the opening elements.
  • Page 17 KEY, RADIO FREQUENCY REMOTE CONTROL: general information (2/2) Radio frequency remote control operating range This varies according to the surround- ings: take care not to lock or unlock the doors by inadvertently pressing the but- tons on the remote control. Note: if a door or the boot is open or not properly shut, locking is not carried out.
  • Page 18 RADIO FREQUENCY REMOTE CONTROL UNIT: use Unlocking the doors The remote control A can be used to lock or unlock the doors and boot. Pressing button 2 unlocks the doors It is powered by a battery which can be and tailgate. replaced.
  • Page 19 RADIO FREQUENCY REMOTE CONTROL UNIT: deadlocking If the vehicle is equipped with a dead- locking function, this allows you to lock the opening elements and to prevent the doors from being unlocked using the interior handles (for example, by breaking the window and then trying to open the door from the inside).
  • Page 20 CARD: general information (1/2) The card is used for: Card operating range – locking/unlocking the doors and tail- This varies according to the surround- gate (doors, tailgate) and the fuel ings. It is important to make sure when filler flap (see the following pages); handling the card that you do not lock –...
  • Page 21 CARD: general information (2/2) Advice Avoid leaving the card in hot, cold or Driver’s responsibility humid areas. when parking or stopping Do not keep the card in a place the vehicle where it could be bent or dam- Never leave an animal, aged accidentally, such as in a back child or adult who is not self-suffi- pocket of a garment.
  • Page 22 “HANDS-FREE” CARD: use (1/4) Deactivating/activating the “hands-free” mode Depending on the vehicle, you can de- activate/activate: – unlocking when approaching and locking when moving away from the vehicle; – locking and unlocking by pressing on the buttons on the door handle. Driver’s responsibility You can also disable/activate the sound when parking or stopping...
  • Page 23 “HANDS-FREE” CARD: use (2/4) Hands-free unlocking, when Hands-free locking when If the card has been within the detec- tion area 3 for approximately 15 min- approaching the vehicle; moving away from the utes, remote locking is disabled. To lock vehicle With the card in access zone 3, the ve- the vehicle, press the 2 button on the 1 hicle will unlock.
  • Page 24 “HANDS-FREE” CARD: use (3/4) To indicate that the vehicle has been locked, the hazard warning lights flash twice and then light up for approxi- mately four seconds. Special features of the unlocking system After eight days of non-use, approach unlocking is disabled. Press button 2 (front door or boot handle) or use the remote control card (refer to the following pages) to unlock...
  • Page 25 “HANDS-FREE” CARD: use (4/4) Locking using the card With the doors and boot closed, press button 5: the vehicle locks. To indicate that the vehicle has been locked, the hazard warning lights flash twice and then light up for approxi- mately four seconds.
  • Page 26 CARD: deadlocking If the vehicle is equipped with a dead- locking function, this allows you to lock the opening elements and to prevent the doors from being unlocked using the interior handles (for example, by breaking the window and then trying to open the door from the inside).
  • Page 27 LOCKING, UNLOCKING THE DOORS (1/3) If the remote control or, depending on the vehicle, the card does not work In some cases, the radio frequency remote control or the card may not work: – card or radio frequency remote con- trol battery worn or run flat, vehicle battery flat etc;...
  • Page 28 LOCKING, UNLOCKING THE DOORS (2/3) Vehicles with key/remote Locking the doors manually Using the key integrated in the card control – Insert the tip of the key 2 into the Turn screw 6 with the door open (using notch 3 at the bottom of the cover B the end of the key) and close the door.
  • Page 29 LOCKING, UNLOCKING THE DOORS (3/3) Door and tailgate status If transporting an object with the tail- gate open, you can still lock the doors: indicator with the engine stopped, press and When the ignition is on, the indicator hold switch 7 for more than five sec- light integrated in switch 7 informs you onds to lock the other doors.
  • Page 30 OPENING AND CLOSING THE DOORS (1/2) Driver’s responsibility when parking or stopping the vehicle Never leave an animal, child or adult who is not self-suffi- cient alone on your vehicle, even for a short time. They may pose a risk to themselves or to others by starting the engine, Opening the doors from the Opening from the inside...
  • Page 31 OPENING AND CLOSING THE DOORS (2/2) Lights-on reminder buzzer A warning beep sounds when the driv- er’s door is opened to warn you that the lights are still on. Door/tailgate open buzzer Child safety At a standstill, warning light 3 lights Move lever 5 and check from the inside up on the instrument panel alongside that the doors are securely locked, to...
  • Page 32 AUTOMATIC LOCKING WHEN DRIVING Activating/deactivating the Operating faults function If you experience an operating fault (no automatic locking, the indicator light in- To switch it on: with the vehicle at a corporated in switch 2 does not light up standstill and the engine running, press when trying to lock the doors and boot, switch 2 until a beep sounds.
  • Page 33 FRONT HEADRESTS To adjust the angle of the headrest If your vehicle is thus equipped, move the A section towards or away from you to the required position To remove the headrest Raise the headrest to its highest po- sition (tilt the seatback backwards if necessary).
  • Page 34 FRONT SEATS WITH MANUAL CONTROL (1/3) Settings To tilt the seatback Lift handle 3 and tilt the seatback to the To move the seat forwards or back desired position. Release the handle at For safety reasons, make Lift handle 1 to release. Release the the desired position and make sure that these adjustments only handle at the desired position and...
  • Page 35 FRONT SEATS WITH MANUAL CONTROL (2/3) When using the passenger seat in table position, you must not use the two rear seats immediately behind it. Be sure to hold the seat- back when placing it in the flat position. Table function Risk of injury.
  • Page 36 FRONT SEATS WITH MANUAL CONTROL (3/3) Repositioning the seat Heated seats Make sure that nothing prevents the With the ignition on: seat from moving. – pressing the switch 7 on the required – Pull the handle 6 and raise the seat- seat for the first time activates the back, ensuring that it locks firmly in heating system at maximum power.
  • Page 37 DRIVER’S SEAT WITH ELECTRIC CONTROLS (1/2) Adjusting the seat position On vehicles that are equipped, the switch 1 can be used to access the To move the seat forwards or back “Seats” menu on the multimedia screen Move switch 4 forwards or backwards. (see following pages).
  • Page 38 DRIVER’S SEAT WITH ELECTRIC CONTROLS (2/2) For safety reasons, carry Heated seats out any adjustments when the vehicle is not being With the ignition on: driven. – Pressing the switch 5 on the required Make sure that the seatbacks are seat for the first time activates the correctly locked in place.
  • Page 39 FRONT SEATS: Functions (1/3) Browse the “Driver” menu to: – select the massage type (Tonic, Massage Relaxing or Lumbar); – adjust the intensity (+ or -); Tonic Relaxing Lumbar – adjust the speed (+ or -); Intensity – reset the settings selected on the Speed dropdown menu 2;...
  • Page 40 FRONT SEATS: Functions (2/3) Easy driver access Press ON or OFF to activate or deacti- vate this function. When this function is activated, the seat automatically moves back when the driver leaves the vehicle, and returns to its position when the start button is pressed.
  • Page 41 FRONT SEATS: Functions (3/3) Position It is possible to store the driving posi- tion of the driver seat. The driving position includes the set- tings for the seat base and seatback as well as the door mirrors. Save Recall The driving position can be stored and recalled by pressing the buttons: Visual feedback –...
  • Page 42 STEERING WHEEL Activating the function With the ignition on, press the switch 2, the warning light integrated in the switch lights up. Deactivating the function - Automatic: The function switches off automatically after the regulation phase of approxi- mately 30 minutes. The switch 2 warn- ing light stays on.
  • Page 43 SEAT BELTS (1/5) Adjusting your driving Always wear your seat belt when trav- elling in your vehicle. You must also position comply with the legislation of the par- – Sit well back in your seat (having ticular country you are in. removed your coat or jacket etc.).
  • Page 44 SEAT BELTS (2/5) Locking Unwind the belt slowly and smoothly and ensure that buckle 3 locks into catch 5 (check that it is locked by pull- ing on buckle 3). If the belt jams, allow it to return slightly before attempting to unwind it again. If your seat belt is completely jammed, pull slowly, but firmly, so that just over 3 cm unwinds.
  • Page 45 SEAT BELTS (3/5) ß Driver’s seat belt reminder In all cases, check that the rear pas- and, depending on the vehi- sengers are wearing seat belts and that cle, front passenger seat belt re- the number of seat belts shown as fas- minder tened matches the number of rear seat places occupied.
  • Page 46 SEAT BELTS (4/5) Adjusting the height of the Rear seat belts 8 front seat belts The belts are locked, unlocked and adjusted in the same way as the front Use button 7 to adjust the seat belt belts. height so that the shoulder strap is worn as shown previously.
  • Page 47 SEAT BELTS (5/5) The following information applies to the vehicle’s front and rear seat belts. – No modification may be made to the component parts of the originally fitted restraint system: seat belts, seats and their mountings. For special operations (e.g. fitting child seats), contact an authorised dealer. –...
  • Page 48 METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (1/6) Depending on the vehicle, they are – Have the entire restraint composed of: system checked following – seat belt inertia reel pretension- an accident. ers; – No operation whatso- –...
  • Page 49 METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (2/6) Load limiter driver and passenger front Airbags Above a certain severity of impact, this mechanism is used to limit the force of Fitted to the driver and passenger the belt against the body so that it is at sides.
  • Page 50 METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (3/6) Operating faults å This warning light comes on when the engine is started and then goes out after approximately three sec- onds. If it does not come on when the ignition is switched on or if it stays on, there is a fault in the system.
  • Page 51 METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (4/6) The following cases trigger the pre- In a frontal impact with another vehi- In a side impact with another vehicle tensioners or airbags. cle of an equivalent or higher category, of an equivalent or higher category, at with an impact area equal to or greater an impact speed equal to or greater...
  • Page 52 METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (5/6) In the following examples, the pre- In the following examples, there is a – side impact to the front or rear of the tensioners or the airbags could op- risk that pretensioners orairbags may vehicle;...
  • Page 53 METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (6/6) All of the warnings below are given so that the airbag is not obstructed in any way when it is inflated and also to prevent the risk of serious injuries caused by items which may be dislodged when it inflates. Warnings concerning the driver’s airbag –...
  • Page 54 METHODS OF RESTRAINT IN ADDITION TO THE REAR SEAT BELTS Force limiter Above a certain severity of impact, this mechanism is used to limit the force of the belt against the body so that it is at an acceptable level. –...
  • Page 55 SIDE PROTECTION DEVICES Side air bags These air bags are fitted to the front seats and are activated at the sides of the seats (door side) to protect the oc- cupants in the event of a severe side impact. Curtain air bags These are airbags fitted along the sides of the vehicle in the ceiling which trigger along the front and rear door side win-...
  • Page 56 ADDITIONAL METHODS OF RESTRAINT All of the warnings below are given so that the air bag is not obstructed in any way when it is inflated and also to prevent the risk of serious injuries caused by items which may be dislodged when the air bag inflates. The air bag is designed to complement the action of the seat belt.
  • Page 57 CHILD SAFETY: General information (1/2) Carrying children Please ensure that you comply with the legislation of your country. Children, and adults, must be correctly seated and strapped in for all journeys. The children being carried in your vehi- cle are your responsibility. Driver’s responsibility A child is not a miniature adult.
  • Page 58 CHILD SAFETY: General information (2/2) Using a child seat Set a good example by always fas- The level of protection offered by the tening your seat belt and teaching child seat depends on its ability to re- your child: strain your child and on its installation. –...
  • Page 59 CHILD SAFETY: choosing a child seat Rear-facing child seats Forward-facing child seats Booster cushions A baby’s head is, proportionally, heavier The child’s head and abdomen need to From 15 kg or 4 years, the child can than that of an adult and its neck is very be protected as a priority.
  • Page 60 CHILD SAFETY: choosing a child seat mounting (1/4) There are two ways of attaching child Attachment via the seat belt seats: via the seat belt or using the The seat belt must be adjusted to ISOFIX system. ensure that it is effective in the event of harsh braking or an impact.
  • Page 61 CHILD SAFETY: choosing a child seat mounting (2/4) Attachment using the ISOFIX Attach the child seat with the ISOFIX system locks, if these are provided. The ISOFIX system allows quick, easy, safe fitting. Approved child seats ISOFIX are stand- ardised in accordance with current reg- The ISOFIX system consists of 2 rings ulations if any of the four cases below and, in some cases, a third ring.
  • Page 62 CHILD SAFETY: choosing a child seat mounting (3/4) The rings are located on the rear seat-  backs and indicated by the symbol In all cases, attach the strap hook to the corresponding ring 3 or 4 and place the seat in the desired position.
  • Page 63 CHILD SAFETY: choosing a child seat mounting (4/4) The rings are located behind the rear  seats and indicated by the symbol Attach the strap hook to the corre- sponding ring 3 and place the vehicle seat in the desired position. Pull the belt so that the back of the child seat comes into contact with the back of the vehicle seat.
  • Page 64 CHILD SAFETY: fitting a child seat, general information (1/2) Some seats are not suitable for fitting The types of child seat indicated may After installing the child seat, when this child seats. The diagram on the follow- not be available. Before using a differ- is possible, you can move the vehi- ing page shows you how to attach a ent child seat, check with the manufac-...
  • Page 65 CHILD SAFETY: fitting a child seat, general information (2/2) In the rear seat A carrycot can be installed across the vehicle and will take up at least two seats. Position the child with his or her feet nearest the door. Move the front seat as far forward as possible to install a rear-facing child seat, then move back the seat in front...
  • Page 66 CHILD SEATS: attachment by seat belt (1/3) The table below summarises the information already shown in the diagram on the following pages, to ensure the appli- cable regulations are respected. Front passenger Type of child seat Weight of the child Rear side seats Rear centre seat seat (1)
  • Page 67 CHILD SEATS: attachment by seat belt (2/3) X = Seat not suitable for fitting child seats of this type. U = Seat which allows a child seat with “Universal” approval to be installed using a seat belt; check that it can be fitted. (2) A carrycot can be installed across the vehicle and will take up at least two seats.
  • Page 68 CHILD SEATS: attachment by seat belt (3/3) Fitting diagram ³ Check the status of the airbag before fitting a child seat or allowing a passenger to use the seat. ² Seat not suitable for fitting child seats. Child seat attached using the belt ¬...
  • Page 69 CHILD SEATS: attachment using the isofix system (1/3) Fitting diagram Child seat fitted using the ISOFIX mounting  Seat which allows an ISOFIX child seat to be fitted. ± The rear seats are fitted with an anchorage point which allows a forward-facing ISOFIX child seat with universal approval to be attached.
