Renault MASTER 2024 User Manual

page of 404

/ 404
Bookmarks

Advertisement

Quick Links

Download this manual

vehicle user manual

Advertisement

Need help?

Need help?

Do you have a question about the MASTER 2024 and is the answer not in the manual?

Questions and answers

Summary of Contents for Renault MASTER 2024

Page 1 vehicle user manual...
Page 3 Welcome aboard your vehicle This user manual contains the information required: – for you to familiarise yourself with your vehicle, to use it to its best advantage and to fully benefit from the all the functions and the technical developments it incorporates. –...
Page 4 CONTENTS Welcome aboard your vehicle ..........4 Driving ................. 182 Exterior ................4 Running in..............182 Passenger compartment ..........6 Starting, stopping the engine........183 Driver's position ............... 8 Gear control ..............188 Driving aids ..............10 Special features of Diesel versions ......192 Safety on board .............
Page 5 CONTENTS Wiper blades: replacement.......... 357 Fuses ................359 Fitting a radio ............... 363 Installation and use of accessories......364 Operating faults ............366 Technical specifications ............ 374 Information about the vehicle ........374 Replacement parts and repairs ........382 Service sheets ............. 383 Anticorrosion check .............
Page 6 EXTERIOR 1 4 - We l c o m e a b o a r d y o u r v e h i c l e...
Page 7 EXTERIOR 1. Electric windows �� 296 1 Windscreen wiper(s) �� 296 Demisting �� 284 �� 288 2. Bodywork maintenance �� 323 3. Key/remote control �� 44 Locking/unlocking the doors �� 44 4. Fuel flap for combustion version Filling with fuel �� 170 5. Rear view mirrors �� 155 �� 156 6.
Page 8 PASSENGER COMPARTMENT 1 6 - We l c o m e a b o a r d y o u r v e h i c l e...
Page 9 PASSENGER COMPARTMENT 1. Adjusting your driving position �� 68 1 2. Passenger compartment storage/fittings �� 301 3. Rear bench seat �� 67 Rear headrests �� 67 4. Transporting objects �� 307 5. Child safety �� 86 6. Front headrests �� 62 Front seats �� 63 We l c o m e a b o a r d y o u r v e h i c l e - 7...
Page 10 DRIVER'S POSITION 1 8 - We l c o m e a b o a r d y o u r v e h i c l e...
Page 11 DRIVER'S POSITION 1. Exterior lighting �� 160 1 2. Instrument panel �� 148 �� 139 3. Window wiper(s)/washer(s) control �� 166 4. Multimedia screen �� 144 5. Heating system/air conditioning �� 279 6. Centre console storage compartment/Charging zone �� 301 7. Gear lever �� 190 8. Ignition switch �� 184 9.
Page 12 DRIVING AIDS 1 1 0 - We l c o m e a b o a r d y o u r v e h i c l e...
Page 13 DRIVING AIDS – Stop and Start �� 184 1 – Tyre pressure loss warning �� 208 – Driver correction devices and aids �� 212: – ABS (anti-lock braking system) – ESC (electronic stability control) – Braking assistance – Hill start assistance – Additional driving aid functions �� 216: –...
Page 14 SAFETY ON BOARD 1 1 2 - We l c o m e a b o a r d y o u r v e h i c l e...
Page 15 SAFETY ON BOARD 1. Airbags Front �� 77 1 2. Front passenger airbag inhibition �� 116 3. Seat belts �� 68 4. Airbags side �� 82 We l c o m e a b o a r d y o u r v e h i c l e - 1 3...
Page 16 IDENTIFYING A VEHICLE - LABELS 1 1 4 - We l c o m e a b o a r d y o u r v e h i c l e...
Page 17 IDENTIFYING A VEHICLE - LABELS 1. Vehicle identification plate �� 374 1 2. Vehicle identification number reminder �� 374 3. Technical information for the emergency services �� 374 4. Tyre pressure labels �� 208 �� 329 5. Engine identification �� 375 We l c o m e a b o a r d y o u r v e h i c l e - 1 5...
Page 18 THE ENGINE COMPARTMENT (ROUTINE MAINTENANCE) 1 Combustion version 1 6 - We l c o m e a b o a r d y o u r v e h i c l e...
Page 19 THE ENGINE COMPARTMENT (ROUTINE MAINTENANCE) 1. 12 Volt battery �� 321 1 2. Coolant �� 316 3. Brake fluid �� 318 4. Engine oil dipstick �� 312 5. Opening the bonnet �� 311 6. Coolant �� 316 7. Engine oil filler cap �� 312 We l c o m e a b o a r d y o u r v e h i c l e - 1 7...
Page 20 THE ENGINE COMPARTMENT (ROUTINE MAINTENANCE) 1 Electric version 1 8 - We l c o m e a b o a r d y o u r v e h i c l e...
Page 21 THE ENGINE COMPARTMENT (ROUTINE MAINTENANCE) 1. 12 Volt battery �� 321 1 2. Engine coolant �� 316 3. Brake fluid �� 318 4. Opening the bonnet �� 311 5. Heating circuit coolant �� 316 6. Traction battery coolant �� 316 7. Screen washer fluid �� 318 We l c o m e a b o a r d y o u r v e h i c l e - 1 9...
Page 22 BREAKDOWN RECOVERY 1 2 0 - We l c o m e a b o a r d y o u r v e h i c l e...
Page 23 BREAKDOWN RECOVERY 1. Replacing windscreen wiper blade(s) �� 357 1 2. Puncture: a. Tools �� 334 b. Emergency spare wheel �� 336 c. Changing a wheel �� 337 3. Fuses �� 359 4. Rear towing point �� 346 5. Replacing rear light bulbs �� 351 6. Front towing point �� 346 7.
Page 24 VEHICLE E-TECH 100% ELECTRIC (EV) Introduction 2 2 2 - G e t t i n g t o k n o w y o u r v e h i c l e...
Page 25 VEHICLE E-TECH 100% ELECTRIC (EV) – the vehicle multimedia screen. Your vehicle range will depend on the 1 400 V traction battery traction battery charge level and also For more information, refer to the mul 2 Electric charging connection (pas on your driving style �� 205. timedia equipment instructions or con senger side) 2 tact an Approved Dealer.
Page 26 VEHICLE E-TECH 100% ELECTRIC (EV) The A symbol identifies the electrical Bad weather, flooded roads: elements in your vehicle which may The vehicle drive system Do not drive through floods present safety risks. in an electric vehicle us if the depth of water is 2 es a direct voltage of ap...
Page 27 VEHICLE E-TECH 100% ELECTRIC (EV) Driver obstruction Your electric vehicle is On the driver's side, only silent. Before leaving it, 2 use mats suitable for the with your foot on the vehicle, attached with brake, stop the engine. the pre-fitted components, and RISK OF SERIOUS INJURY check the fitting regularly.
Page 28 VEHICLE E-TECH 100% ELECTRIC (EV) Important recommendations 2 Please read these instructions carefully. Failure to follow these instructions may lead to a risk of fire, serious in jury or electric shocks which could result in death. In the event of an accident or impact In the event of an accident or an impact to the underside of the vehicle (e.g.
Page 29 VEHICLE E-TECH 100% ELECTRIC (EV) Risk of electric shock and a risk to life. 2 G e t t i n g t o k n o w y o u r v e h i c l e - 2 7...
Page 30 VEHICLE E-TECH 100% ELECTRIC (EV) Charging 2 Charging schematic diagram 2 8 - G e t t i n g t o k n o w y o u r v e h i c l e...
Page 31 VEHICLE E-TECH 100% ELECTRIC (EV) 1 Specific wall socket or recharging terminal 2 Charging cable 2 3 Electric charging connection (pas senger side) If you have any questions regarding the equipment needed for charging, please ask an authorised dealer. G e t t i n g t o k n o w y o u r v e h i c l e - 2 9...
Page 32 VEHICLE E-TECH 100% ELECTRIC (EV) Important recommendations for charging your vehicle 2 Please read these instructions carefully. Failure to follow these instructions may lead to a risk of fire, serious in jury or electric shocks which could result in death. Charging Do not do anything to the vehicle during charging (washing, working in the engine compartment, etc.).
Page 33 VEHICLE E-TECH 100% ELECTRIC (EV) – occasional charge using a domestic Charging lead A Before cleaning the charg socket, (8 A charge) when you are not at home, for example. ing lead, make sure the 2 lead is disconnected. In all cases, sockets must be fitted as stated in the instructions provided with Clean the cable using a cloth the charging lead B .
Page 34 VEHICLE E-TECH 100% ELECTRIC (EV) If a malfunction occurs dur ing the charging process 2 (red warning light appears on the unit D ), stop charging im mediately. Please refer to cord in structions. 3 2 - G e t t i n g t o k n o w y o u r v e h i c l e...
Page 35 VEHICLE E-TECH 100% ELECTRIC (EV) Important recommendations for charging your vehicle 2 Important recommendations for charging your vehicle Please read these instructions carefully. Failure to follow these instructions may lead to a risk of fire, serious in jury or electric shocks which could result in death. Choice of charging cord The standard charging cords supplied with the vehicle have been designed specifically for this vehicle. It is designed to pro...
Page 36 VEHICLE E-TECH 100% ELECTRIC (EV) Charging types that conform to Eu ropean standards 2 Alternating current (AC) If the information is displayed on the vehicle charging flap, follow the in structions below. Before plugging in a charging lead, check that: – the colour and one of the letters of the input socket 1 correspond to the colour and one of the letters on the end 4 of the lead;...
Page 37 VEHICLE E-TECH 100% ELECTRIC (EV) Labels Charging type Alternating current (AC) 2 Charging terminal 1 /Charging ca Connection Vehicle 3 /Charging cable 5 ble 4 Charging types that conform to European standards (for all other cases, please consult an approved dealer). G e t t i n g t o k n o w y o u r v e h i c l e - 3 5...
Page 38 VEHICLE E-TECH 100% ELECTRIC (EV) Direct current (DC) 2 If the information is displayed on the vehicle charging flap, follow the in structions below. Before plugging in a charging lead, make sure that the colour and one of the letters on the inlet socket 3 corre spond to the colour and one of the let...
Page 39 VEHICLE E-TECH 100% ELECTRIC (EV) Labels Charging type Direct current (DC) 2 Connection Vehicle 3 /Charging lead 5 Charging types that conform to Euro pean standards (for all other cases, please consult an approved dealer). G e t t i n g t o k n o w y o u r v e h i c l e - 3 7...
Page 40 VEHICLE E-TECH 100% ELECTRIC (EV) There are also one or two buttons (de fore vary between stopping and Electric charging socket 3 pending on the vehicle) located inside restarting the vehicle if the battery is the charging flap: cold or warm. 2 To preserve the service life of your –...
Page 41 VEHICLE E-TECH 100% ELECTRIC (EV) Recharging the traction battery If you have just accepted a system update via the mul 2 timedia system, the traction battery charging will be delayed or cancelled. Wait for the update to be complet ed before connecting the charging lead to the vehicle. For more in formation on system updates, please refer to the multimedia in structions.
Page 42 VEHICLE E-TECH 100% ELECTRIC (EV) If fast-charging the vehicle The traction battery charg (DC), the charging cable ing time depends on the 2 between your vehicle and amount of energy remain the charging terminal must not ex ing and the power delivered by ceed 30 metres. the charging terminal. The infor If in doubt about the length of the mation is displayed on the instru...
Page 43 VEHICLE E-TECH 100% ELECTRIC (EV) 2 – the battery refill rate; The display on the instrument panel Precautions to take when removing – an estimate of the remaining charg disappears after a few seconds. It from the socket ing time (this is not displayed after the reappears on the instrument panel –...
Page 44 VEHICLE E-TECH 100% ELECTRIC (EV) – store the cable 2 . charging operation according to the The label 12 located on the right-hand status of the warning light 9 : side reminds you of the following in Note: immediately after a long period structions: of charging the traction battery, the –...
Page 45 VEHICLE E-TECH 100% ELECTRIC (EV) Charging programming When the programming is confirmed, the indicator light lights up on 2 the instrument panel. Note: charging will start if the engine is switched off, the vehicle is connected to a power supply and access is autho rised. If you have just accepted a system update via the mul...
Page 46 KEY, REMOTE CONTROL General information The key must not be used Driver's responsibility for any function other than when parking or stop 2 Radio frequency remote control A those described in the ping the vehicle handbook (removing the cap from Never leave an animal, a bottle, etc.).
Page 47 KEY, REMOTE CONTROL Radio frequency remote control B The key must not be used Driver's responsibility for any function other than when parking or stop 2 those described in the ping the vehicle handbook (removing the cap from Never leave an animal, a bottle, etc.).
Page 48 KEY, REMOTE CONTROL remote control, the doors will lock again automatically. For replacement, or if you Driver's responsibility require an additional re when parking or stop 2 Interference mote control. ping the vehicle You must only contact an ap Never leave an animal, Interference by factors in the immedi ate vicinity (external installations or the proved Dealer.
Page 49 KEY, REMOTE CONTROL Locking the doors on the vehicle, from the multimedia screen �� 144. Press button 4 . Radio frequency remote control A Note: in the event of disconnection/re The hazard warning lights and side in 2 placement of the 12 Volt battery, the dicator lights flash twice to indicate "Access" mode will be reconfigured by locking.
Page 50 KEY, REMOTE CONTROL Radio frequency remote control B The hazard warning lights and side in Driver's responsibility dicator lights flash twice to indicate locking. when parking or stop 2 ping the vehicle Depending on the vehicle, press and hold button 4 to lock the vehicle and Never leave an animal, close the front windows.
Page 51 KEY, REMOTE CONTROL Deadlocking Locking is confirmed by two slow To lock/unlock the doors flashes and three quick flashes of from the inside �� 57. the hazard warning lights and side in dicator lights. 2 To deactivate deadlocking Driver's responsibility Press button 3 once. when parking or stop Unlocking is indicated by one flash of ping the vehicle the hazard warning lights and the indi...
Page 52 KEY, REMOTE CONTROL When they need to be replaced, be sure to use 2 the same or equivalent type of battery (consult an Approved Dealer). The batteries are available from approved Dealers, and their service life ap proximately two years. Check that there is no dye on the battery: risk of an incorrect electrical contact.
Page 53 KEY, REMOTE CONTROL When replacing: – make sure that the 2 batteries are correctly in serted. Risk of explosion. – if the flap does not close cor rectly, do not use and keep out of reach of children. Precautions relating to batteries: – keep batteries (new or used) out of reach of children; –...
