TRANSPORTING OBJECTS
Transporting objects in the rear
load area
Depending on the vehicle, securing
rings 1 and 2 can be used to stop
transported objects from moving. The
number of rings and their position may
vary depending on the vehicle.
The sole purpose of these
rings 2 is to prevent trans­
ported objects from moving.
The objects must be secured to
the mounting rings 1 on the vehi­
cle floor beforehand.
Always position the
heaviest items directly
on the floor. Use the
lashing points on the lug­
gage compartment floor, if these
are fitted to the vehicle. The lug­
gage should be loaded in such a
way that no items will be thrown
forward and strike the occupants
if the driver has to brake sudden­
ly. Fasten the rear seat belts,
even if the seats are not occu­
pied.
F max: 500 daN (as indicated on label
A located in the rear load area).