  • Page 70 CHILD SEATS: attachment using the isofix system (2/3) The table below summarises the information already shown on the diagram on the previous pages, to ensure the regula- tions in force are respected. Weight of Front passenger Type of child seat Seat size ISOFIX Rear side seats Rear centre seat...
  • Page 71 CHILD SEATS: attachment using the isofix system (3/3) X = Seat not suitable for fitting child seats ISOFIX. IUF/IL = On equipped vehicles, seat which allows an approved “Universal/semi-universal” or “vehicle specific” child seat to be at- tached using the ISOFIX system; check that it can be fitted. i-U = Suitable for the i-Size restraint devices in the “universal”...
  • Page 72 CHILD SAFETY: deactivating, activating the front passenger airbag (1/3) The front passenger airbag should only be activated or deactivated when the vehi- cle is stationary with the ignition off. If it is interfered with when the ve- hicle is being driven, indicator lights å...
  • Page 73 CHILD SAFETY: deactivating, activating the front passenger airbag (2/3) The markings on the dashboard and labels A on each side of the passen- ger sun visor 3 (example: label shown above) remind you of these instruc- tions. DANGER Since operation of the front passenger airbag is not compatible with the po- sition of a rear-facing child seat,...
  • Page 74 CHILD SAFETY: deactivating, activating the front passenger airbag (3/3) Operating faults It is forbidden to fit a rear-facing child seat to the front passenger seat if the airbag activation/deactivation system is faulty. Allowing any other passenger to sit in that seat is not recommended. Contact your approved dealer as soon as possible.
  • Page 75 AUDIBLE AND VISUAL SIGNALS Direction indicators Move stalk 1 parallel to the steering wheel and in the direction you are going to turn it. One-touch mode When driving, it is possible that the steering wheel may not be turned suf- ficiently to return the stalk automatically to its starting position.
  • Page 76 DRIVER’S POSITION, LEFT-HAND DRIVE (1/2) 1.62...
  • Page 77 DRIVER’S POSITION, LEFT-HAND DRIVE (2/2) The equipment fitted, described below, DEPENDS ON THE VERSION AND COUNTRY. 19 Gearstick. 1 Air vent. 11 Switches for: 2 Demister outlet. – hazard warning lights; 20 Engine start/stop button (vehicles 3 Stalk for: – electric door locking. with card).
  • Page 78 DRIVING POSITION: RIGHT-HAND DRIVE (1/2) 9 10 1.64...
  • Page 79 DRIVING POSITION: RIGHT-HAND DRIVE (2/2) The equipment fitted, described below, DEPENDS ON THE VERSION AND COUNTRY. 8 Main switch and controls for cruise 1 Air vent. 15 Control for adjusting steering 2 Demister outlet. control/speed limiter and adaptive wheel height and reach. 3 Passenger Airbag location.
  • Page 80 WARNING LIGHTS (1/6) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. Instrument panel A, B or C: this comes In some cases, the appearance of a on when the driver's door is opened. warning light is accompanied by a mes- sage.
  • Page 81 WARNING LIGHTS (2/6) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. š Side light warning light Low fuel level warning light STOP light ® It appears in yellow when the This lights up when the igni- ignition or the engine is switched on tion or engine is switched on and goes á...
  • Page 82 WARNING LIGHTS (3/6) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. À Brake circuit fault warning Oil pressure warning light Warning light © light It lights up when the ignition or This lights up when the ignition It lights up when the ignition or the the engine is switched on and goes off or engine is switched on and goes out...
  • Page 83 WARNING LIGHTS (4/6) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.  Ô É Warning light for the elec- Coolant temperature warn- Preheating warning light tronic stability program ing light (Diesel version) (ESC) and traction control system This lights up red when the ignition is This should come on when the igni- It lights up when the ignition or the...
  • Page 84 WARNING LIGHTS (5/6) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.    Engine standby warning Lane departure system Mode warning light ECO light ➥ 2.8 warning light ➥ 2.49 This comes on when ECO ...
  • Page 85 WARNING LIGHTS (6/6) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. ß Driver's seat belt reminder and, depending on the vehi- cle, front passenger seat belt re- minder ➥ 1.29 On display C  Passenger airbag ON ➥...
  • Page 86 DISPLAYS AND INDICATORS (1/9) Instrument panel in miles (option to switch to km/h) Vehicles not fitted with a multimedia screen – With the ignition off, press the 2 switch as many times as required to reach the vehicle tab 5; –...
  • Page 87 DISPLAYS AND INDICATORS (2/9) Instrument panel A Speedometer 6 Overspeed buzzer Depending on the style selected, the Depending on the vehicle and country, It lights up when the ignition is switched  display varies. on. In some cases, the appearance of a warning light is displayed warning light is accompanied by a mes- and a beep sounds.
  • Page 88 DISPLAYS AND INDICATORS (3/9) Fuel gauge 15 If the level is at the minimum, the warn- ing light in the indicator appears in yellow, accompanied by a beep. Fill up as soon as possible. Multimedia information 11 Coolant temperature indicator 13 Depending on the vehicle, you can dis- In normal use, indicator 13 should be play information from the multimedia...
  • Page 89 DISPLAYS AND INDICATORS (4/9) Instrument panel B Coolant temperature indicator 16 Overspeed buzzer In normal use, indicator 16 should be Depending on the vehicle and country, It lights up when the ignition is switched  before area 17. Under “intensive” op- on.
  • Page 90 DISPLAYS AND INDICATORS (5/9) Multimedia information 21 Fuel gauge 25 Depending on the vehicle, you can dis- If the level is at the minimum, the warn- play information from the multimedia screen (the compass, telephone, navi- ing light in the indicator appears in gation, etc.).
  • Page 91 DISPLAYS AND INDICATORS (6/9) Instrument panel C Rev counter 26 Trip computer 29 (graduations x 1000) ➥ 1.81 It lights up when the ignition is switched on. In some cases, the appearance of a Coolant temperature indicator 28 Estimated mileage with remaining warning light is accompanied by a mes- fuel 30 In normal use, the indicator 28 should...
  • Page 92 DISPLAYS AND INDICATORS (7/9) Fuel gauge 34 If the level is at the minimum, the warn- ing light in the indicator appears in orange, accompanied by a beep. Fill up as soon as possible. Speedometer 33 Driving style indicator 32 ➥ 2.22 Overspeed buzzer Depending on the vehicle and country, ...
  • Page 93 DISPLAYS AND INDICATORS (8/9) You can adjust some settings from the multimedia screen. Refer to the multimedia instructions. Adjusting the display information height Depending on your driving position, you can raise or lower the information on the display. Adjusting the display brightness You can adjust the brightness (day or night mode): Good information visibility can be af-...
  • Page 94 DISPLAYS AND INDICATORS (9/9) Operating faults In the event of a malfunction (the dis- play fails to open when the engine is started, or the display retracts, with the engine running, following an object im- pacting the display): – stop and restart the engine; –...
  • Page 95 TRIP COMPUTER: general information (1/4) Trip computer A, B or C Depending on the vehicle, this includes the following functions: – distance travelled; – journey settings; – information messages; – operating fault messages (con- © nected to the warning light); –...
  • Page 96 TRIP COMPUTER: general information (2/4) Vehicle fitted with trip computer A The functions are distributed in zones 5, 6, 7, and 8. The location of the zones differs depending on the style selected. Press the 1 switch to browse between menus and select functions by repeat- edly pressing the 2 or 3 switch, then if necessary use the 4 switch to confirm...
  • Page 97 TRIP COMPUTER: general information (3/4) Vehicle fitted with trip computer B Vehicle fitted with trip computer C The functions will be distributed in Press the 1 switch as many times as re- zones 5, 6, 7 and 8. quired to reach the “Vehicle” tab. Press the 1 switch to browse between Press repeatedly using the 2 or 3 con- menus and select functions by repeat-...
  • Page 98 TRIP COMPUTER: general information (4/4) Interpreting some of the Selections values displayed after (the display depends on the vehicle resetting equipment and country) a) Trip log, operating faults and infor- The values showing average fuel con- mation message readout; sumption, range and average speed will become more stable and reliable b) current fuel consumption and aver- the further you travel after pressing the...
  • Page 99 TRIP COMPUTER AND WARNING SYSTEM: journey parameters (1/4) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. Examples of selections Interpreting the display selected a) Trip log. Successive display: Vehicle Systems OK – information messages (passenger airbag OFF etc.); –...
  • Page 100 TRIP COMPUTER AND WARNING SYSTEM: journey parameters (2/4) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. Examples of selections Interpreting the display selected Tyre pressure init. d) Reset the tyre pressure. long press ➥ 2.32 e) Setting the time.
  • Page 101 TRIP COMPUTER AND WARNING SYSTEM: journey parameters (3/4) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. Examples of selections Interpreting the display selected On-board computer with mileage- before-service message f) Service distance. Mileage before service Service in With the ignition on and engine not running, access the “Mileage 30 000 km / 12 months...
  • Page 102 TRIP COMPUTER AND WARNING SYSTEM: journey parameters (4/4) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. Examples of selections Interpreting the display selected On-board computer with distance before next service message (cntd.) f) Service distance. Mileage before service Oil change in With the ignition on and the engine not running, access the mileage...
  • Page 103 TRIP COMPUTER AND WARNING SYSTEM: information messages These can help in the vehicle starting phase, or give information about a selection or a driving status. Examples of information messages are given in the following pages. Examples of messages Interpreting the display selected “Parking Brake ON”...
  • Page 104 TRIP COMPUTER AND WARNING SYSTEM: operating fault messages © These appear with the warning light and mean that you should drive very carefully to an authorised dealer as soon as possible. If you fail to follow this recommendation, you risk damaging your vehicle. They disappear when the display selection key is pressed or after several seconds and are stored in the computer log.
  • Page 105 TRIP COMPUTER AND WARNING SYSTEM: warning message ® These appear with the warning light and require you to stop immediately, for your own safety, as soon as traf- fic conditions allow. Stop your engine and do not restart it. Contact an approved Dealer. Examples of warning messages are given in the following pages.
  • Page 106 VEHICLE SETTINGS CUSTOMISATION MENU (1/3) Adjusting the settings d) “Welcome”: – External welcome; Select a menu then the function to be – Automatic fold-out of mirrors; modified (the display depends on the – Interior welcome; vehicle equipment and country): – Courtesy light auto mode. a) “Driving”: Depending on the function, select: –...
  • Page 107 VEHICLE SETTINGS CUSTOMISATION MENU (2/3) Adjusting the settings d) “DRIVING ASSIST”: – Lane departure warning sound Navigate using the 4 or 5 control to volume; select the function to be modified and – Lane departure warning sensitiv- press 6 “OK” to confirm (display may ity;...
  • Page 108 VEHICLE SETTINGS CUSTOMISATION MENU (3/3) function activated < function deactivated Once a line has been selected, press 6 “OK" to adjust the function. If you select either “PARKING ASSIST” then “VOLUME”, or “DASHBOARD” then “LANGUAGE”, you will have to make a further selection (sound volume of the parking distance control or in- strument panel language).
  • Page 109 POWER-ASSISTED STEERING Never drive with an inadequately Note: the power-assisted steering de- charged battery. pends on the driving mode selected in the “MULTI-SENSE” menu (➥ 3.2). Variable power-assisted steering The variable power assisted steering system is equipped with an electronic control system which alters the level of assistance to suit the vehicle speed.
  • Page 110 CLOCK AND EXTERIOR TEMPERATURE (1/2) Vehicles fitted with a multimedia Vehicles not fitted with a multimedia Set the hour using control 3 or 4, then screen screen press 5 “OK” to confirm. The time and exterior temperature are Press the switch 2 as many times as re- Set the minutes using control 3 or 4, displayed on the multimedia screen 1.
  • Page 111 CLOCK AND EXTERIOR TEMPERATURE (2/2) External temperature indicator Depending on the vehicle, If the Special note: electrical supply is cut (battery dis- connected, broken supply wire, When the external temperature is be- etc.), the clock will automatically tween -3°C and +3°C, the °C figures go back to the right time after a few flash (indicates risk of ice).
  • Page 112 REAR VIEW MIRRORS (1/3) Folding rear view mirrors Welcome and goodbye function Refer to the multimedia instructions to The door mirrors automatically fold in access the welcome and goodbye func- when the vehicle is locked (switch 3 in tion. position B). Activate or deactivate the function by In any case, you can make the door selecting (ON or OFF).
  • Page 113 REAR-VIEW MIRRORS (2/3) Position memory Recalling the memorised position – Adjust the door mirrors (see previous paragraphs); Refer to the multimedia manual to – Refer to the multimedia instructions access recall of the saved position. to access the settings memory. Save Select “...
  • Page 114 REAR VIEW MIRRORS (3/3) Interior rear view mirror Special feature: When the rear-view mirror has been Rear view mirror with lever 4 manually deployed or folded back, it is possible to reset it to a usage position. When driving at night, to avoid being To do this, position the switch 3 to C.
  • Page 115 HEADLIGHT BEAM ADJUSTMENT Examples of positions for adjusting control A according to the load 5 doors Estate 4 doors Driver alone or with front passenger All seats occupied On vehicles fitted with this function, control A allows you to adjust the height Driver with passengers and of the beams according to the load.
  • Page 116 EXTERIOR LIGHTING AND SIGNALS (1/6) Depending on the vehicle, the dipped beam headlights will appear automati- cally after several sweeps of the wind- screen wiper blades. Side lights Dipped beam š headlights Turn ring 2 until the symbol is Manual operation opposite mark 3.
  • Page 117 EXTERIOR LIGHTING AND SIGNALS (2/6) During deactivation of the main beam The main beam headlights come on au- headlights, the dipped beam headlights tomatically if: return to their original position. – exterior light is weak; – no other vehicles or lighting are de- tected;...
  • Page 118 EXTERIOR LIGHTING AND SIGNALS (3/6) To deactivate automatic main beam headlights: – pull stalk 1; – or turn ring 2 to a position other than AUTO.  Warning light goes out on the in- strument panel. Note: make sure the windscreen is not obscured (dirt, mud, snow, condensa- tion, etc.).
  • Page 119 EXTERIOR LIGHTING AND SIGNALS (4/6) Lights-on reminder buzzer Welcome and goodbye function If the lights are on after the engine is (depending on the vehicle) switched off, a warning beep sounds when the driver’s door is opened to Once the function is activated, the day- warn you that the lights are still on.
  • Page 120 EXTERIOR LIGHTING AND SIGNALS (5/6) With the engine lights switched off, the 2 ring in AUTO, pull the lever 1 to- wards you: the side lights and dipped beam headlights will switch on for ap- proximately 30 seconds along with the š...
  • Page 121 EXTERIOR LIGHTING AND SIGNALS (6/6) Rear fog lights Switching off the lights  Turn centre ring 4 on the stalk Turn the centre ring 4again until the 3 until the symbol faces mark 3, then re- symbol is opposite the symbol for the lease it.