Page 54 DOORS AND OPENING ELEMENTS Opening/closing from the inside Lights-on reminder audible alarm Front doors If you have switched off the ignition and left the lights switched on, a warn 2 Opening/closing from the outside ing buzzer will sound when a door is opened. Driver's responsibility when parking or stop ping the vehicle Never leave an animal, child or adult who is not selfsuffi...
Page 55 DOORS AND OPENING ELEMENTS Opening the doors to 180° Rear doors Opening from the outside 2 Pull the lever 3 to open the door. Open the door, but not fully. Remove the tie rod 6 from its housing If the vehicle is parked Unlock the door using the remote con...
Page 56 DOORS AND OPENING ELEMENTS Opening the doors to 270° Rear hinged doors A For your safety, check that all the vehicle’s 2 doors are properly closed before starting the engine. Rear hinged doors B Remove the checkstrap from its hous Opening from the inside ing as when opening to 180°. Open the door fully until the magnets 7 make To open the vehicle from the inside, contact.
Page 57 DOORS AND OPENING ELEMENTS Closing from the inside With the button 11 in the locked posi Sliding side door tion C , move it to the left. Partially close the right-hand door then Opening/closing from the outside slam it shut. Manual locking 2 Repeat the same procedure with the left-hand door using the handle 9 .
Page 58 DOORS AND OPENING ELEMENTS Opening/closing from the inside Manual locking, unlocking from the Child locks inside 2 With the door open, turn the lever 4 Opening from the inside Lift the button 3 to unlock the door, downwards and close the door. then lower it to lock it.
Page 59 DOORS AND OPENING ELEMENTS Manual locking Locking, unlocking the opening Recommendations con elements and doors cerning the sliding side 2 If the remote control does not work door. Care must be taken In some cases, the radio frequency when opening or closing the slid remote control may not work: ing door, as is the case for any of –...
Page 60 DOORS AND OPENING ELEMENTS Manual locking of the front passen Interior locking/unlocking door con Sliding side door and rear hinged ger door and, depending on the trol doors vehicle, the rear hinged doors 2 Front doors The switch 5 controls the rear hinged With the door open, turn the screw 3 doors and, depending on the vehicle, The switch 4 controls all the doors.
Page 61 DOORS AND OPENING ELEMENTS Locking the doors with the tailgate Operating principle the sliding side door and the rear open hinged doors. After the vehicle is started, the system To lock the vehicle leaving a door open automatically locks the doors when Locking the opening elements 2 ...
Page 62 DOORS AND OPENING ELEMENTS switch indicator light comes on when the doors are locked. To deactivate it: with the ignition on, 2 press and hold the switch 1 for ap proximately five seconds until the "Au to Door Lock OFF" message is dis played on the instrument panel. The warning light goes out. Driver's responsibility If you decide to keep the doors locked when you...
Page 63 DOORS AND OPENING ELEMENTS Operating faults If you experience an operating fault 2 (no automatic locking, the indicator light on the switch 1 does not light up when trying to lock the opening ele ments, etc.), first check that the open ing elements are properly closed. If they are properly closed and the fault is still present, contact an approved Dealer.
Page 64 FRONT SEATS headrest to the desired height by Front headrests pressing tab 1 . 2 Adjusting the angle of the headrest (depending on the vehicle) The headrest is an im portant safety compo To raise the headrest nent: ensure that it is in Simply slide it up. place and in the correct Push away or approach section B until position.
Page 65 FRONT SEATS To tilt the seatback Front seats Handle the lever 3 . Adjusting seat A 2 Lumbar adjustment (depending on the vehicle) With the ignition on, press the switch – once to activate the maximum tem perature, the two built-in indicator To move a seat forwards or back lights will light up; wards –...
Page 66 FRONT SEATS Adjusting seat with suspension B To adjust the height of the seat base For safety reasons, carry out any adjustments Move the lever 8 as many times as 2 while the vehicle is sta necessary upwards or downwards. tionary. Lumbar adjustment We would advise you not to re cline the seatbacks too far to en...
Page 67 FRONT SEATS To adjust the seat suspension Adjusting the pivoting seat C Adjusting the height of the arm rests 2 With the vehicle stationary, turn the To move the seat forwards or back control knob 10 to the right to stiffen – upwards – raise the armrest 15 to the suspension or to the left to slacken the desired position;...
Page 68 FRONT SEATS Lumbar adjustment – move the seat as far back as possi ble; – adjust the seatback to the upright 2 position; – open the door; – pull the handle 13 towards the in side of the vehicle and rotate the seat to unlock it from its "forward-facing" position. Returning to the driving position –...
Page 69 REAR SEATS headrest to the desired height by Special note for three-seater Rear headrests pressing tab 1 . versions 2 This version differs in that it has rear To raise the headrest seatbelts and headrests on the rear The headrest is an im side seats only. Never seat a passen Simply slide it up.
Page 70 SEAT BELTS – adjust the position of the steering Seat belts Incorrectly adjusted or wheel. twisted seat belts may 2 Adjusting the seat belts Adjusting your driving position cause injuries in the event of an accident. Always wear your seat belt when trav Use one seat belt per person, elling in your vehicle.
Page 71 SEAT BELTS – position the lap belt 2 so that it lies If your seat belt is completely jammed, Instrument panel A flat on the thighs and against the pull slowly, but firmly so that just over 3 pelvis. cm unwinds. Allow it to return slightly before attempting to unwind it again.
Page 72 SEAT BELTS Driver’s seat belt reminder and, Rear seat belt reminder warning warning light appears on the depending on the vehicle, front light (depending on the vehicle) passengers' seat belt reminder central display 6 if a front seat is occu With the doors closed, the graphic 7 is 2 pied and the seat belt is not fastened.
Page 73 SEAT BELTS – a beep sounds for around 30 sec – symbol in red: seat occupied and onds; seat belt not fastened; – symbol in grey: seat not occupied. 2 – the graphic 7 is displayed for at With the doors closed, the warn ing light appears on the central dis least 60 seconds and the sym...
Page 74 SEAT BELTS Adjusting the height of the front – the graphic 8 is displayed for ap graphic 10 appears during approxi seat belts proximately 180 seconds and the sym mately 60 seconds every time one of the rear seat belts is fastened or un bol for the seat concerned appears in 2 red. fastened. Always make sure that the front pas When the vehicle speed reaches or sengers are properly fastened in and exceeds 12 mph (20 km/h), if one of that the number of seat belts indicated...
Page 75 SEAT BELTS Seat with armrest(s) 2 Ensure that the seat belt is passed un derneath the armrest 10 , check that the buckle 3 is fastened in the catch Lower the armrest 10 on the door side (movement A ). Unwind the belt slowly and smoothly. Pass the lap belt under the armrest 10 and the shoulder strap over the arm...
Page 76 SEAT BELTS Warning The following information applies to the vehicle’s front and rear seat belts. 2 – No modification must be made to the originally-fitted restraint system components (seat belts, seats and their mountings). For special operations (e.g. fitting a child seat), please contact an approved dealer. –...
Page 77 SEAT BELTS Rear seat belts Check that the rear seat Incorrectly adjusted or belts are positioned and twisted seat belts may 2 Rear seat belts with inertia reel operating correctly each cause injuries in the time the rear seats are event of an accident.
Page 78 SEAT BELTS This version differs in that it has rear seatbelts and headrests on the rear side seats only. Never seat a passen 2 ger in the centre seat area. The label A informs you that it is pro hibited to seat passengers in areas other than the seats provided. Check that the rear seat belts are positioned and operating correctly each time the rear seats are...
Page 79 ADDITIONAL SAFETY DEVICES Pretensioners Methods of restraint in addition – Have the entire re to the front seat belts straint system checked 2 following an accident. Depending on the vehicle, they may comprise: – No operation whatsoever is per mitted on any part of the system – seat belt pretensioners; (pretensioners, Airbags, comput...
Page 80 ADDITIONAL SAFETY DEVICES driver and passenger front Airbags – remote sensors. The airbag system uses Operation pyrotechnic principles. This system is only operational when 2 This explains why, when the ignition is switched on. the airbag inflates, it will If a severe frontal impact occurs, the generate heat, produce smoke airbag(s) inflate(s) rapidly, cushioning (this does not mean that a fire is...
Page 81 ADDITIONAL SAFETY DEVICES In a frontal impact against a rigid (nondeformable) surface at an im pact speed equal to or greater than 16 mph (25 km/h). 2 In a side impact with another vehi The pretensioners or Airbags may cle of an equivalent or higher cate be triggered by: gory, at an impact speed equal to or –...
Page 82 ADDITIONAL SAFETY DEVICES 2 The pretensioners or Airbags may – side impact at the front or rear of the not be triggered by: vehicle; – frontal impact against an obstacle – a rear impact, however severe; with a sharp angle; –...
Page 83 ADDITIONAL SAFETY DEVICES Warning All of the warnings below are given so that the airbagis not obstructed in any way when it is inflated and also to pre 2 vent the risk of serious injuries caused by items which may be dislodged when it inflates. Warnings in relation to the driver's airbag –...
Page 84 ADDITIONAL SAFETY DEVICES Side protection devices 2 Side Airbags These airbag may be fitted to the front seats and are deployed at the sides of the seats (door side) to protect the oc cupants in the event of a severe side impact. Depending on the vehicle, a marking on the wind screen informs you of the presence of additional means of restraint (airbag, pretensioners,...
Page 85 ADDITIONAL SAFETY DEVICES Warning 2 Warning related to the side airbag airbag – Fitting seat covers: seats equipped with an airbag require covers specifically designed for your vehicle. Con tact an approved dealer to find out if these covers are available. The use of any covers other than those designed for your vehicle (including those designed for another vehicle) may affect the operation of the Airbags and reduce your pro...
Page 86 ADDITIONAL SAFETY DEVICES Additional methods of restraint All of the warnings below are given so that the airbagis not obstructed in any way when it is inflated and also to pre 2 vent the risk of serious injuries caused by items which may be dislodged when it inflates. The airbag is designed to complement the action of the seat belt.
Page 87 ADDITIONAL SAFETY DEVICES The 1 warning light comes on Operating faults when the ignition is switched on and goes out after a few seconds. 2 If it does not light up when the ignition is switched on, or if it lights up when the engine is running, this indicates a fault in the system.
Page 88 CHILD SAFETY General information A collision at 31 mph (50 Driver's responsibility km/ h ) is the same as when parking or stop 2 Carrying children falling a distance of 10 ping the vehicle metres. Transporting a Never leave an animal, Please ensure that you comply with child without a restraint is the child or adult who is not selfsuffi...
Page 89 CHILD SAFETY proved Dealer to find out which seats are recommended for your vehicle. Set a good example by al Never leave a child unat ways fastening your seat tended in the vehicle. The regulations on transporting chil 2 dren are specific to each country. The belt and teaching your Check that your child is use of a child seat during transport de...
Page 90 CHILD SAFETY Forward-facing child seats Booster cushions Choosing a child seat Rear-facing child seats 2 Up to 18 kg or 4 years, the child may From 15 kg or 4 years, the child can travel on a forward-facing seat. travel using a booster seat, which will Choose your seat according the child's enable the seat belt to be adapted to A baby’s head is, proportionally, heav...
Page 91 CHILD SAFETY Choosing a child seat mounting The seat belt must never Attachment via the seat belt be twisted or the tension 2 relieved. Never pass the The seat belt must be adjusted in or shoulder strap under the der to ensure it works in the event of arm or behind the back.
Page 92 CHILD SEATS leave enough space in the rear seats Fitting a child seat, general in for passengers or other child seats). In the case of a rear-facing child seat, do formation 2 not let it touch the dashboard or move Some seats are not suitable for fitting it to the furthest forward position.
Page 93 2 G e t t i n g t o k n o w y o u r v e h i c l e - 9 1...
Page 94 CHILD SEATS Attachment by seat belt 2 2-seater van version Fitting diagram 9 2 - G e t t i n g t o k n o w y o u r v e h i c l e...
Page 95 CHILD SEATS Check the status of the airbag before fitting a child seat or allowing a passenger to use the seat. 2 Seat not suitable for fitting child seats. Seat equipped for attaching a "Universal" approved seat using a seatbelt. Seat enabling a child seat with "B2"...
Page 96 CHILD SEATS Installation table The table below summarises the information already shown on the previous diagram in order to ensure the regulations 2 in force are respected. 2-seater van version Front passenger seat Child seat group Weight of the child Passenger Airbag activated Without passenger airbag or deactivated Rear-facing shell seat...
Page 97 2 G e t t i n g t o k n o w y o u r v e h i c l e - 9 5...
Page 98 CHILD SEATS 3-seater van version 2 Fitting diagram 9 6 - G e t t i n g t o k n o w y o u r v e h i c l e...
Page 99 CHILD SEATS Check the status of the airbag before fitting a child seat or allowing a passenger to use the seat. 2 Seat not suitable for fitting child seats. Seat equipped for attaching a "Universal" approved seat using a seatbelt. Seat enabling a child seat with "B2"...
Page 100 CHILD SEATS Installation table The table below summarises the information already shown on the previous diagram in order to ensure the regulations 2 in force are respected. 3-seater van version Airbag activated on passenger side Without passenger airbag or deactivated Child seat Weight of the Central front pas...
Page 101 2 G e t t i n g t o k n o w y o u r v e h i c l e - 9 9...
Page 102 CHILD SEATS 5-seater double cab version 2 Fitting diagram 1 0 0 - G e t t i n g t o k n o w y o u r v e h i c l e...
Page 103 CHILD SEATS Check the status of the airbag before fitting a child seat or allowing a passenger to use the seat. 2 Seat not suitable for fitting child seats. Carrying a passenger is STRICTLY PROHIBITED. Seat equipped for attaching a "Universal" approved seat using a seatbelt. Seat enabling a child seat with "B2"...
Page 104 CHILD SEATS Installation table The table below summarises the information already shown on the previous diagram in order to ensure the regulations 2 in force are respected. 5-seater double cab version Front passenger seat Rear side Rear centre Weight of the Passenger Airbag ac...
Page 105 CHILD SEATS RISK OF DEATH OR SERIOUS INJURY, before installing a child seat: (1) on the front passenger seat, check that the airbag has been deactivated �� 116; (2) position the vehicle seat as far back and as high as possible. Tilt the seatback slightly �� 63. Adjust the seat 2 ...
Page 106 CHILD SEATS 6-seater double cab version (3 front seats and 3 rear seats) 2 Fitting diagram 1 0 4 - G e t t i n g t o k n o w y o u r v e h i c l e...
