PCSS-A Series Technical Manual
Page 58
Original Language Version: 1.25
Channel # Units
0 microns
1 microns
2 microns
3 - 7 N/A
8 microns
9 microns
10 - 12 N/A
13 N/A
14 N/A
15 microns
16 microns
17 enum
18 enum
19 microns
20 0.001°
21 microns
22 microns
23 microns
24 microns
25 enum
26 enum
27 enum
28 0.001°
29 0.001°
30 %
31 enum
32 mm/s
33 enum
Table 8-14: Analogue inputs received from the CNC (An_in)
Channel # Units
0 microns
1 N/A
Table 8-15: Analogue outputs sent by the PCSS (An_out)
Description
Reference Y1
Reference Y2
Pinching point
Reserved
CNC mute or slow speed position
Up-stand height
Reserved
Count direction Y1
Count direction Y2
Machine length
Sheet thickness
Material type
Exclusion zone size
Punch height
Programmed angle
Die V width
Sheet left Z position
Sheet length
Penetration depth
Bend method
Sub-bend method
Bend mode
Measured angle from IMG-100
Warp from IMG-100
Confidence from IMG-100
Image status from IMG-100
Pressing speed
Punch type
Description
Mute or slow speed position calculated by PCSS
Condition code from PCSS