  • Page 122 WINDSCREEN WASH, WIPE (1/6) Efficiency of a wiper blade Check the condition of the wiper blades. How long they last depends on you: – it must remain clean: clean the blade and the screen regularly with soapy water; – do not use it when the screen is dry;...
  • Page 123 WINDSCREEN WASH, WIPE (2/6) When activating automatic wiping or when increasing sensitivity, one sweep of the blades is performed. Note: – the rain sensor is only intended as a driving aid. In the event of reduced visibility, the driver should manually activate the wipers.
  • Page 124 WINDSCREEN WASH, WIPE (3/6) Operating fault Special note In the event of a malfunction of the au- When driving the vehicle, the wiping tomatic wiping, the wiper is set to inter- speed slows down whenever the vehi- mittent wiping. Contact an authorised cle stops.
  • Page 125 WINDSCREEN WASH, WIPE (4/6) Specific front wiper position Note: after replacement, to reposition the blades correctly, make sure the (service position) blades are resting on the windscreen, This position enables the blades to be switch on the ignition and activate the lifted to remove them from the winds- wiper control.
  • Page 126 WINDSCREEN WASH, WIPE (5/6) Note: in temperatures below zero, the washer liquid may freeze on the wind- screen, reducing visibility. Heat the windscreen using the demister control before cleaning. Windscreen washer With the ignition on, pull stalk 1 then release. A brief pull will trigger a single sweep of the wipers, in addition to the wind- screen washer.
  • Page 127 WINDSCREEN WASH, WIPE (6/6) Note: to ensure the headlight wash- ers operate correctly in winter, remove snow from the jet trims and de-ice the jet trims using an aerosol de-icer. You are recommended to regularly remove dirt encrusted on the headlight glass.
  • Page 128 REAR SCREEN WASH, WIPE (1/2) To stop the operation, pivot ring 3 again. Note: when washing using a roller type car wash, return the ring 3 on the stalk 1 to the stop position to deactivate automatic wiping. Efficiency of a wiper blade Follow usage recommendations.
  • Page 129 REAR SCREEN WASH, WIPE (2/2) Activation/deactivation of the rear In the event of obstacles present on the screen wiper rear window (dirt, snow, etc.), the wiper will try to sweep away all the obstacles. Engaging reverse gear triggers inter- If an obstacle prevents the blade from mittent wiping (if the front wipers are in moving, it can be stopped.
  • Page 130 FUEL TANK (1/3) Fuel grade Useable tank capacity: For details on filling the fuel tank, refer to the information on “Filling with fuel” – About 11 gallons (50 litres) for Use a high-grade fuel that complies on the next page. petrol versions;...
  • Page 131 FUEL TANK (2/3) Filling with fuel With the ignition off, insert the nozzle to open valve 3 and insert it fully before turning it on to fill the fuel tank (risk of splashing). Keep the nozzle in this position through- out the entire filling operation.
  • Page 132 FUEL TANK (3/3) Running out of fuel on diesel versions Vehicles with key/remote control No modifications what- – Set the ignition key to the “ON” posi- soever are permitted on tion 2 ➥ 2.3 and wait a few minutes any part of the fuel supply before starting to enable the fuel cir- system (electronic units, cuit to be primed;...
  • Page 133 REAGENT TANK (1/4) Please ensure that you comply with the legislation of your country. It is impor- tant to remember that failure to respect regulations in force could lead to legal Vehicle fitted with the Stop and action being taken against the vehicle Start function owner.
  • Page 134 REAGENT TANK (2/4) Filling (continued) If the reagent overflows, or contami- nates any paintwork, clean the affected The tank can be filled at the pump. With area quickly with plenty of cold water the ignition off, insert the nozzle and and a soft cloth.
  • Page 135 REAGENT TANK (3/4) Maintenance/Range The information displayed on the instrument panel may be accompanied by a beep. Indicator Message What to do? lights – “AdBlue Level Correct” – When the message is displayed when the ignition is switched on, you have less than 1,488 miles (2,400 km) range. –...
  • Page 136 REAGENT TANK (4/4) System fault When the indicator lights light up, this may be accompanied by a beep. Indicator lights Message Readings “Check anti-pollution system” Indicates a fault in the system. Contact your approved  “AdBlue quality to check” © dealer as soon as possible.
  • Page 137 Section 2: Driving Running in ..............Ignition switch .
  • Page 138 RUNNING IN Petrol version Diesel version For the first 600 miles (1,000 km), do For the first 1,000 miles (1,500 km), not exceed 78 mph (130 km/h) in the do not exceed 80 mph (130 km/h) in highest gear, or 3,000 to 3,500 rpm. the highest gear, or 2,500 rpm.
  • Page 139 IGNITION SWITCH: vehicle with key “ON" 2 position The ignition is switched on: Accessories (radio etc.) can be used. “START" 3 position If the engine fails to start at the first attempt, the key must be turned back before the starter can be activated again.
  • Page 140 STARTING, STOPPING THE ENGINE: vehicle with key É Stopping the engine Diesel versions With the engine idling, turn the key – Turn the ignition key to the “ON" po- back to the “LOCK" position 0. sition 2 and hold this position until the engine preheating light goes off;...
  • Page 141 STARTING, STOPPING THE ENGINE: vehicle with card (1/3) “Hands-free” starting with the tailgate open In this case, the card should not be lo- cated in the luggage compartment, to prevent the risk of loss. Driver’s responsibility when parking or stopping the vehicle Never leave an animal, child or adult who is not self-suffi-...
  • Page 142 STARTING, STOPPING THE ENGINE: vehicle with card (2/3) Press the brake or clutch pedal, then place the card 3 (button side) during approximately two seconds on the placement area 4. Press the 2 button to start the vehicle. The message goes out. Accessories function Operating faults (switching on the ignition)
  • Page 143 STARTING, STOPPING THE ENGINE: vehicle with card (3/3) If the card is no longer in the passenger When you leave your vehi- compartment when you try to switch cle, especially if you have the engine off, the message “Keycard your card with you, check absent : press/hold START”...
  • Page 144 FUNCTION STOP AND START (1/4) This system enables a reduced fuel The vehicle equipment remain opera- consumption and lower greenhouse – when the vehicle speed is zero tional while the engine is stopped. gas emissions. The system is acti- during approximately one second or, When the engine switches to standby, vated automatically when the vehicle depending on the vehicle, as soon...
  • Page 145 FUNCTION STOP AND START (2/4) Preventing the engine from Conditions for coming out of standing by engine standby In certain situations, such as negotiat- For vehicles equipped with auto- ing a crossroads for instance, it is pos- matic gearboxes: sible (with the system activated) to keep –...
  • Page 146 FUNCTION STOP AND START (3/4) Conditions preventing the For vehicles equipped with manual – the gradient is too steep for vehicles gearboxes: fitted with an automatic gearbox; standby of the engine – when opening the driver’s door, with- – the “Clear view” function is activated Certain conditions prevent the system out any gear engaged and the clutch ➥...
  • Page 147 FUNCTION STOP AND START (4/4) Deactivating, activating the Special feature of the automatic engine re-start function Under certain conditions, the engine Press 1 to deactivate the function. The can restart on its own in order to guar- message “Stop & Start deactivated” antee your safety and comfort.
  • Page 148 SPECIAL FEATURES OF PETROL VERSIONS (1/2) The following operating conditions: If you notice any of the above operating faults, have the necessary repairs car- – driving for long periods when the low ried out as soon as possible by an ap- fuel level warning light is lit;...
  • Page 149 SPECIAL FEATURES OF PETROL VERSIONS (2/2) Particle filter Note: The indicator light may go out If the filter becomes saturated, the © after 20 minutes when the driving con- warning light and, depending The particle filter is used in the treat- ...
  • Page 150 SPECIAL FEATURES OF DIESEL VERSIONS (1/2) Diesel engine speed Precautions to be taken in winter Diesel engines are fitted with an injec- tion pump which prevents the engine To avoid any faults in icy weather: speed being exceeded irrespective of –...
  • Page 151 SPECIAL FEATURES OF DIESEL VERSIONS (2/2) Particle filter Note: the warning light may re-appear If the filter becomes saturated, the © if the driving conditions are not suitable warning light and, depending The particle filter is used in the treat- ...
  • Page 152 GEAR LEVER, HANDBRAKE Handbrake To apply: Pull lever 3 upwards. Check that the To release: vehicle is immobilised. The warning Pull the lever 3 up slightly, press light on the instrument panel will button 2 and then lower the lever to the come on.
  • Page 153 ELECTRONIC PARKING BRAKE (1/4) In all other instances, for example the engine has stalled or is in standby due to the Stop and Start function ➥ 2.8, the assisted parking brake is not applied automatically. Manual mode must be used. For certain country-specific model ver- sions, the assisted brake application function is not activated.
  • Page 154 ELECTRONIC PARKING BRAKE (2/4) Assisted release of the parking brake The parking brake is released: – once the vehicle starts to accelerate; – if the vehicle is equipped with an au- tomatic gearbox, the parking brake is released when the gearbox exits the “Park”...
  • Page 155 ELECTRONIC PARKING BRAKE (3/4) To park the vehicle without applying the electronic parking brake (if there is a risk of freezing, for example): – switch off the engine by pressing the engine start/stop button 1 or by turn- ing the ignition key 2; –...
  • Page 156 ELECTRONIC PARKING BRAKE (4/4) Versions with an automatic Operating faults gearbox © – If there is a fault, the warning light illuminates on the instrument For safety reasons, automatic release panel accompanied by the “Check is deactivated when the driver’s door Parking Brake”...
  • Page 157 “AUTOHOLD" FUNCTION Vehicle stopped (e.g. at a red light, an Conditions for interrupting the intersection, a traffic jam, etc.), the func- braking force tion ensures braking force even when The following conditions must be met: the driver releases the brake pedal. –...
  • Page 158 DRIVING ADVICE, ECO-DRIVING (1/8) Fuel consumption is accredited in ac- Depending on the vehicle, you will have Free-wheel function cordance with a standard regulatory various functions which enable you to On vehicles fitted with an automatic method. Identical for all manufactur- lower your fuel consumption: gearbox (depending on the vehicle), ers, this enables vehicles to be com-...
  • Page 159 DRIVING ADVICE, ECO-DRIVING (2/8) On the instrument panel A, B Gear change indicator 1 or C Depending on the vehicle, to obtain op- timum consumption levels, a warning Depending on the vehicle, the informa- light on the instrument panel lets you tion display can be organised and cus- know the best time to move up or down tomised based on the instrument panel...
  • Page 160 DRIVING ADVICE, ECO-DRIVING (3/8) Driving style indicator 2 Informs you about the driving style adopted in real time. This is shown by indicator light 2. The more petals displayed on 2, the more your driving is flexible and eco- nomical. If you regularly monitor this indicator, you will reduce your vehicle’s fuel con- sumption.
  • Page 161 DRIVING ADVICE, ECO DRIVING (4/8) Acceleration indicator Eco 3 This informs you in real time whether you are accelerating moderately or strongly. This is shown by the 3 warning light: – green: acceleration is moderate and correct; – white: acceleration is too high; –...
  • Page 162 DRIVING ADVICE, ECO DRIVING (5/8) An overall rating from 0 to 100 is dis- played to let you assess your eco driv- ing performance. The higher the rating, the lower the fuel consumption. Eco advice is given to help improve your performance.
  • Page 163 DRIVING ADVICE, ECO-DRIVING (6/8) ECO mode While driving, it is possible to exit the ECO mode temporarily in order to im- ECO mode is a function which opti- prove engine performance. To do this, mises fuel consumption. It affects cer- press the accelerator pedal firmly and tain driving operations (acceleration, fully.
  • Page 164 DRIVING ADVICE, ECO-DRIVING (7/8) – Do not overrev the engine in the in- – Bad weather, flooded roads: termediate gears. You should always use the highest Do not drive through gear possible. floods if the water is – Avoid sudden acceleration. above the lower edge of –...
  • Page 165 DRIVING ADVICE, ECO-DRIVING (8/8) – In vehicles fitted with air condi- tioning, it is normal to observe an increase in fuel consumption (espe- cially in urban conditions) when it is used. For vehicles fitted with manual air conditioning, switch off the system when it is not required.
  • Page 166 MAINTENANCE AND ANTIPOLLUTION ADVICE Your vehicle complies with criteria for In addition, replacing engine, fuel – Air filter, fuel filter: a choked ele- recycling and recovering vehicles at the supply system and exhaust compo- ment will reduce efficiency. It must end of their service life, which entered nents with parts other than those origi- be replaced.
  • Page 167 ENVIRONMENT Emissions Your vehicle has been designed with – At the end of the vehicle’s service respect for the environment in mind for life, it should be sent to approved Your vehicle has been designed to its entire service life: during production, centres to ensure that it is recycled.
  • Page 168 TYRE PRESSURE LOSS WARNING (1/6) Operating principle When fitted to the vehicle, this system notifies the driver if one or more tyres This system detects a loss of pressure lose pressure. in one of the tyres by measuring the The system can be identified by the 1 wheel speed while driving.
  • Page 169 TYRE PRESSURE LOSS WARNING (2/6) Operating conditions Resetting the standard level – significant change in load or distribu- tion of load on one side of the vehi- for the tyre pressures The system should be reset with a cle; pressure equal to that stated on the tyre This should be done: –...
  • Page 170 TYRE PRESSURE LOSS WARNING (3/6) Hold down the 5 switch until the “Operation completed” message ap- pears. You can now drive. Resetting procedure Ignition on, vehicle stopped: – repeatedly tap the 6 switch as many times as necessary to reach the “ve- ...
  • Page 171 TYRE PRESSURE LOSS WARNING (4/6) The table below shows the possible messages related to the tyre resetting procedure. Steps Messages Readings – Tyre pressure init. at stop The message is displayed during driving. If you want to reset the pressure of the four tyres, stop the vehicle.
  • Page 172 TYRE PRESSURE LOSS WARNING (5/6) Readjustment of tyre After each change of wheel/tyre, read- just the tyre pressure and launch the pressures reset of the tyre pressure reference The pressure of the four tyres must value. be set when cold (refer to the label lo- cated on the edge of the driver’s door).
  • Page 173 TYRE PRESSURE LOSS WARNING (6/6) The information on the instrument panel signals any potential tyre pressure faults (e.g. deflated or punctured tyre). Indicator Messages Readings lights This indicates that tyre under-inflation or puncture has been detected.  Inflate tyres and init. Check and adjust the pressure of the four tyres when cold and reset the system.
  • Page 174 TYRE PRESSURE MONITOR (1/5) Resetting the standard level for the tyre pressures This should be done: – when the standard tyre pressure needs to be changed to adapt to usage conditions (empty, carrying a load, motorway driving, etc.); – after swapping a wheel (however this practice is not recommended);...