Page 107 CHILD SEATS Check the status of the airbag before fitting a child seat or allowing a passenger to use the seat. 2 Seat not suitable for fitting child seats. Carrying a passenger is STRICTLY PROHIBITED. Seat equipped for attaching a "Universal" approved seat using a seatbelt. Seat enabling a child seat with "B2"...
Page 108 CHILD SEATS Installation table The table below summarises the information already shown on the previous diagram in order to ensure the regulations 2 in force are respected. 6-seater double cab version (3 Airbag activated on passen Without passenger airbag or front seats and 3 rear seats) ger side deactivated...
Page 109 CHILD SEATS (1) RISK OF DEATH OR SERIOUS INJURY, before installing a child seat: on the front passenger seat, check that the airbag has been deactivated �� 116. 2 G e t t i n g t o k n o w y o u r v e h i c l e - 1 0 7...
Page 110 CHILD SEATS 6-seater double cab version (2 front seats and 4 rear seats) 2 Fitting diagram 1 0 8 - G e t t i n g t o k n o w y o u r v e h i c l e...
Page 111 CHILD SEATS Check the status of the airbag before fitting a child seat or allowing a passenger to use the seat. 2 Seat not suitable for fitting child seats. Seat equipped for attaching a "Universal" approved seat using a seatbelt. Seat enabling a child seat with "B2"...
Page 112 CHILD SEATS Installation table The table below summarises the information already shown on the previous diagram in order to ensure the regulations 2 in force are respected. 6-seater double cab version (2 front seats and 4 rear Front passenger seat Rear side Rear central seats)
Page 113 CHILD SEATS RISK OF DEATH OR SERIOUS INJURY, before installing a child seat: (1) on the front passenger seat, check that the airbag has been deactivated �� 116. (2) position the vehicle seat as far back and as high as possible. Tilt the seatback slightly �� 63. Adjust the seat 2 ...
Page 114 CHILD SEATS 7-seater double cab version 2 Fitting diagram 11 2 - G e t t i n g t o k n o w y o u r v e h i c l e...
Page 115 CHILD SEATS Check the status of the airbag before fitting a child seat or allowing a passenger to use the seat. 2 Seat not suitable for fitting child seats. Seat equipped for attaching a "Universal" approved seat using a seatbelt. Seat enabling a child seat with "B2"...
Page 116 CHILD SEATS Installation table The table below summarises the information already shown on the previous diagram in order to ensure the regulations 2 in force are respected. 7seater double cab ver Airbag activated on passenger Without passenger airbag or sion side deactivated Rear side...
Page 117 CHILD SEATS (1) RISK OF DEATH OR SERIOUS INJURY, before installing a child seat: on the front passenger seat, check that the airbag has been deactivated �� 116. 2 G e t t i n g t o k n o w y o u r v e h i c l e - 11 5...
Page 118 CHILD SAFETY: DEACTIVATING, ACTIVATING THE FRONT PASSENGER AIRBAG Front passenger airbag deacti The passenger airbag vation may only be activated or 2 deactivated when the vehicle is stationary with the ignition off. If it is interfered with when the ve hicle is being driven, indicator lights will come on. Switch the ignition off then on again to reset the airbag in accor...
Page 119 CHILD SAFETY: DEACTIVATING, ACTIVATING THE FRONT PASSENGER AIRBAG bels above) are provided to remind The front passenger airbag is activat you of these instructions. Activating the front passenger Operating faults 2 airbag It is forbidden to fit a rear-facing child seat to the front passenger seat if the airbag activation/deactivation system is faulty.
Page 120 2 11 8 - G e t t i n g t o k n o w y o u r v e h i c l e...
Page 121 2 G e t t i n g t o k n o w y o u r v e h i c l e - 11 9...
Page 122 DRIVING POSITION Driver's position left-hand drive combustion version 2 1 2 0 - G e t t i n g t o k n o w y o u r v e h i c l e...
Page 123 DRIVING POSITION 17. Heating and ventilation controls. The fittings described below DE 28. Bonnet release control. PEND ON THE VEHICLE VERSION 18. Switches: AND COUNTRY. – activating/deactivating the Stop and 2 1. Demister outlets for side windows. Start function; – the traction control; 2.
Page 124 DRIVING POSITION Driver's position left-hand drive electric version 2 1 2 2 - G e t t i n g t o k n o w y o u r v e h i c l e...
Page 125 DRIVING POSITION 17. Induction charging zone or centre – electric heated windscreen. The fittings described below DE console storage compartment. PEND ON THE VEHICLE VERSION 28. Bonnet release control. AND COUNTRY. 18. Heating and ventilation controls. 2 1. Demister outlets for side windows. 19.
Page 126 DRIVING POSITION Driver's position righthand dri ve combustion version 2 1 2 4 - G e t t i n g t o k n o w y o u r v e h i c l e...
Page 127 DRIVING POSITION 14. Controls for: 27. Glovebox or storage compartment The fittings described below DE – activating/deactivating the "My Safe PEND ON THE VEHICLE VERSION 28. Bonnet release control. AND COUNTRY. ty" function; 2 – lighting rheostat for control instru 1. Demister outlets for side windows. ments; 2.
Page 128 DRIVING POSITION Driver's position righthand dri ve electric version 2 1 2 6 - G e t t i n g t o k n o w y o u r v e h i c l e...
Page 129 DRIVING POSITION 14. Cup holders. 27. Glovebox or storage compartment The fittings described below DE PEND ON THE VEHICLE VERSION 15. Controls for: 28. Bonnet release control. AND COUNTRY. – activating/deactivating the "My Safe 2 1. Demister outlets for side windows. ty" function; –...
Page 130 TRIP COMPUTER (the display depends on the vehicle one of the journey parameters select General information ed on the display, press button 2 or 3 equipment and country): until the display resets to zero. a) total mileage and trip mileage Depending on the vehicle, this in 2 recorder; cludes the following functions: Resetting the trip mileage recorder b) journey settings: –...
Page 131 TRIP COMPUTER Vehicle fitted with trip computer B Automatic resetting of the journey Press switch 1 to navigate between parameters zones and select the functions by pressing switches 2 or 3 (the display Resetting occurs automatically when depends on the vehicle equipment and 2 ...
Page 132 TRIP COMPUTER Manual reset Select the trip setting to reset, then press and hold the switch 4 to reset 2 the range. Automatic reset The range is automatically reset when the traction battery is fully charged. The calculated value corresponds to an average use, taking into account the exterior temperature. If a particu...
Page 133 TRIP COMPUTER Journey settings The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. 2 Examples of selections Interpreting the display selected – 63,242 miles (101,778 km) a) Total mileage and trip mileage recorder. – 70 miles (112.4 km) Average b) Trip settings: Average consumption: the value is displayed after having travelled at least 400...
Page 134 TRIP COMPUTER Examples of selections Interpreting the display selected Average 2 Average speed since last reset. The value is displayed after driving 400 metres. 76.7 mph (123.4 km/h) 56 mph (90 km/h) c) Current speed (depending on the vehicle). d) Engine coolant temperature. 16°...
Page 135 TRIP COMPUTER Examples of selections Interpreting the display selected Onboard computer with mileagebeforeser 2 vice message e) Service interval. Service in With the ignition on, the engine not running and the display set to "Mileage before service", press button 2 or 3 for approximately five sec 24,855 miles (40,000 onds to display the mileage before service (distance or time to next ser...
Page 136 TRIP COMPUTER Examples of selections Interpreting the display selected Onboard computer with mileagebeforeser 2 vice message Depending on the vehicle, the mileage before an oil change varies according to the driving style (frequent driving at low speed, door-to-door journeys, extensive use at idling speed, towing a trailer, etc.). The distance remaining until the next oil change can therefore decrease more quickly in some cases than the actual distance travelled.
Page 137 TRIP COMPUTER Examples of selections Interpreting the display selected f) Reset the tyre pressure �� 208. Tyre pressure init. long press 2 g) General settings. Settings (Press and hold) Press button 2 or 3 for approximately five seconds to select the display language. h) Trip log.
Page 138 TRIP COMPUTER Information messages These can help in the vehicle starting phase, or give information about a selection or a driving status. 2 Examples of information messages are given in the following pages. Examples of messages Interpretation of messages Indicates that you have deactivated the traction control func Traction control off tion.
Page 139 TRIP COMPUTER Operating fault messages 2 They appear with the warning light to inform you that you should drive very carefully to an approved dealer as soon as possible. If you fail to follow this recommendation, you risk damaging your vehicle. They disappear when the display selection key is pressed or after several seconds and are stored in the computer log.
Page 140 TRIP COMPUTER Warning messages 2 These appear with the warning light and require you to stop immediately, for your own safety, as soon as traf fic conditions allow. Stop your engine and do not restart it. Call an approved Dealer. Some examples of warning messages are given below.
Page 141 TRIP COMPUTER Rev counter 1 (rpm x 1000) Speedometers 3 and, depending Displays and indicators on the vehicle, 4 (kilometres or miles per hour) 2 Instrument panel A The presence and operation of the display and indicators DEPENDS ON THE LEVEL OF EQUIPMENT AND THE COUNTRY.
Page 142 TRIP COMPUTER Trip computer 5 Selection of views 2 It lights up when the ignition is switched on. In some cases, the ap Fuel gauge 6 Depending on the vehicle, use the pearance of a warning light is accom control 1 to browse and select the var The number of squares lit shows the panied by a message. ious view on the instrument panel B .
Page 143 TRIP COMPUTER driving aids and the information area bustion engine versions, approximately on the instrument panel. 93 mph (150 km/h) or 99 mph (160 km/h), depending on the vehicle. Excessive speed audible alarm 2 3 Driving style indicator �� 200 Depending on the vehicle and country, 4 Battery Information warning light is displayed (traction battery charge rate, estimated...
Page 144 TRIP COMPUTER Left-hand gauge indicator lights Right-hand gauge indicators Instrument panel in miles Vehicles not fitted with a multime dia screen instrument panel A 2 9 Left-hand direction indicator 14 Right-hand direction indicator 10 Warning light 15 Parking brake warning light �� 148 �� 196 11 Tyre under-inflation warning light 16 "Hands off steering wheel"...
Page 145 TRIP COMPUTER Vehicles not fitted with a multime – With the ignition off, press the switch dia screen instrument panel B 1 as many times as required to reach the "Settings" world 6 ; – press control 2 or 3 repeatedly to 2 reach "Vehicle setting", then press switch 4 "OK";...
Page 146 TRIP COMPUTER Vehicle settings personalisation a) "Driving": For safety reasons, carry menu – Direction indicator volume; out any adjustments – Free-wheel; 2 Vehicles fitted with a multimedia – ... while the vehicle is sta screen 1 tionary. b) "Access": – Unlocking the driver’s door; – Lock doors during driving; Vehicles not fitted with a multime...
Page 147 TRIP COMPUTER Press control 4 or 5 repeatedly to – Blind spot; make a further selection (Park Assist reach the "Vehicle settings" menu, – Active braking; sound volume or instrument panel lan – Speed warning; then confirm by pressing "OK". guage). – Fatigue warning; 2 Use control 4 or 5 to browse and se...
Page 148 TRIP COMPUTER Vehicles not fitted with a multime Clock and outdoor temperature dia screen, display A Vehicles fitted with a multimedia 2 screen 1 , navigation system, tele phone, etc. Set the hour using control 3 or 4 , then press the switch 5 "OK" to confirm. Set the minutes using control 3 or 4 , Press the switch 2 as many times as then press the switch 5 "OK" to con...
Page 149 TRIP COMPUTER Vehicles not fitted with a multime dia screen, display B Depending on the vehicle, Exterior temperature If the electrical supply is cut indicator 2 (battery disconnected, bro As ice formation is relat ken supply wire, etc.), the clock ed to climatic exposure, will automatically go back to the local air humidity and tempera right time after a few minutes ture, the external temperature once the system is capable of re...
Page 150 WARNING LIGHTS Instrument panel A or B For your own safety, the The presence and operation of the 2 warning light warning lights DEPEND ON THE requires you to stop im EQUIPMENT AND COUNTRY. mediately, as soon as traffic con ditions allow. Switch off the en gine and do not restart it. Call an approved dealer.
Page 151 WARNING LIGHTS Front fog light tell-tale light Warning light This comes on when the ignition is switched on and goes out after about 2 Rear fog light tell-tale light three seconds. It may light up in con junction with other warning lights and/ Left-hand direction indicator or messages on the instrument panel. tell-tale light It means you should drive very care- fully to an approved Dealer as soon...
Page 152 WARNING LIGHTS �� 212 gine is switched on and goes off after a Traction control warning light few seconds. �� 214 If it comes on while driving, alongside Mode warning light Eco 2 This comes on when Eco mode is acti the warning light , this means vated �� 200. Anti-lock braking warning there is a system fault.
Page 153 WARNING LIGHTS Stop as soon as traffic conditions allow – If it lights up continuously accompa Pedestrian and cyclist and consult an approved dealer. detection warning light at start-up nied by the warning light, �� 247 please consult an authorised dealer as 2 Oil pressure warning light soon as possible;...
Page 154 WARNING LIGHTS restart. Leave the vehicle and consult Engine standby warning Electrotechnical system fault an approved dealer. light warning light �� 184 When it comes on, this indicates an 2 The "EVACUATE IN electrotechnical fault related to the electrical assembly (traction battery SAFETY" message ac...
Page 155 WARNING LIGHTS Display C and rear view mirror On the rear view mirror D warning light and a beep, this means that the electrical circuit is over charged or discharged �� 321. 2 Display C Limited performance warning light This appears when the traction battery temporarily does not deliver its nomi nal power. During this period, vehicle performance is reduced.
Page 156 STEERING Power-assisted steering Adjusting the steering wheel With the engine switched height and depth Variable power assisted steering off, or if there is a system 2 fault, it is still possible to The variable power-assisted steering turn the steering wheel. The force system is equipped with an electronic required will be greater.
Page 157 REAR VIEW Electrically-adjustable rear view Additional rear view mirror 5 Rear view mirrors mirrors 2 Interior rear view mirror (depending on the vehicle) With the ignition on, select the door Lower the sun visor 4 to access the mirror using the switch 2 , then use the special mirror to increase side vision button 3 to adjust it to the desired po...
Page 158 REAR VIEW Camera rear view 2 The various zones seen by the driver When opening one of the vehicle are: doors, the rear view mirror 2 attached Depending on the vehicle, the rear to the roof centre console shows the –...