  • Page 175 TYRE PRESSURE MONITOR (2/5) – press and hold (around 3 seconds) the button 4 to launch the reset. The flashing tyres followed by the mes- sages “Learning Tyre Pressures” and then “Tyres location in progress” indicates that the reset request for the tyre pressure reference value has been acknowledged.
  • Page 176 TYRE PRESSURE MONITOR (3/5) The table below shows the possible messages related to the tyre resetting procedure. Steps Displays Messages Readings Tyre pressure init. long press With the ignition on and the vehicle stationary, start the resetting the pressure of all four tyres by pressing and holding the 4 OK switch.
  • Page 177 TYRE PRESSURE MONITOR (4/5) Readjustment of tyre Replacing wheels/tyres pressures This system requires specific equip- ment (wheels, tyres, hubcaps, etc.). The pressure of the four tyres must ➥ 5.13. be set when cold (refer to the label lo- Contact an approved Dealer to fit new cated on the edge of the driver’s door).
  • Page 178 TYRE PRESSURE MONITOR (5/5) The information on the instrument panel signals any potential tyre pressure faults (e.g. deflated or punctured tyre). For ® your safety, the warning light requires you to stop immediately as soon as traffic conditions allow. Indicator lights Messages Displays Readings...
  • Page 179 DRIVER CORRECTION DEVICES AND AIDS (1/6) ABS (anti-lock braking Depending on the vehicle, this is com- posed of: system) In an emergency, apply firm and – ABS (anti-lock braking system); Under heavy braking, the ABS prevents continuous pressure to the brake the wheels from locking, allowing the –...
  • Page 180 DRIVER CORRECTION DEVICES AND AIDS (2/6) Operating faults: © – lit up on the in- strument panel accompanied by the messages “Check ABS”, “Check braking system” and “Check ESC”: this indicates that the ABS, the ESC and the emergency brake assist are disabled.
  • Page 181 DRIVER CORRECTION DEVICES AND AIDS (3/6) Electronic stability control Understeer control Operating faults ESC with understeer control This system optimises the action of the When the system detects an operat- and traction control ESC in the case of pronounced under- ing fault the message “Check ESC”...
  • Page 182 DRIVER CORRECTION DEVICES AND AIDS (4/6) Emergency brake assist Braking anticipation Depending on the vehicle, when you This system supplements the ABS rapidly release the accelerator, the and helps reduce vehicle stopping dis- system anticipates the braking ma- tances. noeuvre in order to reduce stopping Operating principle distances.
  • Page 183 DRIVER CORRECTION DEVICES AND AIDS (5/6) Hill start assistance The hill start assistance Depending on the gradient of the in- system cannot completely cline, this system assists the driver prevent the vehicle from when starting on a hill. It prevents the rolling backwards in all sit- vehicle from rolling backwards by au- uations (extremely steep gradients,...
  • Page 184 DRIVER CORRECTION DEVICES AND AIDS (6/6) Operating faults © – If the warning light, together with the message “Check power steering”, is displayed on the instru- ment panel: please contact an au- thorised dealer. ® – If the warning light , together with the message “WARNING: Power Steering”, is displayed on the...
  • Page 185 LANE DEPARTURE WARNING (1/5) Using information from the 1 camera, the function warns the driver when a continuous or broken line is crossed or when approaching the roadside (di- vider, barrier, pavement, embankment, etc.) without the direction indicator lights being activated. This function is an addi- tional driving aid.
  • Page 186 LANE DEPARTURE WARNING (2/5) To disable the function, press the 2 switch as many times as required to select “Lane departure warning off” (or, depending on the vehicle “Lane Keeping deactivated”) on the instru-  ment panel. Warning light goes out on the instrument panel.
  • Page 187 LANE DEPARTURE WARNING (3/5) Temporarily not available Conditions for non-activation of the system – Very fast lane departure; The system cannot be activated when: – driving continuously on a line; – reverse gear is engaged; – four seconds approximately after changing lanes;...
  • Page 188 LANE DEPARTURE WARNING (4/5) Operating faults – press the 6 or 7 control repeatedly to reach the “DRIVING ASSIST” menu. In the event of a malfunction, the left Press the switch 8 OK; and right line indicators (and, depend-  –...
  • Page 189 LANE DEPARTURE WARNING (5/5) This function is an additional driving aid. This function is not under any circumstances intended to replace the due care and attention of the driver, who should at all times be in control of the vehicle. System servicing/repairs –...
  • Page 190 LANE KEEPING ASSIST (1/6) Note: make sure the windscreen is not obscured (dirt, mud, snow, condensa- tion etc.). Using information from the 1 camera, the function triggers corrective action on the vehicle steering system when a continuous or broken line is crossed or when approaching the roadside (di- vider, barrier, pavement, embankment, etc.) without the direction indicator...
  • Page 191 LANE KEEPING ASSIST (2/6) To disable the function, press the 2 switch as many times as required to select “Lane Keeping deactivated” on the instrument panel.  Warning light goes out on the in- strument panel. Note: deactivating the “Lane Keeping Assist”...
  • Page 192 LANE KEEPING ASSIST (3/6) In these cases: Special cases – the function triggers an action on the When using the function: vehicle’s steering system to correct – If the system can no longer detect the vehicle trajectory; any action by the driver on the steer- ...
  • Page 193 LANE KEEPING ASSIST (4/6) Temporarily not available Conditions for non-activation of the system – Very fast lane departure; – driving continuously on a line; The system cannot be activated when: – four seconds approximately after – reverse gear is engaged; changing lanes;...
  • Page 194 LANE KEEPING ASSIST (5/6) Operating faults – press the 6 or 7 control repeatedly to reach the “DRIVING ASSIST” menu. When the system detects an operating Press the switch 8 OK; © fault, the warning light appears – press the 6 or 7 control repeatedly on the instrument panel along with the to reach the “Lane Keeping sensitiv- message “Check Front camera”.
  • Page 195 LANE KEEPING ASSIST (6/6) This function is an additional driving aid. This function is not under any circumstances intended to replace the due care and attention of the driver, who should at all times be in control of the vehicle. System servicing/repairs –...
  • Page 196 BLIND SPOT WARNING (1/7) Special feature Using information from the sensors in- stalled on each side of the rear bumper Make sure that the radar area C is not (area C), the function warns the driver: obscured (by stickers, mud, snow etc.). –...
  • Page 197 BLIND SPOT WARNING (2/7) – press the switch 5 OK again to acti- vate or deactivate the function: function activated < function deactivated Activation/deactivation – press the 3 or 4 control repeatedly to reach the “Settings” menu. Press the Vehicles fitted with a multimedia switch 5 OK;...
  • Page 198 BLIND SPOT WARNING (3/7) Indicator 6 Operation An indicator light 6 is located on each The function warns you when the speed rear view mirror 7. of your vehicle exceeds approximately 9 mph (15 km/h): Note: clean the rear view mirrors 7 reg- –...
  • Page 199 BLIND SPOT WARNING (4/7) Display E Conditions for non-function Direction indicator activated, the 6 – When driving on a road with tight warning light flashes when the func- bends; tion detects a vehicle in the blind spot – in reverse. warning area and/or a vehicle is rapidly If the vehicle is equipped with a towbar approaching from the rear on the side...
  • Page 200 BLIND SPOT WARNING (5/7) Operating faults If the system detects a fault, the mes- sage “Check Side radars” is displayed on the instrument panel. Consult an ap- proved dealer. – The system’s detection range operates according to a standard lane width. If you are driving in wide traf- fic lanes, the system might not be able to detect a vehicle in the...
  • Page 201 BLIND SPOT WARNING (6/7) This function is an additional driving aid. This function is not under any circumstances intended to replace the due care and attention of the driver, who should at all times be in control of the vehicle. The driver should always adapt their speed to the traffic conditions, regardless of the system indications.
  • Page 202 BLIND SPOT WARNING (7/7) Limitation of the system operation – The radar area should be kept clean and free of any modifications in order to ensure the proper operation of the system. – Small objects moving close to the vehicle (motorcycles, bicycles, pedestrians, etc.) may not be recognised by the system. –...
  • Page 203 SAFE DISTANCE ALERT (1/4) The function is activated when the vehi- cle speed is between about 19 and 124 mph (30 and 200 km/h). Location of the camera 1 Make sure the windscreen is not ob- scured (by dirt, mud, snow, condensa- tion etc.).
  • Page 204 SAFE DISTANCE ALERT (2/4) – press the 5 or 6 control repeatedly to reach the “Distance warning” menu. Press the switch 7 OK; – press the switch 7 OK again to acti- vate or deactivate the function: function activated < function deactivated Activating/deactivating the Vehicles not fitted with a multimedia...
  • Page 205 SAFE DISTANCE ALERT (3/4) – C (orange): the time interval falls be- tween around 1 and 2 seconds (in- sufficient distance between the two vehicles); – D (red): the time interval is less than or equal to around one second (very insufficient distance between the two The measurement is dis- vehicles).
  • Page 206 SAFE DISTANCE ALERT (4/4) This function is an additional driving aid. This function is not under any circumstances intended to replace the due care and attention of the driver, who should at all times be in control of the vehicle. System servicing/repairs –...
  • Page 207 ACTIVE EMERGENCY BRAKING (1/8) Depending on the reactivity of the driver, the system can assist with brak- ing in order to limit damage or prevent a collision. Location of the camera 1 Make sure the windscreen is not ob- scured (by dirt, mud, snow, condensa- tion etc.).
  • Page 208 ACTIVE EMERGENCY BRAKING (2/8) Operation Special features of warnings Depending on the speed, the warning Detection of vehicles and braking may be activated simulta- When driving, in the event of a risk of neously. collision with the vehicle in front the Special features of stationary system will: vehicles...
  • Page 209 ACTIVE EMERGENCY BRAKING (3/8) Detection of pedestrians and Special features of warnings cyclists Depending on the speed, the warning (depending on the vehicle) and braking may be activated simulta- When there is a risk of collision with a neously. cyclist or pedestrian while the vehicle is moving, the system will: –...
  • Page 210 ACTIVE EMERGENCY BRAKING (4/8) – press the 6 or 7 control repeatedly to reach the “Active braking” menu and press the 8 OK switch. Press the switch 8 OK again to activate or deactivate the function: function activated < function deactivated Upon deactivation of the system, the ...
  • Page 211 ACTIVE EMERGENCY BRAKING (5/8) Temporarily not available Operating faults  If the system detects a temporary ©  or, depending on the  fault the warning light illumi- vehicle, illuminated on the instru- nates, or depending on the vehicle the ...
  • Page 212 ACTIVE EMERGENCY BRAKING (6/8) Active emergency braking This function is an additional driving aid. This function is not under any circumstances intended to replace the due care and attention of the driver, who should at all times be in control of the vehicle. The triggering of this function may be delayed or prevented when the system detects clear signs of control of the vehicle by the driver (action on the steer- ing wheel, pedals etc.).
  • Page 213 ACTIVE EMERGENCY BRAKING (7/8) System disturbance Some conditions can disturb or damage the operation of the system, such as: – a complex environment (metal bridge, tunnel etc.); – poor weather conditions (snow, hail, black ice etc.); – poor visibility (night, fog etc.); –...
  • Page 214 ACTIVE EMERGENCY BRAKING (8/8) Deactivating the function You must disable the function if: – the brake lights are not functioning; – the area of the camera has been damaged (e.g. on the inside or outside of the windscreen); – the front of the vehicle was damaged (impact, scratch on the radar, etc.); –...
  • Page 215 FATIGUE DETECTION WARNING (1/2) The fatigue detection warning is a func- tion which is useful on monotonous roads (motorways, high-speed roads etc.). It analyses driver behaviour and takes account of events to inform you of any risk of fatigue such as: –...
  • Page 216 FATIGUE DETECTION WARNING (2/2) – repeatedly press the control 3 up or Note: down until you reach the “Fatigue – if the warning is not deleted by press- detection warning” menu, then press ing switch 2 OK, the beep repeats; the switch 2 OK.
  • Page 217 DETECTION OF ROAD SIGNS (1/4) Note: make sure the windscreen is not For vehicles equipped with a navigation obscured (dirt, mud, snow, condensa- system and if the vehicle is travelling in tion etc.). a country where the speed units differ from those of the vehicle, the system For vehicles which are equipped with it, displays the speed limit sign in the unit...
  • Page 218 DETECTION OF ROAD SIGNS (2/4) – press the 4 or 5 control repeatedly to reach the “Settings” menu and press 6 OK; – press the 4 or 5 control repeatedly to reach the “DRIVING ASSIST” menu and press 6 OK; –...
  • Page 219 DETECTION OF ROAD SIGNS (3/4) If the speed limit is exceeded, the circle around the panel flashes (7 warning light) along with a sound signal to warn the driver. Operation Varying the limit speed If the speed limit notification differs from Warning lights the detected speed value, press and The function displays the following...
  • Page 220 DETECTION OF ROAD SIGNS (4/4) Operating faults The system cannot detect the speed limit if: – the windscreen is not clean; – the camera is blinded by the sun; – there is insufficient visibility (night, fog etc.); – the signs are not legible (snow, etc.) or are hidden (by another vehicle or by trees);...
  • Page 221 SPEED LIMITER (1/4) Controls The speed limiter function helps you stay within the driving speed limit that 1 Speed limiter On/Off switch. you choose, known as the limit speed. 2 Cruise control On/Off switch. Depending on the vehicle, the speed limiter is linked with the “Hill Descent 3 Switch to activate and decrease the Control”...
  • Page 222 SPEED LIMITER (2/4) Driving Switching on To store the current speed, press the 4 switch (RES/+) or the 3 switch (SET/-  ) : When a limit speed has been set but Press switch 1. The 7 warning light ap- the limit speed replaces the dashes not yet reached, driving is similar to pears in grey.
  • Page 223 SPEED LIMITER (3/4) Exceeding the limit speed Limited speed cannot be maintained When driving down a steep gradient, It is possible to exceed the limit speed the system may not maintain the limit at any time. To do this: press the accel- speed: the limit speed flashes in red erator pedal firmly and fully (beyond on the instrument panel and an audi-...
  • Page 224 SPEED LIMITER (4/4) Putting the function on Switching off the function standby The speed limiter function is inter- rupted: The speed limiter function is suspended when you press switch 5 (0). The limit – when you press the 1 switch. In this speed is stored and displayed in grey case, the speed is no longer stored;...
  • Page 225 CRUISE CONTROL (1/5) 4 Switch the function to standby (with cruising speed saved) (0). 5 Speed limiter On/Off switch. This function is an addi- tional driving aid. The func- tion does not take the place of the driver. Therefore, it can under no circum- The cruise control function helps you to The presence of the “Hill Descent stances replace the driver’s respon-...
  • Page 226 CRUISE CONTROL (2/5) Switching on Activating cruise control Driving Press switch 1. While the vehicle is moving a steady Once a cruising speed is registered speed above approximately 19 mph and the cruise control function is active, The 7 warning light appears in grey. (30 km/h), press the 2 (SET/-) switch you may lift your foot off the accelera- The “Cruise control ON”...
  • Page 227 CRUISE CONTROL (3/5) Exceeding the cruising speed The cruising speed may be exceeded at any time by depressing the accelera- tor pedal. While it is being exceeded, the cruising speed flashes in red on the instrument panel. Cruise control with cruising speed maintained during gear Then, release the accelerator pedal: changing:...
  • Page 228 CRUISE CONTROL (4/5) Putting the function on Returning to the cruising speed NB: if the speed previously stored is much higher than the current speed, standby If a speed is stored, it can be recalled, the vehicle will accelerate more rapidly once you are sure that the road condi- The function is set to standby if you: to reach this threshold.
  • Page 229 CRUISE CONTROL (5/5) Switching off the function The warning light 7 disappears from the instrument panel to confirm that the The cruise control function is inter- function is no longer active. rupted: – when you press the 1 switch. In this case, the speed is no longer stored;...
  • Page 230 ADAPTIVE CRUISE CONTROL (1/13) Based on information from a radar According to conditions on the road This function is an addi- or camera, the adaptive cruise con- (traffic, weather etc.), the adaptive tional driving aid. The func- trol function (or Stop and Go adap- cruise control function can be activated: tion does not take the place tive cruise control function on vehicles...
  • Page 231 ADAPTIVE CRUISE CONTROL (2/13) Location of the camera 1 Controls 6 Cruising speed activation, storage and decrease switch (SET/-). Make sure the windscreen is not ob- 3 Safe distance settings 7 Switch to activate and increase cruis- scured (by dirt, mud, snow, condensa- 4 Switch the function to standby (with ing speed or to recall the memorised tion etc.).
  • Page 232 ADAPTIVE CRUISE CONTROL (3/13) Switching on The cruising speed 11 replaces the dashes and cruise control is confirmed Press switch 5. by the appearance of the cruising Warning light  appears in grey, and speed in green and warning light ...
  • Page 233 ADAPTIVE CRUISE CONTROL (4/13) Safe distance control activation As soon as cruise control is activated, the default safe distance 10 is displayed in green on the instrument panel. The default safe distance corresponds to approximately two seconds (see follow- ing pages). If the system detects a vehicle in your lane, an outline of a vehicle 9 appears above the distance gauge 10 on the in-...
  • Page 234 ADAPTIVE CRUISE CONTROL (5/13) Adjusting the safe distance (cont.) – distance gauge B: intermediate dis- tance 2 (corresponding to approxi- mately 2 seconds); – distance gauge C: intermediate dis- tance 1 (corresponding to approxi- mately 1.6 seconds); – distance gauge D: short distance (corresponding to approximately 1.2 seconds).
  • Page 235 ADAPTIVE CRUISE CONTROL (6/13) Stopping and starting on Putting the function on vehicles fitted with an standby automatic gearbox You can set the function to standby If the vehicle in front slows down, the when: system adapts its speed to a complete –...
  • Page 236 ADAPTIVE CRUISE CONTROL (7/13) Exit from standby Depending on the situation, the system sounds a beep associated with: Based on the stored cruising speed – the orange alert E if the situation re- If a speed is stored, it can be recalled, quires the driver’s attention;...
  • Page 237 ADAPTIVE CRUISE CONTROL (8/13) Operating faults If the radar detection area is obstructed or the radar signal is disrupted, the If an adaptive cruise control function message “Front radar no visibility” is operating fault is detected, the mes- displayed on the instrument panel and sage “Check Adaptive Cruise control”...
  • Page 238 ADAPTIVE CRUISE CONTROL (9/13) Limitations of system The system cannot detect: Detection during cornering operation – vehicles arriving at intersections: slip When entering a corner or bend, the roads (e.g. H) ; radar and/or camera may temporarily Vehicle detection not be able to detect the vehicle in front –...
  • Page 239 ADAPTIVE CRUISE CONTROL (10/13) Detection of vehicles in adjacent Vehicles hidden due to variations in – vehicles transporting long objects lanes ground relief which exceed the line; The system may detect vehicles driving The system will not detect vehicles – the actual length of tall vehicles on an adjacent lane when: hidden due to variations in ground relief (e.g.
  • Page 240 ADAPTIVE CRUISE CONTROL (11/13) Stationary and slow moving – vehicles in front12 which change Non-detection of fixed obstacles vehicles lane, revealing a stationary vehi- and objects of a small size cle 13 (e.g. P). The system cannot detect: When your speed is over approximately 31 mph (50 km/h), the system does –...
  • Page 241 ADAPTIVE CRUISE CONTROL (12/13) This function is an additional driving aid. It can under no circumstances replace the driver’s responsibility to respect speed limits and safe distances and to be vigilant. The driver must always be in control of the vehicle. The driver must always adapt their speed to the surroundings and driving conditions, regardless of system indications.
  • Page 242 ADAPTIVE CRUISE CONTROL (13/13) In the event of system disturbance Some conditions can disturb or damage the operation of the system, such as: – the windscreen or bumper is obscured in the area of the radar (by dirt, ice, snow, condensation, number plate etc.); –...
  • Page 243 PARKING DISTANCE CONTROL (1/5) Operating principle Ultrasonic sensors in the rear bumper measure the distance between the ve- hicle and an obstacle. This measurement is indicated by beeps which become more frequent the closer you come to the obstacle, until they become a continuous beep when the vehicle is approximately 20 to This function is an addi-...
  • Page 244 PARKING DISTANCE CONTROL (2/5) Operation Note: the display 2 shows the vehicle surroundings and emits beeps. Most objects located less near the It is necessary to travel a few metres front, rear and sides of the vehicle are before the side detection is activated. detected.
  • Page 245 PARKING DISTANCE CONTROL (3/5) If a side obstacle is detected: – the beeps become faster and then sound continuously as the obstacle gets nearer. Green, orange and red zones will be displayed on the dis- play D; – if there is no risk of collision, no beep will sound when approaching the ob- stacle.
  • Page 246 PARKING DISTANCE CONTROL (4/5) Vehicles not fitted with a multimedia screen With the vehicle stopped, press the 6 switch to deactivate parking distance control. Warning light 5 in the switch lights up. Press again on the 6 switch to activate the function. The indicator light built into the 5 switch goes out.
  • Page 247 PARKING DISTANCE CONTROL (5/5) Operating faults – select “BIP VOLUME” to adjust the volume of the parking distance con- When the system detects an operating trol using the 8 or 9 control. fault, a beep sounds for approximately 3 seconds each time reverse gear is se- Deactivating the parking lected and is accompanied by the mes- sage “Check parking sensor”...
  • Page 248 REVERSING CAMERA (1/2) Special feature The 1 rear view camera is located on the luggage compartment lid. Make sure that the 1 camera is not ob- scured (by dirt, mud, snow, condensa- tion etc.). This function is an additional aid. It cannot, therefore, under any circum- stances replace the vigilance or the responsibility of the driver.
  • Page 249 REVERSING CAMERA (2/2) 4 moving guide line: This is shown in blue on the multime- dia screen 2. It indicates the vehicle tra- jectory according to the position of the steering wheel. Activating, deactivating the reversing camera To activate or deactivate the function via the multimedia screen 2, refer to the multimedia instructions.
  • Page 250 PARKING EXIT WARNING (1/4) Special feature Using information from the radars in- stalled on each side of the rear bumper Make sure that the radar area A is not (area A), the system notifies the driver obscured (by stickers, mud, snow etc.). The system’s detection capability when another vehicle appears in the If a radar is obscured, the message...
  • Page 251 PARKING EXIT WARNING (2/4) Activation/deactivation from Operation The indicators 4 on the multimedia screen show you on which side the ap- the multimedia screen 1 The function warns you if a vehicle is in proaching vehicle has been detected. area B and is approaching your vehicle. To activate or deactivate the function, Note: clean the camera regularly so refer to the multimedia instructions.
  • Page 252 PARKING EXIT WARNING (3/4) Operating faults If the system detects a fault, the mes- sage “Check Side radars” is displayed on the instrument panel. Consult an ap- proved dealer. Limitation of the system operation – The radar area should be kept clean and free of any modifications in order to ensure the proper operation of the system.
  • Page 253 PARKING EXIT WARNING (4/4) This function is an additional driving aid. This function is not under any circumstances intended to replace the due care and attention of the driver, who should at all times be in control of the vehicle. The system should under no circumstances be taken to be an obstacle detector or an anti-collision system.
  • Page 254 ASSISTED PARKING (1/5) Switching on Special features Using ultrasonic detectors as indicated by the 3 arrows installed in the vehicle With the vehicle stationary or driving Ensure that the ultrasonic sensors indi- bumpers, this function helps to find ac- at less than approximately 19 mph cated by the arrows 3 are not obscured cessible parking spaces and assists in (30 km/h):...
  • Page 255 ASSISTED PARKING (2/5) Operation Note: when starting the vehicle, or after having successfully completed parallel Parking parking using the system, the default manoeuvre proposed by the system is As long as the vehicle speed is less assistance in exiting a parallel parking than 19 mph (30 km/h), the system space.
  • Page 256 ASSISTED PARKING (3/5) The space is then indicated on the mul- – Release the steering wheel; timedia screen by a capital letter “P”. – carry out manoeuvres at the front – Stop the vehicle; and rear by following the instructions shown on the multimedia screen 1 –...
  • Page 257 ASSISTED PARKING (4/5) Cancelling the manoeuvre The switch warning light 2 goes out,  The manoeuvre is cancelled in the fol- warning light disappears lowing cases: from the instrument panel and an au- dible signal confirms that the manoeu- – the vehicle speed has exceeded 4 vre has been suspended.
  • Page 258 ASSISTED PARKING (5/5) This function is an additional driving aid. This function is not under any circumstances intended to replace the due care and attention of the driver, who should at all times be in control of the vehicle. Make sure that the manoeuvre complies with the applicable traffic regulations in your location.
  • Page 259 AUTOMATIC TRANSMISSION (1/3) Selector lever 1 Operation P: park With the selection lever 1 in position P, switch on the ignition. R: reverse To move out of position P, you must de- N: Neutral press the brake pedal before pressing D: automatic mode the unlocking button 2.
  • Page 260 AUTOMATIC TRANSMISSION (2/3) Driving in automatic mode Driving in manual mode Special circumstances With the selector lever in position D, Put lever 1 into position D. – If the bends and road surface do move the lever to the left into the M po- not allow you to stay in automatic In most road conditions you will en- sition.
  • Page 261 AUTOMATIC TRANSMISSION (3/3) Parking the vehicle Maintenance period When the vehicle is stopped, move the Refer to the maintenance document lever to position P while keeping your for your vehicle or consult an Approved foot on the brake pedal: the gearbox is Dealer to check whether the automatic in neutral and the drive wheels are me- gearbox requires scheduled mainte-...
  • Page 262 EMERGENCY CALL (1/3) If the vehicle is equipped with it, the emergency call system enables auto- matic or manual calling of the emer- gency services in the event of an ac- cident or illness, in order to reduce the emergency response time. If you use the emergency call function to report an accident which you have witnessed, this implies stopping where...
  • Page 263 EMERGENCY CALL (2/3) Automatic mode In the event of unintended operation, it is possible to cancel the call by press- If the automatic mode 2 warning light ing the 3 button for around two sec- appears in green this confirms that the onds, before the call is connected to automatic system is activated.
  • Page 264 EMERGENCY CALL (3/3) The system operates with a dedi- cated battery. The battery serv- ice life is approximately four years (the 1 warning light lights up in red Without the emergency call feature, to warn you when approaching the system is not trackable and will expiry).
  • Page 265 Section 3: Your comfort Multi-Sense ..............Air Vents .
  • Page 266 MULTI-SENSE Mode Eco The MULTI-SENSE system enables you to choose between four driving Eco mode focuses on energy saving. modes that can be used to control: The steering is smooth, engine and driving, ambient lighting, comfort and gearbox management enable fuel con- engine sound (depending on the vehi- sumption to be reduced ➥...
  • Page 267 AIR VENTS: air outlets (1/2) 1 side window demister outlets 2 side air vents 3 windscreen demister outlet 4 centre air vents 5 footwell heater outlets for front pas- 7 footwell heater outlets for rear pas- sengers sengers 6 multimedia screen 8 centre console air vents...
  • Page 268 AIR VENTS: air outlets (2/2) Front seats Rear seats Air flow Turn control knob 9: Direction Right/left direction  : maximum air flow; Move cursor 11. Right/left direction  : closed. Move cursor 8. Up/down direction To remove bad odours from your ve- Move cursor 11.
  • Page 269 MANUAL AIR CONDITIONING (1/3) 9 10 11 The controls Indicators Switching air conditioning on or off 1 Adjustment of air temperature/“Clear The following indicators are displayed View” function on the multimedia screen A: The air conditioning is switched on (in- dicator light on) or off (indicator light off) 2 De-icing/demisting of the rear screen 8 Air temperature.
  • Page 270 MANUAL AIR CONDITIONING (2/3) Distribution of air in the passenger compartment There are five air distribution options. Turn control 5 to choose the distribution option. The air distribution is displayed on the multimedia screen. õ The air flow is directed to the windscreen and the front side window demisting vents.
  • Page 271 MANUAL AIR CONDITIONING (3/3) Varying the ventilation speed You can adjust the fan speed by press- ing the controls 6 or 7 to increase or reduce the fan speed. The system is deactivated (OFF): the ventilation speed is zero (vehicle sta- tionary).
  • Page 272 AUTOMATIC CLIMATE CONTROL: Control A (1/5) Soft Normal Fast AUTO Manuel The controls A Short cut to the air conditioning page. To access the automatic climate control SYNC “Synchronisation” function. settings from the multimedia screen 1, De-icing/demisting of the rear refer to the multimedia instructions.
  • Page 273 AUTOMATIC CLIMATE CONTROL: Control A (2/5) To deactivate the function, press the 8 button again or use the 2 control and adjust the right-hand side separately from the left-hand side. Soft Normal Fast The 2 button warning light switches off. Note: the air conditioning configuration depends on the mode selected in the Multi-Sense menu ➥...
  • Page 274 AUTOMATIC CLIMATE CONTROL: Control A (3/5) Automatic mode The automatic climate control system guarantees comfort in the passen- Soft Normal Fast ger compartment and good visibility (except in the event of extreme condi- tions), while optimising consumption. The system controls the ventilation speed, air distribution, air recirculation, and starting and stopping the air condi- tioning and air temperature.