Page 159 REAR VIEW Operation This function is an addi tional aid. It cannot, 2 therefore, under any cir cumstances replace the vigilance or the responsibility of the driver. The driver should always be ready for sudden incidents while driving: always ensure that there are no small, narrow moving ob stacles (such as a child, animal, pushchair, bicycle, stone, post, etc.) in the blind spot when ma...
Page 160 REAR VIEW Switching off the function Adjusting the display and the cam Depending on your vision, an adaptation time may be 2 necessary to focus on the camera view display. Objects which appear on the edge of the door mirror 2 may be distorted. In very bright light (snow, vehicle in sunshine, etc.), the camera view may be partially disturbed.
Page 161 REAR VIEW screen 7 ) in addition to the information If the black background persists, For safety reasons, available through the rear view mirror switch to "mirror" mode and consult an �� 273 as there remains a rear view approved dealer. carry out any adjust...
Page 162 LIGHTING AND SIGNALS gear lever is in the P position. Other Exterior lighting and signals wise, the "Unavailable position lights" message is displayed on the instru 2 ment panel to inform you that it is not Controls possible to activate the side lights. Dipped beam headlights Manual operation Rotate the ring 3 until the symbol is aligned with the mark 2 .
Page 163 LIGHTING AND SIGNALS Additional cornering lighting Activation/deactivation To return to the dipped beam head lights position, push the stalk 1 again. (depending on the vehicle) To activate the automatic main beam headlights: In forward gear, if the dipped beam or Automatic main beam headlights 2 main beam headlights are on and de Rotate the ring 3 until the "AUTO"...
Page 164 LIGHTING AND SIGNALS warning light and/or the warning The system may encounter The "automatic main light flashes on the instrument panel, difficulties under certain beam headlights" sys this indicates that there is a lighting 2 conditions, including: tem should under no cir fault. cumstances be used to –...
Page 165 LIGHTING AND SIGNALS Fog lights Switching off the lights With the engine off, after opening the driver's door, with the ring 3 in To deactivate the function, rotate the "AUTO" position, pull the handle 1 to rotary switch again to align the mark 4 Front fog light wards you: the side lights and dipped 2 ...
Page 166 LIGHTING AND SIGNALS Headlight beam adjustment Load status Control position Driver only with 2 the luggage 1, 2 or 3 compartment loaded (1) The table below gives some exam ples. In all cases, adjust the control A according to the vehicle load so that the road can be seen and other drivers are not dazzled.
Page 167 AUDIBLE AND VISUAL SIGNALS will return to its original position and Horn the direction indicator light concerned will flash three times. 2 Hazard warning lights Press the steering wheel boss A to sound the horn. Headlight flasher Press the switch 2 . To flash the headlights, pull the stalk 1 This switch activates all four direction towards you, then release.
Page 168 WIPER Vehicle fitted with front wind A. single sweep: a short push will Vehicle fitted with intermittent trigger one sweep of the wipers. screen wiper rain sensor windscreen wipers B. stopping 2 C. intermittent wiping: the wipers may stop for a few seconds between wipes. It is possible to change the in...
Page 169 WIPER The rain sensor is located on the wind matically triggered and remains under be less sensitive or may even not react screen, in front of the interior rear view the driver's control; at all. – in the event of temperatures below mirror. zero, automatic wiping is not activated Special feature 2 ...
Page 170 WIPER Specific front wiper position the wipers have folded down onto the windscreen, then move the stalk 1 to In the event of obstacles on (service position) position A (single sweep). the windscreen (dirt, snow, 2 Before switching on the ignition, place ice etc.), clean the wind...
Page 171 WIPER With the ignition on, pull the stalk 1 then release. Efficiency of a wiper blade A longer pull will trigger, in addition to 2 the windscreen washer, two sweeps of Check the condition of the the wipers followed, a few seconds lat wiper blades. How long they last er, by a third.
Page 172 FUEL TANK add fuel to prevent damage to the fu Filling the tank After filling, check that the el pump. cap and cover are closed. To do this, with the ignition off, fill up Useful capacity of fuel tank: approx 2 with fuel or add at least approximately imately 17.6 gal (80 litres).
Page 173 FUEL TANK To fill up with fuel, the Fuel filler cap: this is a Persistent smell of fuel engine must be off (and specific type. If you notice a persistent 2 not only on standby in If you have to replace it, fuel odour you should: the case of vehicles make sure it is identical...
Page 174 FUEL TANK – turn the ignition key to the "On" posi tion M �� 184 and wait around 10 sec onds before starting to allow the fuel 2 circuit to be primed; – turn the key to D position. If the en gine does not start, repeat the proce dure; – if the engine does not start after ten attempts, please contact an approved dealer.
Page 175 REAGENT TANK Topping up Filling the tank with reagent To fill up with reagent, the engine must be stopped Please ensure that you comply with 2 (not just on standby in the the legislation of your country. case of vehicles with the Stop and It is important to remember that failure Start function).
Page 176 REAGENT TANK Precautions for use km" message is displayed on the in after the reagent has returned to its liq strument panel. uid state. The tank can be filled at the pump. In Special cases If the warning lights and message con other cases, it is essential to read the 2 tinue to appear, there is another information shown on the reagent con The reagent fluid freezes below ap cause.
Page 177 REAGENT TANK Depending on how the vehicle is dri No work whatsoever is ven, they may be displayed before the reagent gauge on the instrument permitted on any part of panel is at the minimum �� 139. 2 the system. To prevent damage, only qualified personnel from our network may work on the system.
Page 178 REAGENT TANK Maintenance/Range The information displayed on the instrument panel may be accompanied by a beep. 2 Indicator lights Messages What to do? "AdBlue Level Correct" (depending on the vehi cle) If the message is displayed when the ignition is switched on, you have less than 1,491 miles (2,400 km) range remaining.
Page 179 REAGENT TANK Indicator lights Messages What to do? flashes or The engine will not start. 2 "0 miles (0 km) lockout fill AdBlue" comes on, depend To restart, you must fill the reagent tank yourself. ing on the vehicle. G e t t i n g t o k n o w y o u r v e h i c l e - 1 7 7...
Page 180 REAGENT TANK System faults When the indicator lights described light up, this may be accompanied by a beep. 2 Indicator lights Message Readings « Check Anti Pollution System » Indicates a fault in the system. Contact your approved « AdBlue quality to check » Dealer as soon as possible. illuminate. « AdBlue injection to check »...
Page 181 REAGENT TANK Alert with no message on the instrument panel 2 Depending on the vehicle, the warning light is displayed according to the reagent level indicated by the gauge 4 on the instrument panel. G e t t i n g t o k n o w y o u r v e h i c l e - 1 7 9...
Page 182 REAGENT TANK Maintenance/Range Gauge 2 Warnings What to do? level Range A Range B comes on. You or an Approved Dealer should fill or top up the reagent tank. flashes for a few seconds at the start of the warn Range C ing and each time the ignition is switched on, then stays Loss of engine power.
Page 183 REAGENT TANK System faults When the indicator lights described light up, this may be accompanied by a beep. 2 Indicator lights Message Readings "Check emission Indicates a fault in the system. Contact your approved Dealer as soon as come on. control"...
Page 184 RUNNING IN (Combustion version) Up to 1,500 km, do not exceed 2,500 rpm or approximately 56 mph (90 km/ h) on the highest gear. After complet ing this mileage you may drive faster, however, it is only after approximately 3 3,720 miles (6,000 km) that you may reasonably expect full performance. During the running in period, do not accelerate hard while the engine is still cold and do not let the engine over-rev.
Page 185 STARTING, STOPPING THE ENGINE Stopping the engine Depending on the vehicle, if a gear is Starting, stopping the engine engaged, the "Press Clutch + Start" With the engine idling, turn the key to message is displayed on the instru the "Stop" position St. ment panel. Press the clutch pedal. Starting the engine Turn the key to the "Start"...
Page 186 STARTING, STOPPING THE ENGINE Ignition switch as soon as the engine starts or, de The system is activated automatically pending on the vehicle, when the when the vehicle is started. "READY" message is displayed on the While driving, the system stops the en instrument panel. gine (standby) when the vehicle is at a Note: after turning the key, it may take standstill (traffic jam, traffic lights, etc).
Page 187 STARTING, STOPPING THE ENGINE Preventing the engine from stand For vehicles equipped with manual ing by gearboxes: To fill up with fuel, the en gine must be stopped (and – the gearbox is in neutral; In certain situations, such as negotiat not put on standby): the ig ing a crossroads for instance, it is pos nition must be switched off �� 183, sible (with the system activated) to –...
Page 188 STARTING, STOPPING THE ENGINE – the brake pedal is released, N posi – the difference between the vehicle – the brake pedal is pressed repeated tion is engaged and the parking brake interior temperature and the automatic ly or there is a braking system require is released; climate control setpoint is too high; ment;...
Page 189 STARTING, STOPPING THE ENGINE Deactivating, activating the func tion Before leaving the vehi cle, the engine must be stopped (not put in standby) �� 183. 3 Press the switch 1 to deactivate the function. The warning light 2 illumi nates. Pressing again will reactivate the sys tem. The warning light 2 on the switch 1 goes out.
Page 190 GEAR CONTROL Electronic selector lever A Electronic selector lever B Gear control, electronic lever Electronic levers Position of selector lever 1 3 P: park, button 2 . P: park, button 2 . R: reverse. R: reverse. N: neutral. N: neutral. D: standard forward gear.
Page 191 GEAR CONTROL then release the lever: it will return to mately five seconds and the "Press the stable position. In some cases (e.g. parking brake pedal" message is displayed on the instrument panel for approximately on a slope), with the brake The position engaged lights up on the five seconds.
Page 192 GEAR CONTROL Note: with the engine running and the according to the cases described earli Gearstick vehicle moving at between approxi mately 0 and 5 mph (8 km/h) in N or D Selecting reverse gear position, you must press the brake For safety reasons, do pedal in order to engage R position. not switch off the ignition 3 Parking the vehicle...
Page 193 GEAR CONTROL An impact to the under side of the vehicle (e.g. striking a post, raised kerb or other street furni ture) may result in damage to the 3 vehicle (e.g. deformation of an axle). To avoid any risk of accident, have your vehicle checked by an approved dealer. D r i v i n g - 1 9 1...
Page 194 SPECIAL FEATURES OF DIESEL VERSIONS Engine smoke opacity label ment or, depending on the vehicle, on the vehicle identification plate �� 374. Diesel engine speed 1. Diesel exhaust emissions. When driving, to avoid damaging the engine, never let the engine Precautions to be taken in win speed exceed 4,500 rpm, regardless of which gear is engaged.
Page 195 SPECIAL FEATURES OF DIESEL VERSIONS panel indicates that the filter is becom companied by an increase in engine the warning light displayed on ing clogged and requires cleaning. speed and operation of the cooling system in order to clean the particle fil the instrument panel comes on, ac Note: depending on the vehicle, when ter. companied by the message " Regener the particle filter is operational and ate the particle filter " to indicate that ...
Page 196 SPECIAL FEATURES OF DIESEL VERSIONS – deactivate the "Stop and Start" �� 184 function if the vehicle is light lit on the instrument panel). Do not start the regener In this case, top up �� 316. equipped with it; ation in a garage or a – go to the "Vehicle" tab in the instru Regeneration is not possible: confined area.
Page 197 SPECIAL FEATURES OF DIESEL VERSIONS If the warning light and, de pending on the vehicle, the warning light appear accompanied by the "WARNING: Engine Failure Risk" 3 message, stop the vehicle and contact an approved dealer. For your own safety, the warning light requires you to stop im...
Page 198 PARKING BRAKE Pull-up handbrake Handbrake Make sure that the hand (depending on the vehicle) brake is properly re leased when driving (red indicator light off), other wise overheating, or even dam 3 age, may occur. When the vehicle is stopped, depending on the gradient and/or the vehicle load, it may be necessary to apply the handbrake by at least two further notches and engage a gear (1 or re...
Page 199 ENVIRONMENT For certain diesel vehicles, this system Your vehicle has been designed with also has a particle filter to reduce the respect for the environment in mind volume of soot particles emitted. for its entire service life: during its pro duction, usage and at the end of its Please make your own contri...
Page 200 ENVIRONMENT – allow these components to be easily removed and reprocessed by special ist companies; – promote a circular economy (re-use, recycling, recovery, etc.) This is particularly true for electrified 3 vehicle batteries. In order to preserve raw material re sources, your vehicle also includes many parts made from recycled plas tics or renewable materials. 1 9 8 - D r i v i n g...
Page 201 MAINTENANCE AND ANTIPOLLUTION ADVICE Have your vehicle adjusted and – If it lights up continuously, contact an Your vehicle complies with criteria for checked by an approved dealer, in ac approved Dealer as soon as possible; recycling and recovering vehicles at – If it flashes, reduce the engine speed cordance with the instructions given in the end of their service life, which en...
Page 202 DRIVING ADVICE, ECO-DRIVING Gear change indicator Informs you about the driving style Eco-driving adopted in real time. You will be noti Depending on the vehicle, to obtain fied by indicator 1 . optimum consumption levels, a warn Fuel consumption is accredited in ac The more petals displayed on the indi ing light on the instrument panel lets cordance with standard regulatory cator 1 , the more your driving is flexi you know the best time to move up or methods.
Page 203 DRIVING ADVICE, ECO-DRIVING This informs you in real time whether Eco acceleration indicator you are accelerating moderately or strongly. (depending on the vehicle) You will be notified by 2 : – green: acceleration is moderate and correct; 3 – white: acceleration is too high; –...
Page 204 DRIVING ADVICE, ECO-DRIVING Activating the function Eco advice is given to help improve Journey record your performance. With your favourite journeys saved, you can compare your performance between trips and the performance of other vehicle users. 3 Please refer to the multimedia instruc tions for further information. Eco mode Eco mode is a function which optimis...
Page 205 DRIVING ADVICE, ECO-DRIVING Deactivating the function Blue "Energy recovery" usage zone A When driving downhill, the Depending on the vehicle, the function "Freewheel" function is de can be deactivated by pressing switch During driving, if you lift your foot off activated in order to use the the accelerator pedal or press the regenerative braking system and/ brake pedal, the electric motor gener...
Page 206 DRIVING ADVICE, ECO-DRIVING – reducing the speed from 80 than the lower edge mph (130 km/h) to 68 mph of the wheel rim. (110 km/h) approximately saves up to 20% of fuel ap proximately; On the driver's side, only – reducing the speed from 56 use mats suitable for the 3 mph (90 km/h) to 50 mph (80 vehicle, attached with...
Page 207 DRIVING ADVICE, ECO-DRIVING – An underinflated tyre increases fuel – Never fill the fuel tank right to the – speed and driving style; consumption. brim to avoid overflow. – road type; – To optimise fuel consumption, set – On vehicles equipped with non- –...
Page 208 DRIVING ADVICE, ECO-DRIVING Road type Heating levels – reducing the speed from approxi mately 75 mph (120 km/h) to 62 mph (100 km/h) allows you to save up to around 20% of range; – reducing your speed from approxi mately 56 mph (90 km/h) to 50 mph 3 (80 km/h) allows you to save up to around 10% of fuel range.
Page 209 DRIVING ADVICE, ECO-DRIVING Tyres 3 An underinflated tyre increases ener gy consumption. Comply with the specified tyre pressures for your vehi cle. When driving, use tyres made by the same manufacturer, with the same di mensions, type and structure as the original tyres. The use of nonregula tion tyres significantly reduces vehicle range�� 329. D r i v i n g - 2 0 7...
Page 210 TYRE PRESSURE LOSS WARNING – press and hold (around 3 seconds) If the vehicle is equipped with the func control 5 to start the reset. The "Learn In the event of a wheel tion, this system monitors the tyre ing Tyre Pressures" message confirms change or swap, a reset pressure. that the reset request for the tyre pres and pairing of the pressure sure reference value has been taken Operating principle sensor identifiers must be per...
Page 211 TYRE PRESSURE LOSS WARNING Reset procedure message table The table below shows the possible messages related to the tyre resetting procedure. Steps Messages Readings 3 With the ignition on and the vehicle stationary, start resetting the pres « Tyre pressure init. long press » sure of all four/six tyres by pressing and holding switch 5 OK. The system has registered the tyre pressure reset request for all four/six « Learning Tyre Pressures »...
Page 212 TYRE PRESSURE LOSS WARNING Replacing wheels/tyres Readjustment of tyre pressures This system requires specific equip ment (wheels, tyres, wheel rims, etc.) The pressure of the four tyres must �� 327. be set when cold (refer to the label lo cated on the edge of the driver's door). Contact and approved dealer in case If the tyre pressures cannot be 3 of: wheel change or swap, or replace...
Page 213 TYRE PRESSURE LOSS WARNING Tyre pressure faults The following table lists the warning messages that appear on the instrument panel 1 when the system detects a tyre pressure fault. The information on the instrument panel signals any potential tyre pressure faults (e.g. deflated or punctured tyre). For 3 ...
Page 214 DRIVER CORRECTION DEVICES AND AIDS Depending on the vehicle, they may in In an emergency, apply Your braking systems clude: firm and continuous pres are partially operational. – an anti-lock braking system sure to the brake pedal. However, it is danger (ABS); There is no need to pump it re ous to brake suddenly –...
Page 215 DRIVER CORRECTION DEVICES AND AIDS tomatically until the drive supplied be cator light flashes on the instru These functions are an comes compatible with the level of grip under the wheel again. ment panel. additional aid in the event of critical driving The system also adjusts the engine Understeer control speed to the grip available under the conditions, enabling the...
Page 216 DRIVER CORRECTION DEVICES AND AIDS Operating principle Operating faults These functions are an The function stabilises the vehicle by: When the system detects an operating additional aid in the fault, the message "Check ABS" ap – asymmetric braking of the front event of critical driving pears on the instrument panel together wheels to reduce shaking caused by conditions, enabling the...
Page 217 DRIVER CORRECTION DEVICES AND AIDS The system holds the vehicle for ap vehicle, the warning light appear proximately two seconds. The brakes on the instrument panel accompanied are then gradually released (the vehi by the "Grip Extend Loose Surface cle will move according to the slope). ON" message. This position enables optimal usage on soft ground (mud, 3 ...
Page 218 ADDITIONAL DRIVING AID FUNCTIONS "All On" mode To switch back to "All On" mode, press My Safety the button 1 once. The indicator light Depending on the vehicle, this mode on the button 1 comes on. includes the following driving assis The "My Safety" function can be used tance functions: to deactivate or activate a set of driver –...
Page 219 ADDITIONAL DRIVING AID FUNCTIONS – select the driving aids to be deacti The "My Safety Custom" vated or activated from the "Perso" mode by repeatedly pressing control 5 settings saved for the "Cus or 6 . Press switch 7 OK to deactivate tom" mode are stored when or activate the driving aids. the engine is last stopped or when the doors are locked.
Page 220 ADDITIONAL DRIVING AID FUNCTIONS Activation/deactivation Activating, deactivating the alert using the "My Safety" button 2 This function is an addi tional driving aid. This Depending on the vehicle, function is not under any according to the length of circumstances intended time following the last time to replace the due care and atten...
Page 221 ADDITIONAL DRIVING AID FUNCTIONS on the button 2 comes on and the – repeatedly press control 6 or 7 to reach the "Lane departure" menu, then warning light or, depending on press switch 8 OK; – press switch 8 OK again to activate the vehicle, the warning light ap...
Page 222 ADDITIONAL DRIVING AID FUNCTIONS Settings – the speed is between approximately warning light or, depending 40 mph (65 km/h) and 106 mph (170 km/h); For safety reasons, carry on the vehicle, the warning light appears in yellow on the instrument out any adjustments panel.
Page 223 ADDITIONAL DRIVING AID FUNCTIONS – "High"; – driving continuously on a line; – approximately four seconds after – "Lane departure anticipation": adjust – depending on the vehicle, press changing lanes; the line detection sensitivity level. To switch 5 and repeatedly press control –...
Page 224 ADDITIONAL DRIVING AID FUNCTIONS – warning light appears in yellow on the instrument panel; – in some cases accompanied by the message: 3 – « Driving assist unavailable » – « Check Driving assist » – « Check Front camera » In these cases, please contact an ap...
Page 225 ADDITIONAL DRIVING AID FUNCTIONS Warning This function is an additional driving aid. This function is not under any circumstances intended to replace the due care and attention of the driver, who should at all times be in control of the vehicle. 3 ...
Page 226 ADDITIONAL DRIVING AID FUNCTIONS Activation/deactivation – performs corrective action on the Lane departure prevention steering system. Depending on the vehicle, You can retake control of according to the length of the vehicle at any time by time following the last time 3 operating the steering the engine was stopped, the func...
Page 227 ADDITIONAL DRIVING AID FUNCTIONS Activating, deactivating the func Activating/deactivating the system on the button 2 comes on and the tion using the "My Safety" button 2 from the trip computer 4 warning light or, depending on the vehicle, the warning light ap pears on the instrument panel; 3 ...
Page 228 ADDITIONAL DRIVING AID FUNCTIONS – repeatedly press control 6 or 7 to – speed is between approximately 40 Depending on the vehicle, the reach the "DRIVING ASSIST" menu, mph (65 km/h) and 106 mph (170 km/ then press switch 8 OK; – repeatedly press control 6 or 7 to or ...
Page 229 ADDITIONAL DRIVING AID FUNCTIONS Adjusting settings from the multi pears on the instrument panel accom warning light continues to flash media screen 3 panied by a beep and, depending on or, depending on the vehicle, the the vehicle, the warning light ap pears in yellow until the driver has re warning light and the indicator 9 gained control of the vehicle. on the side of the crossed line change 3 ...
Page 230 ADDITIONAL DRIVING AID FUNCTIONS Function temporarily unavailable/ – "Vibration": adjust the steering wheel quired to reach the tab or, de disabled vibration for the "Lane departure pre vention" function; The system is no longer available or pending on the vehicle, the tab; – depending on the vehicle, "Lane exit disabled when: anticipation"...
Page 231 ADDITIONAL DRIVING AID FUNCTIONS Operating faults When the system detects an operating fault: – the warning light appears on the instrument panel; 3 or, depending on the vehicle – the warning light appears in yellow on the instrument panel. In some cases, they are accompanied by the following message: –...
Page 232 ADDITIONAL DRIVING AID FUNCTIONS Warning This function is an additional driving aid. This function is not under any circumstances intended to replace the due care and attention of the driver, who should at all times be in control of the vehicle. 3 System servicing/repairs –...
Page 233 ADDITIONAL DRIVING AID FUNCTIONS – the vehicle is towing a trailer or a caravan; – the vehicle is entering an area with several surface markings (an area with road works etc.). 3 D r i v i n g - 2 3 1...
Page 234 ADDITIONAL DRIVING AID FUNCTIONS the equipment, from the two radars in Blind spot warning stalled on each side, the function warns the driver: – when the vehicle speed is above less than 19 mph (30 km/h); – when a vehicle or cyclist is in zone 3 A and travelling at a lower speed than your vehicle, in the same direction;...
Page 235 ADDITIONAL DRIVING AID FUNCTIONS Operation Warning light display 2 If you deactivate the direction indicator, the function will return to the initial Warning light 2 warning (display D ). Note: the alert function is based on in formation from the radar. In certain sit uations (traffic jams, etc.), it may alert 3 any type of moving object that is in zone A or B .
Page 236 ADDITIONAL DRIVING AID FUNCTIONS spot alert off" appears on the instru ment panel if a towbar is electrically – The system’s detec connected to the trailer hitch socket. tion range operates ac cording to a standard Temporarily not available lane width. If you are driving in If a radar is obscured, the message 3 wide traffic lanes, the system may "Side radars no visibility"...
Page 237 ADDITIONAL DRIVING AID FUNCTIONS Warning This function is an additional driving aid. This function is not under any circumstances intended to replace the due care and attention of the driver, who should at all times be in control of the vehicle. 3 ...
Page 238 ADDITIONAL DRIVING AID FUNCTIONS Vehicles fitted with a multimedia Safe distance alert screen 2 This function is an addi tional driving aid. This function is not under any circumstances intended to replace the due care and atten 3 tion of the driver, who should at all times be in control of the vehicle. Location of the camera 1 Make sure the windscreen is not ob...
Page 239 ADDITIONAL DRIVING AID FUNCTIONS – repeatedly press control 5 or 6 to B (green): the time interval is greater reach the "Distance warning" menu, than or equal to around two seconds then press switch 7 OK; (distance between the two vehicles –...
Page 240 ADDITIONAL DRIVING AID FUNCTIONS The measurement is dis played for information: the system does not car ry out any action on the vehicle. 3 This function is not designed for use in urban conditions or for a dynamic driving style (sudden cornering, acceleration, braking, etc.), but rather for stable driving conditions.
Page 241 ADDITIONAL DRIVING AID FUNCTIONS Warning This function is an additional driving aid. This function is not under any circumstances intended to replace the due care and attention of the driver, who should at all times be in control of the vehicle. 3 ...
Page 242 ADDITIONAL DRIVING AID FUNCTIONS Active emergency braking This system can apply – surrounding pedestrians and cy maximum braking to the clists. vehicle until it is completely The system informs the driver if there stationary if necessary. is a risk of head-on collision to enable appropriate emergency manoeuvres For safety reasons, always wear 3...
Page 243 ADDITIONAL DRIVING AID FUNCTIONS Detection of oncoming vehicles in the collision becomes imminent, the the context of a manoeuvre to Special features of warn warning light and the mes change direction ings sage "Brake" appear on the instrument Depending on the speed, panel accompanied by a sound alert. the warning and braking may be Note: activated simultaneously.
Page 244 ADDITIONAL DRIVING AID FUNCTIONS Activation/deactivation Activating, deactivating the system – your vehicle is travelling at a speed from the multimedia screen 2 between approximately 12 mph (20 km/h) and 37 mph (60 km/h). Depending on the vehicle, Detection of vehicles stopped in according to the length of the lane time following the last time 3...
Page 245 ADDITIONAL DRIVING AID FUNCTIONS Adjusting settings from the multi – repeatedly press control 5 or 6 to media screen 2 reach the "Active braking" menu, then press switch 7 OK; – press the 7 OK switch again to acti vate or deactivate the function: 3 – function activated –...
Page 246 ADDITIONAL DRIVING AID FUNCTIONS – repeatedly press control 5 or 6 to the case, this may arise from another reach the "DRIVING ASSIST" menu. cause; contact an approved dealer. Press the 7 OK switch. – repeatedly press control 5 or 6 to Operating faults reach the "Active braking sensitivity"...
Page 247 ADDITIONAL DRIVING AID FUNCTIONS Warning This function is an additional driving aid. This function is not under any circumstances intended to replace the due care and attention of the driver, who should at all times be in control of the vehicle. 3 ...
Page 248 ADDITIONAL DRIVING AID FUNCTIONS – the system may not respond to small vehicles as effectively as to other vehicles; – the system may not operate properly when the road surface is slippery (rain, snow, black ice, etc.). ; – to ensure correct operation, the system needs to distinguish the entire obstacle. So the system cannot detect: –...
Page 249 ADDITIONAL DRIVING AID FUNCTIONS Operation Pedestrian and cyclist detection This function is an addi warning on starting tional driving aid. This function is not in tended, under any cir cumstances, to replace the due 3 care and attention of the driver, who should remain in control of the vehicle at all times. Location of the radars 1 Ensure that the radar zone is not ob...
Page 250 ADDITIONAL DRIVING AID FUNCTIONS Cyclist and pedestrian detection in Activating/deactivating the system etc.), it may alert any type of object zone A that is in zone A or B . from the multimedia screen 2 When the vehicle is stationary with a gear engaged, the function warns the This function does not give driver when there is a risk of collision...
Page 251 ADDITIONAL DRIVING AID FUNCTIONS Activating/deactivating the system – repeatedly press control 5 or 6 to neutral (on a manual gearbox) and from the trip computer 3 speed is zero. reach the menu, then press switch 7 OK; Temporary unavailability – repeatedly press control 5 or 6 to When the function is not available, the reach the "DRIVING ASSIST"...
Page 252 ADDITIONAL DRIVING AID FUNCTIONS Warning This function is an additional driving aid. This function is not under any circumstances intended to replace the due care and attention of the driver, who should at all times be in control of the vehicle. 3 The system will not display a warning: –...
Page 253 ADDITIONAL DRIVING AID FUNCTIONS Deactivating the function You must deactivate the function if the radar zone has been damaged (front bumper). In the event of the system behaving abnormally, deactivate it and contact an authorised dealer. 3 D r i v i n g - 2 5 1...
Page 254 ADDITIONAL DRIVING AID FUNCTIONS Operation Driver vigilance warning The driver vigilance warn ing constantly monitors the The driver vigilance warning is a func driver's attention and can tion that analyses the behaviour of the provide several warnings per jour driver (driving style, vehicle steering, ney. etc.) and alerts them if there is a risk of 3 falling asleep.