  • Page 275 AUTOMATIC CLIMATE CONTROL: Control A (4/5) Rear screen de-icing/ demisting Press switch 9. The built-in indicator Soft Normal Fast light comes on. This function enables rapid demisting or de-icing of the rear screen and de-icing of the rear view mirrors (on equipped vehicles). To exit the function, press switch 9 again.
  • Page 276 AUTOMATIC CLIMATE CONTROL: Control A (5/5) Manual use Press switch 3. The indicator light in the switch 3 comes on. Soft Normal Fast Prolonged use of this position may lead to odours, caused by non-renewal of air, and the formation of condensation on the windows.
  • Page 277 AUTOMATIC CLIMATE CONTROL: Control B (1/5) Automatic mode Air recirculation. “FAST” automatic mode. The automatic climate control system guarantees comfort in the passen- “AUTO” automatic mode. ger compartment and good visibility “SOFT” automatic mode. (except in the event of extreme condi- tions), while optimising consumption.
  • Page 278 AUTOMATIC CLIMATE CONTROL: Control B (2/5) Adjusting the ventilation Note: the air conditioning configuration depends on the mode selected in the speed. Multi-Sense menu ➥ 3.2. In automatic mode, the system uses the most suitable amount of air to reach and maintain the desired comfort level.
  • Page 279 AUTOMATIC CLIMATE CONTROL: Control B (3/5) Clear View function All the air is then directed to the windscreen and front side Press the 3 button: the integrated indi- window demisting vents. cator light comes on.  The air flow is distributed be- This function quickly demists and de- tween front side window de- ices the windscreen, the rear screen,...
  • Page 280 AUTOMATIC CLIMATE CONTROL: Control B (4/5) Switching air conditioning on or off In automatic mode, the system switches the air conditioning system on or off, depending on the climate conditions. Press the 2 button to deactivate the air conditioning. The integrated indicator light goes off.
  • Page 281 AUTOMATIC CLIMATE CONTROL: Control B (5/5) Manual use Press the 9 button: the integrated indi- cator light comes on. Prolonged use of this position may lead to odours, caused by non-renewal of air, and the formation of condensation on the windows. We therefore advise you to return to au- tomatic mode as soon as air recircula- tion is no longer needed, by pressing...
  • Page 282 AUTOMATIC CLIMATE CONTROL: Control C (1/5) Automatic mode 10 “Clear View” function. 12 and 18 Ventilation speeds. The automatic climate control system guarantees comfort in the passen- 13 SYNC “Synchronisation” function. ger compartment and good visibility 14, 15 and 16 Automatic modes. (except in the event of extreme condi- tions), while optimising consumption.
  • Page 283 AUTOMATIC CLIMATE CONTROL: Control C (2/5) Temperature adjustment To deactivate the function, press the 13 button again or use the 5 control and There are two types of settings: adjust the right-hand side separately – independent adjustment of the pas- from the left-hand side.
  • Page 284 AUTOMATIC CLIMATE CONTROL: Control C (3/5) Press button 10 – the integrated indica- tor light comes on. Press button 6 to stop the heated rear screen operating, and the integrated in- dicator goes out. To change the fan speed: press but- tons 12 or 18.
  • Page 285 AUTOMATIC CLIMATE CONTROL: Control C (4/5) Stopping the system Rear screen de-icing/ demisting To switch the system off, press button 12 repeatedly until the message Press button 6 – the integrated indica- OFF appears in zone 1. tor light comes on. This function en- ables rapid demisting or de-icing of the rear screen and de-icing of the door mirrors (on equipped vehicles).
  • Page 286 AUTOMATIC CLIMATE CONTROL: Control C (5/5) Air recirculation Manual use Press button 9 to force air recirculation. This function is managed automatically but you can also activate it manually. Prolonged use of this position may lead to odours, caused by non-renewal of Note: air, and the formation of condensation –...
  • Page 287 AIR CONDITIONING: information and operating instructions (1/2) Advice on use Fuel consumption Operating faults In some situations (air conditioning off, You will normally notice an increase in As a general rule, contact your ap- air recirculation activated, ventilation fuel consumption (especially in town) proved dealer in the event of an oper- speed at zero or low etc.), you may when the air conditioning is operating.
  • Page 288 AIR CONDITIONING: information and operating instructions (2/2) Ñ Type of refrigerant fluid  Type of oil in the air condi- tioning circuit  Inflammable product  Consult the driver’s hand- book  Maintenance Quantity of refrigerant fluid present in the ve- x.xxx kg hicle.
  • Page 289 OUTSIDE AIR QUALITY AND DEODORISATION FUNCTION To access the function from the multi- media screen 1, refer to the multimedia instructions. Outside air quality The quality of the air in the vehicle is shown via an explanatory text and an animation on the multimedia screen.
  • Page 290 MULTIMEDIA EQUIPMENT (1/2) Multimedia settings Hands-free telephone integrated control 1 Multimedia screen; 2 Steering column controls; For equipped vehicles, use the steering 3 Steering wheel controls; wheel controls 3. 4 Microphone. Using the telephone We remind you of the need to conform to the legislation in force concerning the use Refer to the equipment instructions...
  • Page 291 MULTIMEDIA EQUIPMENT (2/2) Multimedia sockets 5 The sockets USB can also recharge ac- cessories with a maximum power rating You can use the USB ports or, de- of 12 Watts (voltage: 5V) per socket, pending on the vehicle, the SD card which have been approved by our reader to access the multimedia con- Technical Department.
  • Page 292 ELECTRIC WINDOWS (1/2) Electric windows These systems operate: – with the engine running; – with the ignition off until one of the front doors is opened (limited to ap- proximately 12 minutes). – with the engine off, front doors closed, after pressing the start button.
  • Page 293 ELECTRIC WINDOWS (2/2) One-touch mode Remote control window closing (vehicles with 4 one-touch electric win- This mode works in addition to the ope- dows). ration of the electric windows described When you lock the doors from the out- previously. side, press the locking button on the Briefly press or pull the window switch card twice in quick succession, or on fully: the window is fully lowered or...
  • Page 294 ELECTRIC SUNROOF (1/3) Driver’s responsibility Never leave an animal, child or non-autonomous adult alone in your vehicle, even for a short time. To slide the curtain 1 To slide the sunroof The reason for this is that the child – To open: push the handle 2 rear- –...
  • Page 295 ELECTRIC SUNROOF (2/3) Closing the sunroof by remote control If you press twice on the card lock- ing button in quick succession or on the driver’s door locking button in hands-free mode, all the windows and the sunroof will lock automatically. It is recommended that the user only operates the system when the vehi- cle can be seen clearly and no one is...
  • Page 296 ELECTRIC SUNROOF (3/3) Precautions during use – Vehicle with loaded roof bars. As a general rule, if there is a load on the roof, use of the sunroof is not recommended. Before using the sunroof, check the objects and/or accessories (bike racks, roof boxes, etc.) attached to the roof bars: they should be prop- erly arranged and secured and...
  • Page 297 INTERIOR LIGHTING (1/2) Map reading lights Courtesy light Note: on vehicles equipped with a mul- timedia system, from the multimedia Press switch 1 to get: Press switch 3 for: screen (➥ 1.92) you can: – permanent lighting; – permanent lighting; –...
  • Page 298 INTERIOR LIGHTING (2/2) Luggage compartment light 6 The light comes on when the luggage compartment is opened. With the doors properly shut, lock- ing or starting the engine makes the interior lights and the courtesy lights go out. 3.34...
  • Page 299 SUN VISOR, BLINDS Front sun visor Ticket holder 4 Lower the sun visor 1 on the wind- Can be used to hold motorway toll tick- screen or unclip it and lower it over the ets, maps, etc. side window. Vanity mirror Lift the cover 3.
  • Page 300 PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS (1/4) Door pockets 1 Passenger storage Sun blind storage compartment compartment 3 It can hold a bottle. Pull handle 2 to open it. This can be used for storing motorway tickets, cards, etc. The glove box can hold A4-sized docu- ments, a bottle etc.
  • Page 301 PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS (2/4) Central storage Cup holders 7 compartment 5 A sliding system 6 holds maintains the cups. Central storage compartment 4 When turning corners, accelerating or braking, Ensure that no hard, heavy ensure that the recepta- or pointed objects are cle being held by the cup placed in the “open”...
  • Page 302 PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS (3/4) Central storage Grab handle 10 compartment 9 This offers support and can be held when the vehicle is being driven. With the sliding armrest 8 in its rear- most position, raise it. Do not use it for getting into or out of the vehicle.
  • Page 303 PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS (4/4) Rear door storage Front seat storage pockets 13 Rear armrest with cup holder compartment 12 Lower armrest 15. Rear central storage compartment 14 Ensure that no hard, heavy When turning corners, or pointed objects are accelerating or braking, placed in the “open”...
  • Page 304 ASHTRAY, CIGARETTE LIGHTER, ACCESSORIES SOCKET (1/2) Cigarette lighter 1 Ashtray 3 With the ignition on, push in cigar It can be housed in either position 2. lighter 1, it will spring back with a click To open, lift the cover. To empty, pull the when it is ready.
  • Page 305 ASHTRAY, CIGARETTE LIGHTER, ACCESSORIES SOCKET (2/2) Accessories sockets 4 You can use the one of sockets 4. They are provided for connecting ac- cessories approved by our Technical Department. Connect accessories with a maximum power of 120 watts (12 V) only. When several accessory sockets are used at the same time, the total power of the connected...
  • Page 306 REAR HEADRESTS (1/2) Position for using the central Centre seat headrest B To remove a headrest headrest A storage position Raise the headrest as far as it will go, then press button 1 and remove the Raise the headrest as far as possible to Press the button 1 and lower the head- headrest.
  • Page 307 REAR HEADRESTS (2/2) Storage position for the side headrests Press the button 1 and, depending on the vehicle: – fully lower (movement A) the head- rest 2, or – lower and tilt (movement B) the headrest 3 fully forwards. 3.43...
  • Page 308 REAR BENCH SEAT (1/2) The configuration of the two-seat bench with the small seatback B pulled down, does not allow the central seat to be used as it would be impossible to buckle the seat belt (belt buckles inaccessible). When refitting the seat- back, make sure it is cor- rectly locked in place.
  • Page 309 REAR BENCH SEAT (2/2) Conditions of use – Vehicle stationary; – luggage compartment lid open; – rear seat belts locked. Operating faults If all user conditions have been ful- filled and the folding action still fails to operate, please contact an authorised dealer.
  • Page 310 LUGGAGE COMPARTMENT: 4 DOOR VERSION (1/3) Depending on the vehicle, there are various ways to unlock and operate the luggage compartment lid: – using the locking/unlocking button on the remote control key ➥ 1.4; – using the locking/unlocking button on the card ➥ 1.8; –...
  • Page 311 LUGGAGE COMPARTMENT: 4-DOOR VERSION (2/3) The sensor detects the approach and then the removal of your foot and trig- gers the opening of the boot lid. Do not keep your foot in the air. Perform the movement without stopping and wi- thout touching the rear bumper.
  • Page 312 LUGGAGE COMPARTMENT: 4-DOOR VERSION (3/3) Activation/deactivation of the User precautions hands-free function – Before opening the tailgate, ensure To activate or deactivate the function, that the surrounding space is suffi- refer to the multimedia instructions. cient to permit operation of the tail- gate.
  • Page 313 LUGGAGE COMPARTMENT: 5-DOOR VERSION Opening manually from To open inside the vehicle Press button 1 and lift the tailgate. Special note: To close If it is impossible to unlock the tailgate, Lower the tailgate using the handles 2 it can be done manually from inside: inside the tailgate to help you.
  • Page 314 REAR PARCEL SHELF Removal Unclip the rear parcel shelf 2 and pull it towards you. Unhook the two cords 1 (tailgate side). To refit it, proceed in reverse order to removal. Do not place any heavy or hard object on the parcel shelf.
  • Page 315 LUGGAGE COMPARTMENT COVER To remove the flexible Removing/refitting the Luggage compartment cover section of the luggage luggage cover 2 storage 2 compartment cover 2 Slide section 3 (movement A) and lift Lift section 4 of the luggage compart- the right-hand side (movement B) of ment floor.
  • Page 316 LUGGAGE NET (1/2) Fitting the luggage net Depending on the vehicle, this may be – if using the net for the first time, to used when transporting animals or lug- access the anchorage points 4 lo- behind the front seats gage to isolate them from the passen- cated under the carpet, contact an Inside the vehicle on each side:...
  • Page 317 LUGGAGE NET (2/2) Fitting the luggage net – fix the net belt hook 9 onto the ancho- ring points 10; behind the rear seats – adjust net strap 8 so that it is taut. The Inside the vehicle on each side: seatbacks must not touch the luggage –...
  • Page 318 BOOT STORAGE SPACE AND FITTINGS (1/5) Storage under the carpet The false floor can be attached using the hook 4 in the housing 3. To gain access to this, lift the boot carpet 1 using the tab 2. Always place objects being trans- ported so that the heaviest items are resting against the back of the rear bench seat.
  • Page 319 BOOT STORAGE SPACE AND FITTINGS (2/5) Mobile floor Storage position Separation position (Estate version) This enables more space for storage in This enables you to compartmentalise the luggage compartment: the boot into two separate spaces. It is made up of two independent parts, A and B.
  • Page 320 BOOT STORAGE SPACE AND FITTINGS (3/5) Storage under floor Lift part C into the vertical position until Lift part A using handle 10 and place it it locks. on the lugs 9. To access it, lift part B of the mobile floor using the handle 8, then place it on part A.
  • Page 321 BOOT STORAGE SPACE AND FITTINGS (4/5) Anchorage points Attachment points 11. If your vehicle is not equipped with anchorage points, you can get them from an authorised dealer. Always position the heaviest items directly on the floor. Use the lashing points 11 on the boot floor, if these are fitted to the vehicle.
  • Page 322 BOOT STORAGE SPACE AND FITTINGS (5/5) Bag hooks 12 Storage compartment 13 (Estate version) Maximum weight per hook: 5 kg. 3.58...
  • Page 323 TRANSPORTING OBJECTS IN THE LUGGAGE COMPARTMENT Always position the objects transported so that the largest surface is against: – The rear bench seatback, for normal loading (example A); – The front seatbacks with the rear seatbacks folded down, as is the case for maximum loads (example B).
  • Page 324 TRANSPORTING OBJECTS towbar Permissible nose weight, maxi- A: 895 mm maximum (5-door version). mum permissible towing weight braked and unbraked: ➥ 6.11. A: 1120 mm maximum (Estate version). Choice and fitting of towing A: 1127 mm maximum (4-door version). equipment Maximum weight of towing equip- ment: –...