Page 255 ADDITIONAL DRIVING AID FUNCTIONS – to reactivate the alerts, press the button 3 once. The indicator light on When the alerts are deacti the button 3 lights up. vated, the system contin ues to assess the driver's Activating and deactivating the state of fatigue. alerts from the multimedia screen 3 ...
Page 256 ADDITIONAL DRIVING AID FUNCTIONS Activating and deactivating the – repeatedly press control 7 or 8 to Detection of road signs alerts from the trip computer 5 reach the "DRIVING ASSIST" menu, then press switch 9 OK; – repeatedly press control 7 or 8 to reach the "Vigilance warning"...
Page 257 ADDITIONAL DRIVING AID FUNCTIONS limit displayed on the instrument panel ment panel (e.g. change the unit from by the system (�� 260 and �� 263). miles to kilometres) in order to display accurate information �� 139. If the detected speed limit is exceeded, the road sign displayed on the instru...
Page 258 ADDITIONAL DRIVING AID FUNCTIONS Activation/deactivation Activating, deactivating the over speed sound alert using the 4 "My Map subscription Safety" button Road sign detection is as For safety reasons, carry sociated with a map sub out any adjustments scription. while the vehicle is sta Note: if there is no map for a 3 tionary. country, a message will appear on the multimedia screen to inform of this and suggest downloading the map information relating to the...
Page 259 ADDITIONAL DRIVING AID FUNCTIONS Activating, deactivating the – repeatedly press control 8 or 9 to overspeed sound alert from the reach the "DRIVING ASSIST" menu, multimedia screen 5 then press switch 10 OK; – repeatedly press control 8 or 9 to reach the "Speed alert"...
Page 260 ADDITIONAL DRIVING AID FUNCTIONS Temporary unavailability In some cases, they are accompanied by the following message: If the system is unavailable for reasons – « Driving assist unavailable » ; related to the camera or map data, the symbol or, depending on the ve – « Check Front camera » ; 3 hicle, the symbol is displayed on –...
Page 261 ADDITIONAL DRIVING AID FUNCTIONS Warning This function is an additional driving aid. This function is not under any circumstances intended to replace the due care and attention of the driver, who should at all times be in control of the vehicle. 3 ...
Page 262 SPEED LIMITER 2. Put the function on standby (and Once you have reached the stored The speed limiter function controls the store the limit speed) (0). speed, no effort on the accelerator engine and, depending on the vehicle, pedal will allow you to exceed the pro the braking system to help you not to 3.
Page 263 SPEED LIMITER The minimum stored speed will be 19 turn as soon as you reach a speed mph (30 km/h). The function can be lower than the memorised speed. activated from 0 mph (0 km/h). Limited speed cannot be main Note: the "Speed limiter" function can tained be activated up to the maximum speed of the vehicle.
Page 264 SPEED LIMITER Recalling the limit speed Temporarily not available To exit the driving assis If a speed has been stored, you can The system controls accel tance, press switch 1 as recall it by pressing switch 3 . eration and deceleration of many times as necessary your vehicle using the engine and until you reach OFF.
Page 265 CRUISE CONTROL 5. Speed limiter activation and in The cruise control function controls the crease (SET/+). This function is an addi engine and braking system to help you tional driving aid. The to maintain a driving speed that you 6. Depending on the vehicle, road sign have chosen, known as the cruising function does not take detection activation switch [O].
Page 266 CRUISE CONTROL Switching on Driving Press switch 1 until the warning Once a cruising speed is memorised light is displayed in green on the in and the cruise control function is ac tive, you may lift your foot off the accel strument panel. Warning light erator pedal. comes on the instrument panel. The 3 message "Cruise control ON" message appears on the instrument panel ac Please note that you companied by dashes to indicate that must keep your feet the cruise control function is in opera...
Page 267 CRUISE CONTROL automatically return to its set cruising – the clutch pedal for a prolonged peri speed. Temporarily not available od or if the vehicle is in neutral for a prolonged period on vehicles equipped The system controls accel Cruising speed cannot be main with a manual gearbox; tained eration and deceleration of –...
Page 268 CRUISE CONTROL Switching off the function Putting the speed limiter The cruise control function is interrupt on standby or switching ed when you press the switch 1 to de it off does not cause a select the limiter. In this case, the rapid reduction in speed: speed is no longer stored.
Page 269 PARKING AIDS The function does not take into ac Parking distance control count towing or carrying systems that An impact to the under are not recognised by the system. side of the vehicle while manoeuvring (e.g. strik ing a post, raised kerb or This function is an addi other street furniture) may result 3 tional driving aid. in damage to the vehicle (e.g. de...
Page 270 PARKING AIDS Operation Obstacle detection pending on the proximity of the detect ed obstacle. In the event of a change in trajectory during a manoeu 3 vre, the risk of collision with an obstacle may be signalled late. Special case of obstacles detected on the side The screen 2 shows the vehicle sur The system is able to detect most ob...
Page 271 PARKING AIDS Activation/deactivation Activating/deactivating the system If a side obstacle is detected: from the trip computer 5 – the beeps become faster and then Activation/deactivation from the sound continuously as the obstacle multimedia screen 4 gets nearer. The area where the obsta cle 3 has been detected is displayed (display D );...
Page 272 PARKING AIDS Adjustment – repeatedly press control 7 or 8 to Vehicle stationary, from the "Vehicle" world on your multimedia screen 4 , reach the "DRIVING ASSIST" menu, then press switch 9 OK; press the "Parking aids" menu. For safety reasons, carry –...
Page 273 PARKING AIDS 7 or 8 to reach the menu. Press Each time the vehicle is When the vehicle is travel the switch 9 OK; started, the function contin ling at a speed below ap – repeatedly press control 7 or 8 to ues the mode saved the proximately 6 mph (10 km/ last time the engine was stopped.
Page 274 PARKING AIDS Guidelines System servicing/repairs – In the event of an impact, the alignment of the ultrasonic sensors may be altered and its operation may conse 3 quently be affected. Deactivate the function and consult an authorised dealer. – Any work in the area where the ultrasonic sensors are located (repairs, replacements etc.) must be carried out by a quali fied professional. Only an authorised dealer is qualified to service the system. System disturbance Some conditions can disrupt or damage the system operation, for example: –...
Page 275 PARKING AIDS Reversing camera Operation 3 Fixed guide lines 3 Trailer guide lines 5 The fixed gauge includes coloured This is shown in blue on the multime markers A , B and C indicating the dia screen 2 . This indicates the trajec distance behind the vehicle: tory of the trailer towbar according to the steering wheel position.
Page 276 PARKING AIDS Settings If an obstacle is detected behind the black screen is displayed temporarily on the multimedia screen 2 . vehicle, the "Auto zoom" switches the current display to a top rear view. This may be caused by a fault affecting To activate/deactivate the "Auto zoom"...
Page 277 PARKING AIDS Difference between the estimated Reversing towards a steep down Reversing towards a protruding distance and actual distance hill slope object Reversing towards a steep uphill slope 3 The fixed guidelines 6 show the dis Position H seems further than position tances as further than they actually J on the screen.
Page 278 EMERGENCY CALL – off: nonoperational (network un If the vehicle is equipped, the emer available, etc.); gency call function can be used to call – red: operation fault; the emergency services (without – flashing green: call in progress. charge) automatically or manually in the event of an accident or illness, re 2. "SOS" button. ducing the time it takes for the emer 3 3.
Page 279 EMERGENCY CALL In the event of a system fault, the 1 In the event of an acci warning light goes off and is no longer Without the emergency call lit up. dent, if the location and feature, the system is not traffic conditions permit, In these two cases, contact an ap trackable and will not be proved dealer as soon as possible.
Page 280 EMERGENCY CALL To guarantee your safety and the proper operation of the system, any oper ation carried out on the battery (removal, disconnection, 3 etc.) must be carried out by a qualified specialist. Risk of serious burns or elec tric shocks. You must respect the replacement intervals (without exceeding them) as stated in the mainte...
Page 281 AIR VENTS, HEATING AND AIR CONDITIONING 4 Yo u r c o m f o r t - 2 7 9...
Page 282 AIR VENTS, HEATING AND AIR CONDITIONING Air vents: air outlets 4 2 8 0 - Yo u r c o m f o r t...
Page 283 AIR VENTS, HEATING AND AIR CONDITIONING Air outlets 4 Yo u r c o m f o r t - 2 8 1...
Page 284 AIR VENTS, HEATING AND AIR CONDITIONING Direction 1 Side window demister outlet. Do not attach any objects Move the cursor 7 to the desired posi 2 Side air vents. to the air vents (e.g. tele tion. 3 Windscreen demisting vents. phone mounting). 4 Centre air vents Side air vents 2 Risk of damage.
Page 285 4 Yo u r c o m f o r t - 2 8 3...
Page 286 AIR VENTS, HEATING AND AIR CONDITIONING Manual air conditioning, heating system Controls 4 2 8 4 - Yo u r c o m f o r t...
Page 287 AIR VENTS, HEATING AND AIR CONDITIONING (depending on the vehicle) 1. Distribution of air in the passenger compartment. 2. De-icing/demisting of the rear screen and, depending on the vehicle, the rear view mirrors. 3. Adjusting the ventilation fan speed. 4. Air recirculation. 5.
Page 288 AIR VENTS, HEATING AND AIR CONDITIONING the front side windows, and the exteri Distribution of air in the passenger or rear view mirrors (depending on the Fuel consumption increas compartment vehicle). It automatically activates the es when the air condition air conditioning and rear screen deic ing is being used (switch it There are five air distribution options. ing functions.
Page 289 AIR VENTS, HEATING AND AIR CONDITIONING Turn controls 1 , 3 and 5 to positions: If the air conditioning is not us Setting position activated "A/C" warning – demisting ing the control 1 will deacti – fan speed to position 3 or 4; light on the button 6 goes –...
Page 290 AIR VENTS, HEATING AND AIR CONDITIONING Automatic climate control The controls 4 2 8 8 - Yo u r c o m f o r t...
Page 291 AIR VENTS, HEATING AND AIR CONDITIONING (depending on the vehicle) 1. Adjusting the air temperature. 2. "Clear View" function. 3. Adjusting the ventilation fan speed. 4. Automatic mode. 5. Air conditioning control. 6. Distribution of air in the passenger compartment. 4 ...
Page 292 AIR VENTS, HEATING AND AIR CONDITIONING You can still adjust the ventilation Automatic mode speed by turning control 3 to increase The air flow is directed towards or reduce the ventilation speed. the dashboard air vents, the front The automatic climate control system footwells and, depending on the vehi...
Page 293 AIR VENTS, HEATING AND AIR CONDITIONING Air recirculation (isolation of the Air conditioning: information passenger compartment) Fuel consumption increas and advice on use es when the air condition This function is managed automatically Advice on use ing is being used (switch it but you can also activate it manually. off when it is not required).
Page 294 AIR VENTS, HEATING AND AIR CONDITIONING Consumption Presence of water under the vehi Use the air conditioning (Combustion version) system regularly, even in After prolonged use of the air condi You will normally notice an increase in cold weather, running it at tioning system, it is normal for water to fuel consumption (especially when dri least once a month for approxi...
Page 295 AIR VENTS, HEATING AND AIR CONDITIONING Additional information sealed) may contain fluorinated green house gases. Depending on label and depending on Depending on the vehicle, you will find the type of refrigerant: the following information on label A af Refrigerant fluid R-1234yf fixed inside the engine compartment. (1) Combustion version: 0.520 kg/ The presence and location of the infor...
Page 296 MULTIMEDIA EQUIPMENT "USB-C" multimedia ports 2 4 The presence and location of this Multimedia screen 5 equipment depends on the vehicle’s Induction charging area 3 multimedia equipment. �� 301 1. Radio 2. "USB-C" multimedia ports 3. Induction charging area 4. Steering column control Please refer to the multime dia instructions for further information.
Page 297 MULTIMEDIA EQUIPMENT Multimedia socket 6 Microphone 7 4 You can use the USB ports to access (For the telephone and voice assistant) the multimedia content of your acces sories and to update the system. Using the telephone The sockets USB can also be used to We remind you of the charge accessories with a maximum need to conform to the...
Page 298 PASSENGER COMPARTMENT EQUIPMENT These systems operate with the igni Windows tion on or off, until one of the front doors is opened (limited to about 3 minutes). Electric windows These systems operate with the igni tion on or off, until one of the front doors is opened (limited to about 3 minutes).
Page 299 PASSENGER COMPARTMENT EQUIPMENT Briefly press or pull a window switch raise the window fully to reinitialise the as far as it will go: the window will be system. When closing the win raised or lowered fully. Pressing the dows, ensure that no If necessary, contact an approved switch again stops the window moving.
Page 300 PASSENGER COMPARTMENT EQUIPMENT Rear light 5 – lighting switches off immediately. Sun visor, mirror, grab handle Courtesy light 3 Sun visors 1 (depending on the vehicle) 4 Move the switch 6 to enable: – continuous lighting; Lower the sun visor 1 . –...
Page 301 PASSENGER COMPARTMENT EQUIPMENT Additional rear view mirror 2 Grab handle 3 Assistance handles 4 4 (depending on the vehicle) This offers support and can be held Help to get into or out of the vehicle. when the vehicle is moving. Lower the sun visor to access the ad...
Page 302 PASSENGER COMPARTMENT EQUIPMENT Luggage compartment accessories Accessories socket socket 2 Accessories socket 1 (depending on the vehicle) 4 Connect accessories They are designed to connect acces with a maximum power sories with a power that must not ex of 120 watts (12 V) only. ceed 120 watts (12 V). When several accessory sockets are used at the same time, the total power of the con...
Page 303 PASSENGER COMPARTMENT STORAGE, FITTINGS Front door storage compartments Driving position storage compart Front storage compartments ments Nothing should be placed on the floor (area in front of the driver) as these objects may slide under the pedals during sudden 4 braking manoeuvres, thus ob structing their use. Ensure that no hard, heavy or pointed objects are placed in the "open"...
Page 304 PASSENGER COMPARTMENT STORAGE, FITTINGS Centre console storage compart ments/induction charging area When turning corners, accelerating or braking, ensure that the recepta cle being held by the cup holder is not dislodged. There is a risk of burning if hot liquid escapes. 4 Sun visor and cab upper storage compartments Cab upper storage compartments 7 and 8 : reserved for transporting ob...
Page 305 PASSENGER COMPARTMENT STORAGE, FITTINGS t is essential not to leave When turning corners, any objects (key USB, card accelerating or braking, SD, credit card, jewellery, ensure that the recepta keys, coins etc.) n the induction cle being held by the cup charging area 11 while charging holder is not dislodged.