  • Page 325 ROOF BARS (1/2) Access to the mounting Vehicles not fitted with longitudinal roof bars points Open the doors to access the mount- ing points 1. If original roof bars, ap- For information on the range of equipment adapted to your vehicle, we advise you proved by our Technical to consult an approved Dealer.
  • Page 326 ROOF BARS (2/2) Precautions during use Handling the tailgate Before handling the tailgate, check the objects and/or accessories (bike rack, roof box, etc.) fitted to the roof bars: these must be correctly positioned and secured, so as not to hinder the opera- tion of the tailgate.
  • Page 327 Section 4: Maintenance Bonnet ............... . Engine oil level: general information .
  • Page 328 BONNET (1/2) When working in the engine compartment, ensure that Unlocking the bonnet catch To open, pull handle 1, located on the the windscreen wiper stalk left-hand side of the dashboard. To unlock, push tab 3 at the same time is in the park position.
  • Page 329 BONNET (2/2) Closing the bonnet Check that nothing has been left in the engine compartment. To close the bonnet again, hold the bonnet in the middle and guide it down, allowing a 30 cm gap before it is closed, then release it. It will latch automatically under its own weight.
  • Page 330 ENGINE OIL LEVEL: general information It is normal for an engine to use oil for lubrication and cooling of moving parts Before carrying out any and it is normal to top up the level be- action in the engine com- tween oil changes.
  • Page 331 ENGINE OIL LEVEL: topping up, filling, draining (1/3) Topping up/Filling – Unscrew cap 1; Do not exceed the “maxi" level and – top up the level (as a guide, the ca- The vehicle must be parked on level do not forget to refit the cap 1 and pacity between the “mini"...
  • Page 332 ENGINE OIL LEVEL: topping up, filling, draining (2/3) Topping up/Filling – Unscrew cap 1; Do not exceed the “maxi" level and – top up the level (as a guide, the ca- The vehicle must be parked on level do not forget to refit the cap 1 and pacity between the “mini"...
  • Page 333 ENGINE OIL LEVEL: topping up, filling, draining (3/3) Oil change Engine oil grade Service interval: refer Refer to the Maintenance Service Maintenance Service Booklet for your Booklet for your vehicle. vehicle. Oil change capacity Please refer to the maintenance docu- Filling: take care when ment for your vehicle, or contact an au- Consult your approved Dealer at...
  • Page 334 LEVELS, FILTERS (1/3) Checking intervals Replacement intervals Check the coolant level regularly Refer to the Maintenance Document for (very severe damage is likely to be your vehicle. caused to the engine if it runs out of coolant). If the level needs to be topped up, only use products approved by our Technical Department which ensure: –...
  • Page 335 LEVELS, FILTERS (2/3) Level 2 Topping up It is normal for the level to drop as After any operation on the hydraulic cir- the linings become worn, but it should cuit, a specialist must replace the fluid. never drop below the “MINI” warning Only use fluids approved by our line.
  • Page 336 LEVELS, FILTERS (3/3) Filters Liquid Windscreen washer fluid. In winter, use The replacement of filter elements (air anti-freeze product. Use products rec- filter, passenger compartment filter, ommended by an authorised dealer. diesel filter, etc.) is scheduled in the maintenance operations for your vehi- Note: do not use pure water (risk of cle.
  • Page 337 BATTERY (1/2) The charge status of your battery can decrease especially if you use your ve- hicle: – for short journeys; – for driving in town; – when the temperature drops; – after extended use of energy-con- suming devices (radio, etc.) with the engine switched off.
  • Page 338 BATTERY (2/2) Replacing the battery For your own safety and for the proper operation of the vehicle’s electrical equip- ment (lights, windscreen wipers, ABS, etc.), any intervention on the battery (removal, disconnec- tion, etc.) must categorically be per- formed by a specialist professional. Risk of serious burns or electric shocks.
  • Page 339 TYRE PRESSURE (1/2) Vehicle fitted with a tyre pressure monitoring system In the event of under-inflation (punc-  tures, under-inflation etc.), the warning light appears on the instrument panel. ➥ 2.32. Label A B: dimension of the tyres fitted to the vehicle.
  • Page 340 TYRE PRESSURES (2/2) Tyre safety and use of snow chains: ➥ 5.13 to learn the maintenance con- ditions and the conditions for fitting chains to different versions of the ve- hicle. For your safety, please re- spect the speed limit. When they need to be re- placed, only tyres of the same make, size, type and profile...
  • Page 341 BODYWORK MAINTENANCE (1/3) You should A well-maintained vehicle will last Respect local regulations about wash- longer. It is therefore recommended to ing vehicles (e.g. do not wash your ve- Wash your car frequently, with the maintain the exterior of the vehicle reg- hicle on a public highway).
  • Page 342 BODYWORK MAINTENANCE (2/3) What you should not do Wash the vehicle in bright sunlight or Degrease or clean using freezing temperatures. high-pressure cleaning Do not scrape off mud or dirt without equipment or by spray- pre-wetting. ing on products not ap- Allow dirt to accumulate on the exterior.
  • Page 343 BODYWORK MAINTENANCE (3/3) Vehicles with a matte paint Using a roller type car wash Cleaning the headlights, finish sensors and cameras Return the wiper stalk to the park po- sition. ➥ 1.108. Check the mounting of This type of paint requires certain pre- Use a soft cloth or cotton wool.
  • Page 344 INTERIOR TRIM MAINTENANCE (1/2) Glass instrument panel Textiles (seats, door trim, etc) A well-maintained vehicle will last longer. It is therefore recommended to (e.g. instrument panel, clock, exterior Vacuum-clean the textiles regularly. maintain the interior of the vehicle regu- temperature display etc.) larly.
  • Page 345 INTERIOR TRIM MAINTENANCE (2/2) Removal/replacing removable You should not: equipment originally fitted in Position objects such as deodorants, the vehicle scents etc. near air vents as this could damage your dashboard trim. If you need to remove equipment in order to clean the passenger com- partment (for example, mats), always ensure that they are correctly refitted and are the right way around (the driv-...
  • Page 346 4.20...
  • Page 347 Section 5: Practical advice Puncture/emergency spare wheel ........... Tyre inflation kit .
  • Page 348 PUNCTURE, EMERGENCY SPARE WHEEL (1/3) In case of puncture Depending on the vehicle, a tyre infla- tion kit or emergency spare wheel is provided (refer to the following pages). Special note The tyre pressure monitor function does not check the emergency spare wheel (the wheel replaced by the emer- gency spare wheel disappears from the instrument panel display) ➥...
  • Page 349 PUNCTURE, EMERGENCY SPARE WHEEL (2/3) Emergency spare wheel 3 Vehicle not fitted with a Vehicle fitted with a subwoofer subwoofer This is located in the luggage compart- ment. To access it: To access it: – open the boot; – open the boot; –...
  • Page 350 PUNCTURE, EMERGENCY SPARE WHEEL (3/3) To refit the wheel carrier: – use the wheelbrace 8 to screw fully the nut clockwise (reverse move- ment A); – make sure you lock the wheel carrier in place; – refit the blanking cover, then the cover 9.
  • Page 351 TYRE PRESSURE KIT (1/3) Do not attempt to use the The kit is only approved for inflation kit if the tyre has inflating the tyres of the ve- been damaged as a result hicle originally equipped of driving with a puncture. with the kit.
  • Page 352 TYRE PRESSURE KIT (2/3) Engine running, handbrake applied: Note: While the container empties (approx. 30 secs), the pressure – Connect the compressor hose 4 to gauge 6 briefly shows pressure up to the container inlet 9; 6 bar, then the pressure drops. –...
  • Page 353 TYRE PRESSURE KIT (3/3) Precautions when using the Once the tyre is correctly inflated, remove the kit: – Slowly unscrew inflation The kit should not be operated for more adapter 3 to prevent any repair prod- than 15 consecutive minutes. uct from escaping and store the con- tainer in plastic packaging to prevent the product from leaking.
  • Page 354 TOOLS (1/2) Tool kit Tool box (depending on vehicle) (depending on vehicle) To access the tool kit 1, raise the lug- To access the tool box, unlock the gage compartment carpet and/or mounting(s) 2 by one quarter of a turn, mobile floor ➥...
  • Page 355 TOOLS (2/2) Towing hitch 9 ➥ 5.39 Wheelbrace 10 Locks or unlocks the wheel bolts and tow eye 9. Do not leave the tools un- secured inside the vehicle as they may come loose under braking. After use, Hubcap tool 7 The presence of the tools depends on check that all the tools are correctly the vehicle.
  • Page 356 HUBCAP Remove using the hubcap tool 1 (lo- cated in the tool kit) by connecting the hook in the recess provided next to the valve 2 (to attach the metal clip). To refit it, align it with valve 2. Push the retaining hooks in fully, starting with side A near the valve, followed by B and C, finishing at D opposite the valve.
  • Page 357 CHANGING A WHEEL (1/2) Vehicles equipped with a jack and wheelbrace If necessary, remove the wheel trim. Use the wheelbrace 2 to slacken off the wheel bolts. Position it so as to be able to push from above. Place the jack 3 horizontally; the jack head must be lined up with the sill clos- est to the wheel concerned, as shown by an arrow 1.
  • Page 358 CHANGING A WHEEL (2/2) Undo the bolts and take off the wheel. Vehicle fitted with a tyre pressure monitoring system Fit the emergency spare wheel onto the hub and rotate it until the mounting In the event of under-inflation (punc- ...
  • Page 359 TYRES (1/3) The tyres are the only contact between When the tread has worn down to the the vehicle and the road, so it is essen- wear warning strips, these strips will become visible 2: it is then necessary tial to keep them in good condition. to replace your tyres because the tread You must make sure that your tyres rubber is now only 1.6 mm deep at...
  • Page 360 TYRES (2/3) Tyre pressures The pressures should be checked cold: Vehicle fitted with a tyre pressure ignore higher pressures which may be monitoring system Adhere to the tyre pressures (including reached in hot weather or following a In the event of under-inflation (punc- the emergency spare wheel).
  • Page 361 TYRES (3/3) Fitting new tyres Use in winter Studded tyres This type of equipment may only be Snow or Winter tyres used for a limited period and as laid We would recommend that these be down by local legislation. It is neces- fitted to all four wheels to ensure that For your safety, please re- sary to observe the speed specified by...
  • Page 362 FRONT HEADLIGHTS: replacing the bulbs (1/2) Front fog lights 4 Please see an authorised dealer. Any operation on (or modi- fication to) the electrical Additional lights system must be performed If you wish to fit fog lights to your ve- by an approved dealer hicle, please see an authorised dealer.
  • Page 363 FRONT HEADLIGHTS: replacing the bulbs (2/2) Vehicles with Halogen Halogen main beam headlight 5 Front fog lights 8 – Access the bulb holder via the un- headlights To change the bulb: derneath of the vehicle; – open the bonnet; – unclip the access flap 9; Daytime running lights/side lights/ –...
  • Page 364 REAR LIGHTS AND SIDE LIGHTS: replacing the bulbs (1/7) Rear fog lights 6 or 7 The front bumper needs to be removed; consult an authorised dealer. Bulb type: P21W. 5-door version Direction indicators 4 Consult an approved dealer. Brake/side lights 1 High level brake light 5 Consult an approved dealer Consult an approved dealer.
  • Page 365 REAR LIGHTS AND SIDE LIGHTS: replacing the bulbs (2/7) Number plate lights 8 Side repeaters 9 and welcome lighting 10 Consult an approved dealer. The wing mirror needs to be removed; consult an authorised dealer. 5.19...
  • Page 366 REAR LIGHTS AND SIDE LIGHTS: replacing the bulbs (3/7) Rear fog lights 6 or 7 The front bumper needs to be removed; consult an authorised dealer. Bulb type: P21W. Estate version Direction indicators 4 Consult an approved dealer. Brake/side lights 1 High level brake light 5 Consult an approved dealer Consult an approved dealer.
  • Page 367 REAR LIGHTS AND SIDE LIGHTS: replacing the bulbs (4/7) Number plate lights 8 Side repeaters 9 and welcome lighting 10 Consult an approved dealer. The wing mirror needs to be removed; consult an authorised dealer. 5.21...
  • Page 368 REAR LIGHTS AND SIDE LIGHTS: replacing the bulbs (5/7) 4-door version Brake light 1 Access to the bulb holders 6 and 7 Open the boot, remove the cover 4 to Turn bulb holder 6 a quarter of a turn Side light 3 access the screw 5 and undo it.
  • Page 369 REAR LIGHTS AND SIDE LIGHTS: replacing the bulbs (6/7) Reversing light High level brake light 10 Turn bulb holder 9 a quarter of a turn and take out the bulb. From the boot, unclip the cover on the Consult an approved dealer. Bulb type: W16W.
  • Page 370 REAR LIGHTS AND SIDE LIGHTS: replacing the bulbs (7/7) Number plate lights with LED number plate lights 13 Side repeaters 14 and conventional bulbs 12 welcome lighting 15 (depending on vehicle) (depending on vehicle) Consult an approved dealer The wing mirror needs to be removed; –...
  • Page 371 INTERIOR LIGHTING: changing bulbs (1/3) Ambient lighting Please consult an authorised dealer. Map reading lights 1 Courtesy light 2 Please consult an authorised dealer. Please consult an authorised dealer. 5.25...
  • Page 372 INTERIOR LIGHTING: changing bulbs (2/3) Glove box light 3 Luggage compartment light 4 (four-door version) Please consult an authorised dealer. Unclip the light by pressing the tab with a flat-blade screwdriver or similar. Disconnect the light. Remove the bonnet 5 Access the bulb.
  • Page 373 INTERIOR LIGHTING: changing bulbs (3/3) Luggage compartment light 6 (five-seater and estate versions) Unclip the light by pressing the tab with a flat-blade screwdriver or similar. Disconnect the light. Access the bulb. Bulb type: W5W. The bulbs are under pres- sure and can break when replaced.
  • Page 374 FUSES (1/2) Use the fuse allocation label on the back of flap A to identify the fuses. Certain fuses should only be replaced by a qualified professional. These fuses are not listed on the label. Only change the fuses represented on the label.
  • Page 375 FUSES (2/2) Allocation of fuses (the presence of certain fuses depends on the vehicle equipment level) Symbol Allocation Windscreen washer Multimedia accessories socket, multimedia î screen Æ Front and rear second row accessories socket Ì Horn Ý Towbar socket  Heated rear view mirrors ×...
  • Page 376 BATTERY: troubleshooting (1/2) To avoid all risk of sparks: Connecting a battery charger – Ensure that any consumers (cour- The battery charger must be com- Before carrying out any tesy lights, etc.) are switched off patible with a battery with nominal action in the engine com- before disconnecting or reconnect- voltage of 12 volts.
  • Page 377 BATTERY: troubleshooting (2/2) Starting the vehicle using the battery from another vehicle If you have to use the battery from an- other vehicle to start, obtain suitable jump leads (with a large cross section) from an approved dealer or, if you al- ready have jump leads, ensure that they are in perfect condition.
  • Page 378 CARD: battery (1/2) The batteries are available from ap- proved Dealers, and their service life approximately two years. Check that there is no dye on the battery: risk of an incorrect electrical con- tact. Replacing the battery When refitting, proceed in the reverse If they need to be replaced, order, then press one of the buttons on When the message “Keycard Battery...
  • Page 379 CARD: battery (2/2) Operating faults If the battery is too weak to ensure cor- rect operation, you will still be able to start and lock/unlock the vehicle ➥ 1.13. Precautions relating to batteries: – keep (new or used) batter- ies out of reach of children; –...
  • Page 380 RADIO FREQUENCY REMOTE CONTROL: batteries (1/2) Replacing the battery Note: It is not advisable to touch the electronic circuit in the key cover when Open the case at slot 1 using a flat- replacing the battery. blade screwdriver or similar, and re- When refitting, ensure that the cover is place the battery 2, observing the po- correctly clipped on and the screw tight-...
  • Page 381 RADIO FREQUENCY REMOTE CONTROL: batteries (2/2) Operating faults If the battery is too weak to ensure cor- rect operation, you will still be able to start and lock/unlock the vehicle ➥ 1.13. Precautions relating Do not throw away your used bat- to batteries: teries;...
  • Page 382 ACCESSORIES Electrical and electronic accessories Before installing this type of accessory (particularly for transmitters/receivers: frequency bandwidth, power level, po- sition of the aerial, etc.), make sure it is compatible with your vehicle. You can get advice from an authorised dealer. Connect accessories with a maximum power of 120 Watts only.
  • Page 383 WIPER BLADES: REPLACEMENT (1/2) Replacing windscreen wiper – In frosty weather, make blades 1 sure that the wiper blades are not stuck by ice (to With the ignition on and engine avoid the risk of the motor switched off, lower the windscreen overheating).
  • Page 384 WIPER BLADES: REPLACEMENT (2/2) To refit To refit the wiper blade, proceed in re- verse order to removal. Make sure that the blade is correctly locked in position. Rear screen wiper blade 4 Stalk in stop position (deactivated): – Lift wiper arm 6; –...
  • Page 385 TOWING: breakdown recovery (1/2) Before towing, put the gearbox in neu- The speed specified by current legis- tral, unlock the steering column and re- lation for towing must always be ob- lease the parking brake. served. If you are driving the towing For vehicles fitted with an automatic vehicle, do not exceed the permissible gearbox, if it is not possible to put the...
  • Page 386 TOWING: breakdown recovery (2/2) Use only the 5 towing eye ➥ 5.8. Ensure that the towing eye is bolted correctly. Risk of losing the towed object. Access to towing points Only use the front 3 and rear 6 towing – Use a rigid towing bar. points If a rope or cable is used Front towing point 3...
  • Page 387 OPERATING FAULTS (1/7) The following advice will enable you to carry out quick, temporary repairs. For safety reasons you should always contact an approved Dealer as soon as possible. Using the card POSSIBLE CAUSES WHAT TO DO The card does not lock or unlock the Card battery is flat.
  • Page 388 OPERATING FAULTS (2/7) The following advice will enable you to carry out quick, temporary repairs. For safety reasons you should always contact an approved dealer as soon as possible. Using the remote control POSSIBLE CAUSES ACTION REQUIRED The remote control does not lock or The remote control battery is flat.
  • Page 389 OPERATING FAULTS (3/7) The starter is activated POSSIBLE CAUSES WHAT TO DO The instrument panel indicator lights are Battery terminals not tight, Retighten or reconnect the terminals, or clean them if weak or fail to light up and the starter battery terminals discon- they are oxidised.
  • Page 390 OPERATING FAULTS (4/7) On the road POSSIBLE CAUSES WHAT TO DO Vibrations. Tyres not inflated to correct pres- Check the tyre pressures: if this is not the sures, incorrectly balanced or dam- problem, have them checked by an ap- aged. proved Dealer.
  • Page 391 OPERATING FAULTS (5/7) On the road POSSIBLE CAUSES WHAT TO DO Steering becomes heavy. Assistance overheating. Drive carefully at reduced speed, be aware of the level of force in the steering wheel Fault with the electric assistance needed to turn the wheels. Consult an ap- motor.
  • Page 392 OPERATING FAULTS (6/7) Electrical equipment POSSIBLE CAUSES WHAT TO DO The wipers do not work. Wiper blades stuck. Free the blades before using the wipers. Faulty electrical circuit. Consult an approved dealer. Fuse damaged. Replace the fuse or have it replaced ➥...
  • Page 393 OPERATING FAULTS (7/7) Electrical equipment POSSIBLE CAUSES WHAT TO DO Traces of condensation in the lights Traces of condensation may be a nat- and headlights. ural phenomenon caused by varia- tions in temperature and humidity. In this case, the traces will disappear slowly once the lights are switched The front seat belt reminder light An object is stuck between the floor...
  • Page 394 5.48...
  • Page 395 Section 6: Technical specifications Vehicle identification plates ............Engine identification plates .
  • Page 396 VEHICLE IDENTIFICATION PLATES The information shown on the ve- 4 MMAC (Maximum permissible hicle identification plate should be all-up weight). quoted on all correspondence or 5 MTR (Gross train weight: vehicle orders. fully loaded, with trailer). 6 MMTA (Maximum Permissible The presence and location of the in- Weight) front axle.
  • Page 397 ENGINE IDENTIFICATION PLATES (1/2) Please quote the information on the engine plate or label A in all corre- spondence or orders. (Location varies depending on engine) 1 Engine type. 2 Engine suffix. 3 Engine number.
  • Page 398 ENGINE IDENTIFICATION PLATES (2/2) Please quote the information on the engine plate or label A in all corre- spondence or orders. (Location varies depending on engine) 1 Engine type. 2 Engine suffix. 3 Engine number.
  • Page 399 DIMENSIONS (in metres) (1/3) Five-door version 0,921 2,670 0,768 1,574 to 1,596 4,359 1,446* 1,565 to 1,599 2,058 * Unladen...
  • Page 400 DIMENSIONS (in metres) (2/3) Estate versions 0,921 2,712 0,993 1,574 to 1,596 4,626 1,449* 1,565 to 1,599 2,058 * Unladen...
  • Page 401 DIMENSIONS (in metres) (3/3) Four-door version 0,921 2,711 0,998 1,577 to 1,583 4,630 1,443* 1,583 to 1,587 2,058 * Unladen...
  • Page 402 ENGINE SPECIFICATIONS (1/3) Versions 1.0 TCe 1.3 TCe 1.6 16V 1.8 TCe 1.5 dCi Engine type H5D Turbo H5H Turbo M5P Turbo (see engine plate) Cubic capacity (cc) 1333 1598 1798 1461 Type of fuel Petrol Diesel Octane rating You must use unleaded petrol with the octane rating stated on the The label located in the fuel filler label inside the fuel filler flap.
  • Page 403 ENGINE SPECIFICATIONS (2/3) Versions 1.0 TCe 1.3 TCe 1.6 16V 1.8 TCe 1.5 dCi Engine type H5D Turbo H5H Turbo M5P Turbo (see engine plate) Cubic capacity (cc) 1333 1598 1798 1461 Fuel types that meet Unleaded petrol compliant with stand- Diesel fuel compliant with European standards ard EN 228 contains up to 5% ethanol in...
  • Page 404 ENGINE SPECIFICATIONS (3/3) Versions 1.0 TCe 1.3 TCe 1.6 16V 1.8 TCe 1.5 dCi Engine type H5D Turbo H5H Turbo M5P Turbo (see engine plate) Cubic capacity (cc) 1333 1598 1798 1461 Spark plugs Only use the spark plugs specified for your vehicle’s engine. The type should be marked on a label affixed inside the engine compartment.
  • Page 405 WEIGHTS (in kg) The weights indicated are for a basic vehicle without options: they may vary depending on your vehicle’s equipment. Consult an approved Dealer. Five door Estate Four-door Maximum permissible all-up weight (MMAC) Maximum permissible all-up weight (MMTA) Weights indicated on the vehicle identification plate ➥ 6.2 Gross Train Weight (MTR) Braked Trailer Weight* found by calculating: MTR - MMAC...
  • Page 406 REPLACEMENT PARTS AND REPAIRS Original parts are based on strict specifications and are subject to highly-specialised tests. Therefore, they are of at least the same level of quality as the parts fitted originally. If you always fit genuine replacement parts to your vehicle, you will ensure that it performs well. Furthermore, repairs carried out within the manufacturer’s Network using original parts are guaranteed according to the conditions set out on the reverse of the repair order.
  • Page 407 SERVICE SHEETS (1/6) VIN: .................. Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □...
  • Page 408 SERVICE SHEETS (2/6) VIN: .................. Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □...
  • Page 409 SERVICE SHEETS (3/6) VIN: .................. Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □...
  • Page 410 SERVICE SHEETS (4/6) VIN: .................. Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □...
  • Page 411 SERVICE SHEETS (5/6) VIN: .................. Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □...
  • Page 412 SERVICE SHEETS (6/6) VIN: .................. Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □...
  • Page 413 ANTICORROSION CHECK (1/6) If the continuation of the warranty is subject to repair, it is indicated below. VIN: ............Corrosion repair operation to be carried Stamp out: Date of repair: Stamp Repair to be carried out: Date of repair: Repair to be carried out: Stamp Date of repair: 6.19...
  • Page 414 ANTICORROSION CHECK (2/6) If the continuation of the warranty is subject to repair, it is indicated below. VIN: ............Corrosion repair operation to be carried Stamp out: Date of repair: Stamp Repair to be carried out: Date of repair: Repair to be carried out: Stamp Date of repair: 6.20...
  • Page 415 ANTICORROSION CHECK (3/6) If the continuation of the warranty is subject to repair, it is indicated below. VIN: ............Corrosion repair operation to be carried Stamp out: Date of repair: Stamp Repair to be carried out: Date of repair: Repair to be carried out: Stamp Date of repair: 6.21...
  • Page 416 ANTICORROSION CHECK (4/6) If the continuation of the warranty is subject to repair, it is indicated below. VIN: ............Corrosion repair operation to be carried Stamp out: Date of repair: Stamp Repair to be carried out: Date of repair: Repair to be carried out: Stamp Date of repair: 6.22...
  • Page 417 ANTICORROSION CHECK (5/6) If the continuation of the warranty is subject to repair, it is indicated below. VIN: ............Corrosion repair operation to be carried Stamp out: Date of repair: Stamp Repair to be carried out: Date of repair: Repair to be carried out: Stamp Date of repair: 6.23...
  • Page 418 ANTICORROSION CHECK (6/6) If the continuation of the warranty is subject to repair, it is indicated below. VIN: ............Corrosion repair operation to be carried Stamp out: Date of repair: Stamp Repair to be carried out: Date of repair: Repair to be carried out: Stamp Date of repair: 6.24...
  • Page 419 ALPHABETICAL INDEX (1/8) AUTO mode ............1.102 → 1.104 ABS ..............1.68, 2.43 → 2.48 Autohold ................2.21 automatic gearbox (use) ....2.16, 2.20, 2.123 → 2.125 access vehicle ............0.4, 1.8 → 1.11 automatic gearbox selector lever.......2.123 → 2.125 accessories............2.5 → 2.7, 5.36 accessories socket ........
  • Page 420 ALPHABETICAL INDEX (2/8) child seats..........1.43 – 1.44, 1.46 → 1.57 demisting children ........0.5, 1.43 – 1.44, 1.52 → 1.60 rear screen ............3.5 → 3.12 windscreen ............3.5 → 3.12 children (safety) ........1.6, 1.17, 3.28 → 3.32 cigar lighter ............. 3.40 – 3.41 deodourisation ..............
  • Page 421 ALPHABETICAL INDEX (3/8) emergency spare wheel ........5.2 → 5.4, 5.14 front seat engine driver’s position memory ..........1.27 front seat adjustment ..........1.20 → 1.27 technical specifications ........6.8 → 6.10 engine coolant ....... 1.69, 1.74 – 1.75, 1.77, 4.8 front seats engine oil ............1.68, 4.4 →...
  • Page 422 ALPHABETICAL INDEX (4/8) head-up display ............1.79 – 1.80 interior trim heated seats ............. 1.22, 1.24 maintenance ............. 4.18 – 4.19 Isofix ..........1.46 → 1.49, 1.55 → 1.57 heated steering wheel ............1.28 heated windscreen ..........3.8 → 3.22 heating and air conditioning system ......3.5 → 3.23 jack ............
  • Page 423 ALPHABETICAL INDEX (5/8) lights mechanical ....4.2 → 4.7, 4.11 – 4.12, 6.13 → 6.18 adjustment ..............1.101 mileage before service ......1.84, 1.87 – 1.88 changing bulbs ..........5.16 – 5.17 front ..............5.16 – 5.17 battery ............... 5.32 – 5.33 lights: hands-free ............1.8 →...
  • Page 424 ............5.34 – 5.35 pedestrian detection ..........2.71 → 2.78 remote control door locking unit ........1.2 → 1.4 power-assisted steering............. 1.95 RENAULT ANTI-INTRUDER DEVICE (RAID) ....1.18 precautions during use ........1.108 → 1.113 RENAULT card pretensioners ............1.34 → 1.39 use ................1.12...
  • Page 425 ALPHABETICAL INDEX (7/8) seat base ..............1.20, 1.23 switching on the vehicle ignition ......2.3 – 2.4, 2.6 seat belt pretensioners front seat belt ...........1.34 → 1.39 tailgate ....1.2 – 1.3, 1.6 – 1.7, 1.15, 1.17, 3.46 → 3.59 seat belt pretensioners ..........1.34 → 1.39 tanks and reservoirs seat belts ...
  • Page 426 ALPHABETICAL INDEX (8/8) tyre pressure loss warning........2.32 → 2.37 windscreen ..............3.8 → 3.22 tyre pressure monitor..1.70, 2.38 → 2.42, 4.13 – 4.14, 5.6, windscreen de-icing/demisting .....3.10, 3.18 → 3.22 5.12, 5.14 windscreen washer .1.108 → 1.113, 1.112, 1.114 – 1.115, 4.10 tyre pressures ....
  • Page 428 7.10...
  • Page 430 à999104119Sê ó ë ä 7M RENAULT S.A.S. SOCIÉTÉ PAR ACTIONS SIMPLIFIÉE AU CAPITAL DE 533 941 113 € / 13-15, QUAI LE GALLO 92100 BOULOGNE-BILLANCOURT R.C.S. NANTERRE 780 129 987 — SIRET 780 129 987 03591 / TÉL. : 0810 40 50 60...

Table of Contents

Save PDF