Page 306 PASSENGER COMPARTMENT STORAGE, FITTINGS Seatback in table position When turning corners, accelerating or braking, ensure that the recepta cle being held by the cup holder is not dislodged. There is a risk of burning if hot liquid escapes. 4 Glovebox 15 : To open it, press the button 16 .
Page 307 PASSENGER COMPARTMENT STORAGE, FITTINGS Storage compartment under front Storage compartment underneath bench seat 24 rear bench seat 26 The storage compartment 18 must be closed when folding the centre seatback. If you fail to follow this recommen dation, you risk damaging your vehicle. 4 Rear storage compartments Clothes hooks 23 To access, pull one of the tabs 25 .
Page 308 PASSENGER COMPARTMENT STORAGE, FITTINGS Check that the rear seat Maximum weight allowed in belts are positioned and the rear load area upper operating correctly each storage compartment 27 : time the rear seats are 35 kg evenly distributed. moved. Rear load area upper storage com 4 partment 27 (depending on the vehicle)
Page 309 TRANSPORTING OBJECTS Transporting objects in the rear load area 4 F max: 500 daN (as indicated on label A located in the rear load area). Always position the heaviest items directly Depending on the vehicle, securing on the floor. Use the rings 1 and 2 can be used to stop lashing points on the lug...
Page 310 TRANSPORTING OBJECTS Fitting the towing ball Towbar and 420 mm, with the vehicle laden. Torque tighten the bolts 3 to 180 N.m. (Newton metres). Towing For fitting and conditions of use, refer to the equipment fitting instructions. Please keep these instructions 4 with the rest of the vehicle docu...
Page 311 TRANSPORTING OBJECTS Roof bars Permissible nose weight, If original roof bars, ap Accessing the mounting points 1 maximum permissible proved by our Technical towing weight while Department, are sup braked and unbraked �� 381. plied with screws, only Choice and fitting of towing use these screws for attaching equipment the roof bars to the vehicle.
Page 312 TRANSPORTING OBJECTS For information on the range of equipment adapt ed to your vehicle, we ad vise you to consult an approved Dealer. Please refer to the manufacturer’s instructions on how to fit and use 4 the bars. Please keep these instructions with the rest of the vehicle docu mentation. Maximum permissible load on roof �� 381. 3 1 0 - Yo u r c o m f o r t...
Page 313 ACCESSING THE ENGINE, LEVELS Bonnet Please note when work ing close to the engine Opening the bonnet that it may be hot. The engine cooling fan may also start at any moment. The label in the engine com partment reminds you of this. Risk of injury. 5 Closing the bonnet Ensure that the windscreen wiper blades are correctly positioned.
Page 314 ACCESSING THE ENGINE, LEVELS Opening the bonnet Engine oil gine has been switched off for some time. General information The dipstick must be used to read the exact oil level and make sure It is normal for an engine to use oil for that the maximum level has not lubrication and cooling of moving parts been exceeded (risk of engine dam...
Page 315 ACCESSING THE ENGINE, LEVELS – read the level: it should never fall be low the "MINI" level B or exceed the The instrument panel Adding engine oil "MAXI" level A . display only gives a Use a funnel or protect warning when the mini Once the level has been read, push the filling neck area to the dipstick in as far as it will go.
Page 316 ACCESSING THE ENGINE, LEVELS Topping up, filling Do not exceed the "MAXI" level and remember to refit the cap 1 and the dipstick Engine oil grade Refer to the maintenance document for your vehicle. 5 Oil change Service interval: refer to the mainte nance document for your vehicle. –...
Page 317 ACCESSING THE ENGINE, LEVELS Warning Before carrying out any Please note when work action in the engine ing close to the engine Adding engine oil compartment, you must that it may be hot. The Use a funnel or protect switch off the ignition engine cooling fan may the filling neck area to �� 183.
Page 318 ACCESSING THE ENGINE, LEVELS Frequency of checking coolant lev When working in the en gine compartment, en Check the coolant level regularly sure that the windscreen (very severe damage is likely to be wiper stalk is in the park caused to the engine if it runs out of coolant). position. Risk of injury.
Page 319 ACCESSING THE ENGINE, LEVELS Electric version Note: for a new vehicle in the running in phase: the fluid level may be higher The vehicle drive system than the "MAXI" mark on the reservoir, in an electric vehicle us then drop between the level "MINI" and es a direct voltage of ap...
Page 320 ACCESSING THE ENGINE, LEVELS If the level needs to be topped up, only Levels, filters use products approved by our Techni cal Department which ensure: Brake fluid level – antifreeze protection; This should be checked frequently, and – anticorrosion protection of the cool immediately if you notice even the ing system.
Page 321 ACCESSING THE ENGINE, LEVELS Replacement intervals Fluid Before carrying out any Refer to the maintenance document Only use windscreen washer fluid con action in the engine for your vehicle. taining antifreeze. compartment, you must We advise you to consult an approved switch off the ignition dealer or a qualified professional.
Page 322 ACCESSING THE ENGINE, LEVELS 5 The replacement of filter elements (air filter, cabin filter, diesel filter etc.) is scheduled in the maintenance opera tions for your vehicle. Replacement intervals for filter components: refer to the mainte nance document for your vehicle. On equipped vehicles, if warning light 4 appears in red, this indicates that the air filter is clogged.
Page 323 BATTERY Label A Depending on the vehicle, the batter is 12 volt battery located under the front carpet and does not require any maintenance. You should not open it or add any fluid. To get to it: – lift the carpet 1 ; –...
Page 324 BATTERY Replacing the battery Electric versions For your own safety and The vehicle drive system for the proper operation in an electric vehicle us of the vehicle's electrical es a direct voltage of ap equipment (lights, wind proximately 400 volts. screen wipers, ABS, etc.), any in This system can get hot during tervention on the battery (re and after switching off the ignition. moval, disconnection, etc.) must Respect warning messages given categorically be performed by a...
Page 325 CLEANING You should do the following Repair, or have repaired quickly, areas Bodywork maintenance where the paint has been damaged, to Wash your car frequently, with the en prevent corrosion spreading. gine off, with cleaning products rec A well-maintained vehicle will last Remember to visit the body shop peri ommended by the manufacturer (never longer.
Page 326 CLEANING Using a roller type car wash – mechanical components (e.g. engine We have selected special compartment); Return the wiper stalk to the Park posi – wheels (e.g. braking system compo products to care for your tion �� 166. Check the mounting of ex nents such as brake callipers); vehicle and you can obtain ternal accessories, additional lights –...
Page 327 CLEANING Multimedia screen Textiles (seats, door trim, etc) wipe clean with a soft cloth or cotton wool. Maintenance of the screen may de Vacuum-clean the textiles regularly. Finally, carefully dry off with a soft dry pend on the type of multimedia equip cloth. Liquid stain ment. Please refer to the multimedia instructions for further information.
Page 328 CLEANING Removal/replacing removable equipment originally fitted in the vehicle If you need to remove equipment in or der to clean the passenger compart ment (for example, mats), always en sure that they are correctly refitted and are the right way around (the driver's mat should be fitted on the driver's side, etc.) and fit them with the compo nents supplied with the equipment (for 5 example, the driver mat should always be fixed using the pre-fitted mounting...
Page 329 TYRES become visible 2 : it is then neces Tyres sary to replace your tyres because Incorrect tyre pres the tread rubber is 1.6 mm deep at sures lead to abnormal most, resulting in poor road-holding Maintaining the tyres tyre wear and unusually on wet roads.
Page 330 TYRES Fitting new tyres Please be aware that a Chains may only be fit poorly tightened or miss ted to tyres of the same For your safety and to ing valve cap can make size as those originally comply with the law. the tyres less airtight and fitted to your vehicle.
Page 331 TYRES Note: be aware that these tyres may Tyre pressure As the tyre pressure sometimes have: monitor may take sever – a direction for driving; al minutes to correctly – a maximum speed index which may be lower than the maximum speed of determine the positions your vehicle.
Page 332 TYRES For your safety and to Vehicle used fully comply with the law. laden (Maximum Per When they need to be missible All-up Weight) replaced, only tyres of and towing a trailer the same make, size, type and The maximum speed must be lim profile should be used on a single ited to 62 mph (100 km/h) and axle.
Page 333 TYRES The kit repairs tyres Do not attempt to use The kit is only approved when the tread A has the inflation kit if the tyre for inflating the tyres of been damaged by ob has been damaged as a the vehicle originally jects smaller than 4 mm.
Page 334 TYRES Inflation kit – refer to the information on the in flation kit compressor that is lo cated under the driver's seat and follow the instructions for use; – inflate the tyre to the recommended pressure �� 329; – after a maximum of 15 minutes, stop inflating and read the pressure (on the pressure gauge 2 ).
Page 335 TYRES The container must be replaced after If the vehicle is parked Nothing should be the first use even if liquid remains in side. on the hard shoulder, placed around the you must warn other driver’s feet as during road users of your sudden braking such ob Please be aware that a vehicle's presence with a warning jects may slide under the pedals poorly tightened or miss...
Page 336 TYRES Tools Nothing should be Location of the tool kit placed on the floor (area in front of the driver) as these objects may slide under the pedals during sudden braking manoeuvres, thus ob structing their use. Contents of the tool kit (depending on the vehicle) 6 Depending on the vehicle, the cover 2 has to be removed to access the tool...
Page 337 TYRES For your safety, the use Do not leave the tools of a jack not recom unsecured inside the ve mended by the manufac hicle as they may be turer is strictly prohibited. projected during braking. The jack is specific to the vehicle After use, check that all the tools and used to change the wheels.
Page 338 TYRES Puncture, emergency spare – Lower the spare wheel as far down In some cases (rear punc as possible by turning the wheelbrace wheel 4 to the left; ture, vehicle loaded with – unclip the component 2 from the Location of the emergency spare towing equipment, etc.), it wheel rim;...
Page 339 TYRES Unlocking the wheel Unlocking dual wheels – centre the component 2 in the mid dle of the wheel; – lift the retaining cable up as far as it will go by turning the wheelbrace 4 to the right and check the wheel is com pletely secure. Note: do not place a punctured wheel with aluminium wheel rims in the emer...
Page 340 TYRES Using the hydraulic jack Do not leave the tools Switch on the hazard unsecured inside the ve warning lights. To prevent any risk of in hicle as they may be Keep the vehicle away jury or damage to the ve projected during braking. from traffic and on a lev hicle, only crank the jack After use, check that all the tools el surface where it will not slip.
Page 341 TYRES Position the jack 1 horizontally. The head of the jack must line up with the point 2 provided. Rear jack support point 3 (van ver sions over 3.5 tonnes) 6 Position the head of the jack against Position the head of the jack against the contact point 2 close to the wheel the contact point 3 close to the wheel concerned.
Page 342 TYRES Position the jack 1 horizontally. The Position the jack 1 horizontally. The head of the jack must line up with the head of the jack must line up with the point 3 provided. point 4 provided. Start pumping by moving the three ex Rear jack support point 4 (rear- tension pieces 5 placed end to end, wheel drive and chassis cab ver...
Page 343 TYRES Tighten the nuts and lower the jack. Switch on the hazard With the wheel on the ground, tighten warning lights. the bolts completely, following the or der of tightening below: Keep the vehicle away from traffic and on a lev el surface where it will not slip. Apply the parking brake and en gage a gear (first or reverse, or in position D, M or R for automatic transmissions).
Page 344 TYRES Vehicle equipped with a jack with a Remove the jack 2 located in the tool heightener kit. Familiarise yourself with the jack arrangement prior to using it. Front jack support point 3 6 Position the jack 2 horizontally. The head of the jack must line up with the point 3 provided.
Page 345 TYRES Place the jack 2 horizontally. The jack Place the jack 2 horizontally. The jack head 5 must be positioned at the head 5 must be positioned at the same level as the support point 3 . same level as the support points 6 . Start cranking the jack up by hand to Rear jack support point 6 align the base plate (which should be...
Page 346 TYRES Wheel trims, wheel trim – wheel Central wheel trim 4 Trim 2 6 With the wheel on the ground, tighten the bolts with force, starting with side (concealed wheel bolts) C , then E , G , D and end with F . Remove it using the hubcap tool 1 , in Check the tightness and tyre pressure (concealed wheel bolts) serting the tool into the recesses 3...
Page 347 TYRES Wheel trim 5 Wheel trim 6 6 (exposed wheel bolts) (front wheel only for vehicles equipped with dual wheels) To remove it without removing the Remove the nut covers 6 by hand, wheel, press it at the points indicated by the arrows.
Page 348 BREAKDOWN RECOVERY Towing a vehicle fitted with an au Towing: breakdown tomatic gearbox – Use a rigid tow bar. If a rope or cable is used The steering wheel must not be locked; the ignition key must be in (where the law allows "M" position (on) in order to unlock this), the vehicle being towed the steering column.
Page 349 BREAKDOWN RECOVERY Only use at the front: When storing the tools, – the towing ring 5 (located in the tool ensure that they are cor kit). rectly placed in their These towing points may only be used original positions in the for towing: never use them for lifting the vehicle directly or indirectly.
Page 350 BREAKDOWN RECOVERY When storing the tools, Do not use your electric ve ensure that they are cor hicle to restart the 12 volt rectly placed in their battery in another vehicle. original positions in the The 12 volt electric power of an toolbox and store the toolbox un electric vehicle is not enough to der the driver’s seat. Do not leave ...
Page 351 BREAKDOWN RECOVERY switched off before disconnecting or reconnecting a battery; Special procedures may Handle the battery with – when charging, switch off the charg be required to charge care as it contains sul er before connecting or disconnecting some batteries. Contact phuric acid which must the battery; your approved dealer. not come into contact –...
Page 352 BREAKDOWN RECOVERY battery supplying the current should Start the engine of the vehicle supply have a capacity (amp-hours, Ah) which ing the current and run it at an interme is at least the same as that of the dis diate engine speed. charged battery. If your vehicle's engine does not start Ensure that there is no risk of contact immediately, switch off the ignition and between the two vehicles (risk of short wait a few seconds before repeating circuiting when the positive terminals...
Page 353 HEADLIGHTS, LIGHTS: REPLACING BULBS Main beam headlights 2 Exterior lighting: replacing bulbs Please note when work ing close to the engine Front headlights that it may be hot. The engine cooling fan may also start at any moment. The To comply with local legisla tion, or as a precaution, you label in the engine com...
Page 354 HEADLIGHTS, LIGHTS: REPLACING BULBS Rear and indicator lights Bulb type:H7. – access the bulb holder located be hind the bumper via the flap; Note: once the bulb has been re – unscrew the bulb holder. Rear lights 1 placed, ensure the cover is positioned correctly. Bulb type: H16LL. Direction indicator lights 4 Any operation on (or Consult an approved Dealer.
Page 355 HEADLIGHTS, LIGHTS: REPLACING BULBS Number plate lights 10 Depending on the vehicle, remove the protective grilles. Loosen the two bolts 2 and pull the rear light unit A . The bulbs are under pressure and may break when replaced. Risk of injury. 6 ...
Page 356 HEADLIGHTS, LIGHTS: REPLACING BULBS Side position lights Remove the light cover to gain access to the bulb. Bulb type: W5W. Side indicator lights 6 To comply with local legisla tion, or as a precaution, you can obtain an emergency kit containing a set of spare bulbs Move the mirror 11 to access the bolt.
Page 357 HEADLIGHTS, LIGHTS: REPLACING BULBS Interior lighting: changing bulbs To comply with local legisla Halogen bulb courtesy light 1 tion, or as a precaution, you can obtain an emergency kit containing a set of spare bulbs and fuses from an approved deal The bulbs are under pressure and may break when replaced.
Page 358 HEADLIGHTS, LIGHTS: REPLACING BULBS LED light 2 6 Consult an approved dealer. 3 5 6 - P r a c t i c a l a d v i c e...
Page 359 WIPER BLADES: REPLACEMENT Removal Replacing windscreen wiper blades 2 Access 6 To replace the wipers, first put them in the service position B . With the ignition on and the engine stopped: – move the stalk 1 twice in succession to position A (single sweep): the wiper To access the wiper blades, stand on blades will stop in the service position...
Page 360 WIPER BLADES: REPLACEMENT To return the blades to the lowered po sition, make sure that the blades are – In frosty weather, folded down onto the windscreen then make sure that the wiper set the stalk 1 to position A (single blades are not stuck by sweep): the windscreen wiper blades ice (to avoid the risk of the motor will fold into the bonnet when the igni...
Page 361 FUSES Tweezers 1 Your vehicle is equipped with two fuse Fuse box boxes in the passenger compartment and in the engine compartment. Check the fuse in ques tion and, if necessary, replace it (replacement fuse must have the same rating as the original. If a fuse is fitted with too high a rating, it may cause the electrical circuit to overheat (risk of fire) in the event of an item of equipment...
Page 362 FUSES Icon Icon Icon Icon Allocation of fuses – Heated windscreen One touch electric win (the presence of certain fuse de dows for driver's seat pends on the vehicle equipment lev Multimedia accessories Heating and air condition socket/Pre-equipment for ing system accessories Icon Icon Luggage compartment ac Courtesy light Heated seats cessories socket/towbar socket...
Page 363 FUSES Removing the cover C Fuses in the engine compart Deactivate the Stop and ment Start function for any op eration performed in the engine compartment. Before carrying out any action in the engine Some functions are protected by fuses compartment, you must located in the engine compartment switch off the ignition �� 183.
Page 364 FUSES Allocation of fuses: engine compartment (the presence of certain fuses DEPENDS ON THE VEHICLE EQUIPMENT LEVEL) Icon Allocation Icon Allocation De-icing Right-hand main beam headlight Heating and air conditioning system Right-hand dipped beam headlight Windscreen wiper 6 Left-hand dipped beam headlight ...
Page 365 FITTING A RADIO If your vehicle is not fitted with an au dio system, one can be fitted and loca – In all cases, follow the tions have been provided for: manufacturer’s instructions – the radio 1 ; carefully. – front speakers 2 (depending on the – The specifications of the brack vehicle). ets and wires (available from our To install any equipment, please con network) vary depending on the sult an approved dealer.
Page 366 INSTALLATION AND USE OF ACCESSORIES Warning Electrical and electronic accessories Before installing this type of accessory (particularly for transmitters/receivers: frequency bandwidth, power level, position of the aerial, etc.), make sure it is compatible with your vehicle. Contact an approved dealer. Before connecting an accessory to a socket, please ensure that it does not exceed the maximum power autho...
Page 367 INSTALLATION AND USE OF ACCESSORIES If you wish to install accessories on the vehicle: consult an approved dealer. Also, to ensure the correct operation of your vehicle, and to avoid any risk to your safety, we recommend that you use only accessories specifically designed for your vehicle, which are the only accessories for which the manufacturer will provide a warranty.
Page 368 OPERATING FAULTS The following advice will enable you to carry out quick, temporary repairs. For safety reasons you should always contact an approved dealer as soon as possible. Using the remote control POSSIBLE CAUSES ACTION REQUIRED The remote control does not lock The remote control battery is flat.
Page 369 OPERATING FAULTS The starter is activated POSSIBLE CAUSES ACTION REQUIRED Warning lights dim or fail to come on; Battery terminals not tight, battery termi Call an approved dealer. the starter does not run. nals disconnected or oxidised. Discharged battery or not operational. Connect another battery to the faulty battery �� 348 or replace the battery if necessary �� 321.
Page 370 OPERATING FAULTS Electric version POSSIBLE CAUSES ACTION REQUIRED Impossible to charge the The outdoor temperature is lower than -26°C. Recharge your vehicle in a more suitable envi ronment. If necessary �� 346. traction battery. The charging flap warning No electrical current in the wall socket or poor Check your installation (circuit breaker, pro light flashes red.
Page 371 OPERATING FAULTS On the road POSSIBLE CAUSES ACTION REQUIRED Vibrations. Tyres not inflated to the correct pressure, in Check the tyre pressures: if this is not the cause, correctly balanced or damaged. have their condition checked by an approved deal Coolant boiling in the Mechanical fault: damaged cylinder head Stop the engine. coolant reservoir. gasket.
Page 372 OPERATING FAULTS On the road POSSIBLE CAUSES ACTION REQUIRED The engine is overheating. Engine cooling fan not working. Stop the vehicle, switch off the engine and contact The coolant temperature an approved dealer. warning light and the warning light come on. ...
Page 373 OPERATING FAULTS ACTION RE Stopped POSSIBLE CAUSES QUIRED The engine cooling fan starts This is not necessarily a fault. The engine cooling fan group may start to run to run after the ignition is in order to regulate the engine temperature. This operation may last several switched off.
Page 374 OPERATING FAULTS Electrical equipment POSSIBLE CAUSES ACTION REQUIRED The wipers do not work. Wiper blades stuck. Free the blades before using the wipers. Faulty electrical circuit. Consult an approved Dealer. Fuse damaged. Replace the fuse or have it replaced �� 359.
Page 375 OPERATING FAULTS Electrical equipment POSSIBLE CAUSES ACTION REQUIRED In this situation, the traces disappear af ter a few hours. 6 P r a c t i c a l a d v i c e - 3 7 3...
Page 376 INFORMATION ABOUT THE VEHICLE The information shown on the vehi Vehicle identification plates cle identification plate should be quoted on all correspondence or or ders. The presence and location of the in formation depends on the vehicle. Identification plate A 1.
Page 377 INFORMATION ABOUT THE VEHICLE Technical Information for the Engine identification, engine emergency services specifications Engine identification 7 The QR Code on the label A allows emergency workers to use a tablet or smartphone to immediately access Please quote the engine identifica tion information provided in zone A technical information that is useful for working on the vehicle in the event of...
Page 378 INFORMATION ABOUT THE VEHICLE Engine specifications Engine type, combustion engine version Versions 2.0 dCi Engine type (see engine plate) 1 998 Cubic capacity (cc) Injection Diesel Type of fuel Diesel Octane rating The label located in the fuel filler flap indicates the authorised fuels. Diesel fuel compliant with standard EN 590 containing up to 7% fatty 7 acid methyl ester in volume.
Page 379 7 Te c h n i c a l s p e c i f i c a t i o n s - 3 7 7...
Page 380 INFORMATION ABOUT THE VEHICLE Dimensions (in metres) Dimensions diagram 7 3 7 8 - Te c h n i c a l s p e c i f i c a t i o n s...
Page 381 INFORMATION ABOUT THE VEHICLE Dimensions table Complete vehicles without recent alterations Standard van Raised van Standard chassis Long chassis 1 Long chassis 1 Long chassis 2 Wheelbase 3,585 4,215 Total length 5,685 (5,780*) 6,315 (6,410*) 7,075* Front overhang 0,970 Rear overhang 1,130 (1,225*) 1,890...
Page 382 INFORMATION ABOUT THE VEHICLE *** Version with "long arm" door mirrors 7 3 8 0 - Te c h n i c a l s p e c i f i c a t i o n s...
Page 383 INFORMATION ABOUT THE VEHICLE Weights (in kg) The weights indicated are for a basic vehicle without options: they vary depending on your vehicle's equipment. Con sult your approved Dealer. Maximum Permissible All-up Weights indicated on the manufacturer's plate (�� 374) Weight (MMAC) Gross Train Weight (MTR) Braked trailer weight* (MRF) found by calculating: MTR-MMAC Unbraked trailer weight*...
Page 384 REPLACEMENT PARTS AND REPAIRS Original parts are based on very stringent specifications and are subjected to specific tests. Therefore, they are of at least the same level of quality as the parts fitted originally. If you always fit genuine replacement parts to your vehicle, you will ensure that it performs well. Furthermore, repairs carried out in the approved dealer network with original parts are guaranteed according to the conditions stated on the back of the repair or...
Page 385 SERVICE SHEETS VIN: .................. Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........ □ Anticorrosion check: OK □ Not OK* □ Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ 7 ........ □ Anticorrosion check: OK □ Not OK* □ Date: Miles (km): Invoice number: Comments/miscellaneous...
Page 386 SERVICE SHEETS VIN: .................. Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........ □ Anticorrosion check: OK □ Not OK* □ Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ 7 ........ □ Anticorrosion check: OK □ Not OK* □ Date: Miles (km): Invoice number: Comments/miscellaneous...
Page 387 SERVICE SHEETS VIN: .................. Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........ □ Anticorrosion check: OK □ Not OK* □ Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ 7 ........ □ Anticorrosion check: OK □ Not OK* □ Date: Miles (km): Invoice number: Comments/miscellaneous...
Page 388 SERVICE SHEETS VIN: .................. Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........ □ Anticorrosion check: OK □ Not OK* □ Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ 7 ........ □ Anticorrosion check: OK □ Not OK* □ Date: Miles (km): Invoice number: Comments/miscellaneous...
Page 389 SERVICE SHEETS VIN: .................. Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........ □ Anticorrosion check: OK □ Not OK* □ Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ 7 ........ □ Anticorrosion check: OK □ Not OK* □ Date: Miles (km): Invoice number: Comments/miscellaneous...
Page 390 SERVICE SHEETS VIN: .................. Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........ □ Anticorrosion check: OK □ Not OK* □ Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ 7 ........ □ Anticorrosion check: OK □ Not OK* □ Date: Miles (km): Invoice number: Comments/miscellaneous...
Page 391 ANTICORROSION CHECK If the continuation of the warranty is subject to repair, it is indicated below. VIN: .................. Date of repair: Stamp Corrosion repair operation to be carried out: Date of repair: Stamp 7 Repair to be carried out: Te c h n i c a l s p e c i f i c a t i o n s - 3 8 9...
Page 392 ANTICORROSION CHECK If the continuation of the warranty is subject to repair, it is indicated below. VIN: .................. Date of repair: Stamp Corrosion repair operation to be carried out: Date of repair: Stamp 7 Repair to be carried out: 3 9 0 - Te c h n i c a l s p e c i f i c a t i o n s...
Page 393 ANTICORROSION CHECK If the continuation of the warranty is subject to repair, it is indicated below. VIN: .................. Date of repair: Stamp Corrosion repair operation to be carried out: Date of repair: Stamp 7 Repair to be carried out: Te c h n i c a l s p e c i f i c a t i o n s - 3 9 1...
Page 394 ANTICORROSION CHECK If the continuation of the warranty is subject to repair, it is indicated below. VIN: .................. Date of repair: Stamp Corrosion repair operation to be carried out: Date of repair: Stamp 7 Repair to be carried out: 3 9 2 - Te c h n i c a l s p e c i f i c a t i o n s...
Page 395 ANTICORROSION CHECK If the continuation of the warranty is subject to repair, it is indicated below. VIN: .................. Date of repair: Stamp Corrosion repair operation to be carried out: Date of repair: Stamp 7 Repair to be carried out: Te c h n i c a l s p e c i f i c a t i o n s - 3 9 3...
Page 396 ANTICORROSION CHECK If the continuation of the warranty is subject to repair, it is indicated below. VIN: .................. Date of repair: Stamp Corrosion repair operation to be carried out: Date of repair: Stamp 7 Repair to be carried out: 3 9 4 - Te c h n i c a l s p e c i f i c a t i o n s...
Page 397 ANTICORROSION CHECK If the continuation of the warranty is subject to repair, it is indicated below. VIN: .................. Date of repair: Stamp Corrosion repair operation to be carried out: Date of repair: Stamp 7 Repair to be carried out: Te c h n i c a l s p e c i f i c a t i o n s - 3 9 5...
Page 398 ALPHABETICAL INDEX A B C D E F G H I K L M N O P R S T U V W Clock, 146, 146 Configuration menu, 144 Accessories socket, 300 Configuration menu settings, 144 Access to the engine compartment, ...
Page 399 ALPHABETICAL INDEX Engine specifications, 375 Environment, 197, 197 Instrument panel, 144 Exterior lighting and signals, 160 Interior lighting, 297 351 Exterior lights, 355 Interior lighting: changing bulbs, 146 Exterior temperature, Interior trim maintenance, ...
Page 400 ALPHABETICAL INDEX Manual air conditioning, 284 Reversing camera, 273 Methods of restraint in addition to the front seat belts, 77 Roof bars, 309, 309 Mirrors, 298 Roof bars rack, 309 144 Multimedia equipment, Safe distance alert, ...
Page 401 ALPHABETICAL INDEX Tyre inflation, 329 Tyre inflation kit, 330 Tyre pressure, 329 208 Tyre pressure loss warning, 327, 327, 327, 329 Tyres, Unlocking the doors, 57 Vehicle customisation settings, 144 Vehicle dimensions, ...
Page 404 RENAULT S.A.S. SOCIÉTÉ PAR ACTIONS SIMPLIFIÉE / 122-122 BIS, AVENUE DU GENERAL LECLERC 92100 BOULOGNE- BILLANCOURT R.C.S. NANTERRE 780 129 987 — SIRET 780 129 987 03591 / renaultgroup.com NU 1483-2 – 77 11 416 160 – 08/2024 – Edition anglaise...

Save PDF
